Page 1 Table of Contents Introduction Instrument Cluster Warning lights and chimes Gauges Message center Entertainment Systems Auxiliary input jack (Line in) USB port Satellite radio information Navigation system SYNC Climate Controls Manual heating and air conditioning Dual electronic automatic temperature control Navigation system based climate control Rear window defroster Lights...
Page 2: Table Of Contents
Table of Contents Locks and Security Keys Locks Anti-theft system Seating and Safety Restraints Seating Safety restraints Airbags Child restraints Tires, Wheels and Loading Tire information Tire inflation Tire Pressure Monitoring System (TPMS) Vehicle loading Trailer towing Recreational towing Driving Starting Brakes AdvanceTrac...
Page 4: Introduction
Introduction CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
Page 5 Introduction Warning symbols on your vehicle When you see this symbol, it is imperative that you consult the relevant section of this guide before touching or attempting adjustment of any kind. Protecting the environment We must all play our part in protecting the environment.
Page 6 In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may...
Page 7 EDR. Ford Motor Company and Ford of Canada do not access event data recorder...
Page 8 If you do not want Ford or its vendors to receive this information, do not activate the service. Ford Motor Company and the vendors it uses to provide you with this information do not store your vehicle travel information.
Page 9 Introduction WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that you use extreme caution when using any device or feature that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
Page 10 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Airbag - Front Child Seat Lower Airbag - Side Anchor Child Seat Tether Brake System Anchor Anti-Lock Brake System Parking Brake System Brake Fluid -...
Page 11 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Child Safety Door Interior Luggage Lock/Unlock Compartment Release Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...
Page 12: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Standard instrument cluster shown, optional cluster similar Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause extensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulbs work.
Page 13 Instrument Cluster Solid illumination after the engine is started indicates the On Board Diagnostics System (OBD-II) has detected a malfunction. Refer to On board diagnostics (OBD-II) in the Maintenance and Specifications chapter. If the light is blinking, engine misfire is occurring which could damage your catalytic converter.
Page 14 Instrument Cluster Airbag readiness: If this light fails to illuminate when the ignition is turned to on, continues to flash or remains on, have the system serviced immediately by your authorized dealer. A chime will sound when there is a malfunction in the indicator light. Safety belt: Reminds you to fasten your safety belt.
Page 15 Instrument Cluster Low washer fluid (RTT): Illuminates when the washer level in the washer fluid reservoir is low. Door ajar (RTT): Illuminates in the message center display when the ignition is in the run position and any door is open. Trunk ajar (RTT): Illuminates in the message center display when the ignition is in the run position...
Page 16 Instrument Cluster more information on this system, refer to Tire pressure monitoring system (TPMS) in the Tires, Wheels and Loading chapter. Adaptive cruise control (ACC) (if equipped): Illuminates when ACC is engaged while following a vehicle. Refer to Adaptive cruise control in the Driver Controls chapter for more information.
Page 17: Gauges
Instrument Cluster Key-in-ignition warning chime: Sounds when the key is left in the ignition in the off or accessory position and the driver’s door is opened. Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (the key is not in the ignition) and the driver’s door is opened.
Page 18 Instrument Cluster WARNING: Never remove the coolant reservoir cap while the engine is running or hot. Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the on position). The fuel gauge may vary slightly when the vehicle is in motion or on a grade.
Page 19: Message Center
Instrument Cluster MESSAGE CENTER Your vehicle’s message center allows you to configure/personalize certain vehicle options to suit your needs. The message center is also capable of monitoring many vehicle systems and will alert you to potential vehicle problems and various conditions with an informational message followed by a long indicator chime.
Page 20 Instrument Cluster If you calculate your average fuel economy by dividing distance traveled by gallons of fuel used (liters of fuel used by 100 kilometers traveled), your figure may be different than displayed for the following reasons: • Your vehicle was not perfectly level during fill-up •...
Page 21 Instrument Cluster System check and vehicle feature customization Press the SETUP button repeatedly to cycle the message center through the following features: RESET FOR SYSTEM CHECK When this message appears, press RESET and the message center will begin to cycle through the following systems and provide a status of the item if needed.
Page 22 Instrument Cluster 3. Once “OIL LIFE SET TO XXX%” is displayed, release and press the RESET button to change the Oil Life Start Value. Each release and press will reduce the value by 10%. Note: Oil life start value of 100% equals 7,500 miles (12,000 km) or 12 months.
Page 23 Instrument Cluster Press RESET to turn the warning chime on or off. The system will revert to chime on each time the vehicle is started. The heads up display and/or chime will activate briefly to confirm the last setting. COLLISION WARN SYSTEM (if equipped) This feature warns the driver of a possible collision.
Page 24 Instrument Cluster LANGUAGE = ENGLISH / SPANISH / FRENCH Allows you to choose which language the message center will display in. Selectable languages are English, Spanish, or French. Waiting four seconds or pressing the RESET button cycles the message center through each of the language choices. Press and hold RESET for two seconds to set the language choice.
Page 25 Instrument Cluster XXX MILES TO E FUEL LEVEL LOW — Displayed as an early reminder of a low fuel condition. CHECK FUEL FILL INLET — Displayed when the fuel fill inlet may not be properly closed. Refer to Easy Fuel™ “no cap” fuel system in the Maintenance and Specifications chapter.
Page 26 Instrument Cluster SERVICE POWER STEERING — The power steering system has detected a condition that requires service. SERVICE POWER STEERING NOW — The power steering system has detected a condition that requires service immediately. TRUNK AJAR — Displayed when the trunk is not completely closed. REMOVE OBJECTS NEAR PASS SEAT —...
Page 27 Instrument Cluster SENSOR BLOCKED SEE MANUAL (if equipped) — Displayed when the blind spot information system/cross traffic alert system sensors are blocked. See Blind Spot Information System (BLIS ) with Cross Traffic Alert in the Driving chapter. VEHICLE COMING FROM LEFT (if equipped) — Displayed when the blind spot information system with cross traffic alert (CTA) system is operating and senses a vehicle.
Page 28 Instrument Cluster COLLISION WARN NOT AVAILABLE SENSOR BLOCKED SEE MANUAL (if equipped) — Displayed when the collision warning system radar is blocked because of poor radar visibility due to bad weather or ice/mud/water in front of the radar. Driver can typically clean the sensor to resolve.
Page 29 Instrument Cluster MAX # OF KEYS LEARNED (if equipped) — Displayed during spare key programming, after a fourth Intelligent Access Key is programmed or upon entering spare key programming mode with four Intelligent Access Keys already programmed to the vehicle. MYKEY ACTIVE DRIVE SAFELY —...
Page 30 Instrument Cluster SERVICE ADVANCETRAC — Displayed when the AdvanceTrac system has detected a condition that requires service. TO STOP ALARM START VEHICLE — Displayed when the perimeter alarm system is armed and the vehicle is entered using the key on the driver’s side door.
Page 31: Entertainment Systems
AM/FM CD/MP3 satellite compatible sound system WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 32 Entertainment Systems Setting the clock To set the time, press CLOCK. The display will read SET TIME. Use the memory preset numbers (0–9) to enter in the desired time–hours and minutes. The clock will then begin from that time. AM/FM Radio / VOL (Power/Volume): Press to turn the radio on/off.
Page 33 Entertainment Systems Saving presets automatically: Autoset allows you to set the strongest local radio stations without losing your original manually set preset stations for AM/FM1/FM2. To activate the autoset feature: Press MENU repeatedly until AUTO PRESET ON/OFF appears in the display. Use SEEK to turn AUTO PRESET to ON, and either wait five seconds for the search to...
Page 34 Entertainment Systems CD/MP3 Player CD: Press to enter CD/MP3 mode. If a disc is already loaded into the system, CD/MP3 play will begin where it ended last. If no CD is loaded, NO DISC will appear in the display. LOAD: For a single CD system–...
Page 35 Entertainment Systems SEEK: Press SEEK access the previous/next track. CAT (Category) / FOLD (Folder): In MP3 mode only– Press CAT/FOLD and then press SEEK to access the previous/next folder. SCAN: Press for a brief sampling of all tracks on the current disc or MP3 folder.
Page 36 Entertainment Systems Satellite Radio (if equipped) Satellite radio is available only with a valid SIRIUS radio subscription. Check with your authorized dealer for availability. SIRIUS: Press repeatedly to access satellite radio mode, if equipped. Press repeatedly to cycle through SAT1, SAT2 and SAT3 modes. TUNE: Turn to go to the next / previous available SIRIUS satellite station.
Page 37 Entertainment Systems MEMORY PRESETS (0–9): There are 30 available presets, 10 each for SAT1, SAT2 and SAT3. To save satellite channels in your memory presets, tune to the desired channel then press and hold a memory preset number (0–9) until sound returns. TEXT: Press and release to display the artist and song title.
Page 38 Entertainment Systems • SONG SEEK MENU- Press OK to enter song seek menu. Press SEEK to scroll through the following options: a. SAVE THIS SONG: Press OK to save the currently playing song’s title in the system’s memory. (If you try to save something other than a song, CANT SAVE will appear in the display.) When the chosen song is playing on any satellite radio channel, the system will alert you with an audible prompt.
Page 39 Entertainment Systems • CHANNEL LOCKOUT MENU- Press OK to enter the Channel Lockout menu. Press the SEEK to scroll through the following options: a. LOCK/UNLOCK THIS CHANNEL: Press OK when LOCK/UNLOCK THIS CHANNEL is displayed and the display will read ENTER PIN.
Page 40: Auxiliary Input Jack (Line In)
Auxiliary input jack (Line in) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 41 Entertainment Systems Your vehicle is equipped with an auxiliary input jack (AIJ). The auxiliary input jack provides a way to connect your portable music player to the in-vehicle audio system. This allows the audio from a LINE IN portable music player to be played through the vehicle speakers with high fidelity.
Page 42: Usb Port
USB port (if equipped) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 43 Entertainment Systems Your vehicle may be equipped with a USB port inside your center console. This feature allows you to plug in media playing devices, memory sticks, and also to charge devices if they support this feature. For further information on this feature, refer to Accessing and using your USB port in the SYNC supplement or Navigation System supplement.
Page 44 CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Do not use any irregular shaped CDs or discs with a scratch protection film attached.
Page 45 Entertainment Systems CDs with homemade paper (adhesive) labels should not be inserted into the CD player as the label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels.
Page 46: Satellite Radio Information
Entertainment Systems Sample MP3 structure If you are burning your own MP3 discs, it is important to understand how the system will read the structures you create. While various .mp3 files may be present, (files with .mp3 extensions other than mp3), only files with the .mp3 extension will be .mp3 played.
Page 47 Note: SIRIUS reserves the unrestricted right to change, rearrange, add or delete programming including canceling, moving or adding particular channels, and its prices, at any time, with or without notice to you. Ford Motor Company shall not be responsible for any such programming changes.
Page 48 Entertainment Systems Radio Display Condition Action Required ACQUIRING Radio requires more No action required. This than two seconds to message should disappear produce audio for shortly. the selected channel. SAT FAULT Internal module or If this message does not system failure clear within a short period present.
Page 49: Navigation System
Entertainment Systems Radio Display Condition Action Required NO TEXT Category Category information not information not available at this time on available. this channel. The system is working properly. NO SIGNAL Loss of signal from You are in a location that the SIRIUS satellite is blocking the SIRIUS or SIRIUS tower to...
Page 50: Climate Controls
Climate Controls MANUAL HEATING AND AIR CONDITIONING SYSTEM (IF EQUIPPED) Temperature conversion: To switch between Fahrenheit and Celsius, refer to Message center in the Instrument Cluster chapter. Defrost: Distributes outside air through the windshield defroster vents and de-mister vents. Can be used to clear the windshield of fog and thin ice.
Page 51 Climate Controls 4. A/C: Press to activate/deactivate air conditioning. Use with recirculated air to improve cooling performance and efficiency. A/C engages automatically in MAX A/C, (defrost) (floor/defrost). Recirculated air: Press to activate/deactivate air recirculation in the vehicle. Recirculated air may reduce the amount of time needed to cool down the interior of the vehicle and may also help reduce undesired odors from reaching the interior of the vehicle.
Page 52 Climate Controls During extreme high ambient temperatures when idling stationary for extended periods of time in gear, it is recommended to run the A/C in the MAX A/C mode, adjust the blower fan speed to the lowest setting and put the vehicle’s transmission into the P (Park) position to continue to receive cool air from your A/C system.
Page 53 Climate Controls DUAL ZONE AUTOMATIC TEMPERATURE CONTROL (IF EQUIPPED) Temperature conversion: To switch between Fahrenheit and Celsius, refer to Message center in the Instrument Cluster chapter. + Fan speed control: Press to increase the fan speed. Defrost: Distributes outside air through the windshield defroster vents and de-mister vents.
Page 54 Climate Controls 4. A/C: Press to activate/deactivate air conditioning. Use with recirculated air to improve cooling performance and efficiency. A/C engages automatically in MAX A/C, (defrost) (floor/defrost). 5. AUTO: Press to engage automatic temperature control. Select the desired temperature using the temperature control. The system will automatically determine fan speed, airflow location, A/C on or off, and outside or recirculated air, to heat or cool the vehicle to reach the desired temperature.
Page 55 Climate Controls Power/Driver temperature: Press to activate/deactivate the climate control system. When the system is off, outside air is prevented from entering the vehicle. Turn to increase/decrease the air temperature on the driver side of the vehicle. The control also adjusts the passenger side temperature when PASS TEMP is disengaged.
Page 56 Climate Controls Temperature conversion: To switch between Fahrenheit and Celsius, refer to Message center in the Instrument Cluster chapter. 1. CLIMATE: Press to control the climate control system through the touch display screen. See Touchscreen functions later in this section. Rear defroster: Press to activate/deactivate the rear window defroster.
Page 57 Climate Controls 10. Driver temperature: Press to increase/decrease the air temperature for the driver side of the vehicle. This control also adjusts the passenger side temperature when dual zone operation is disengaged. Driver cooled seat (if equipped): Press to control the driver cooled seat.
Page 58 Climate Controls • : Distributes air through the floor vents, rear seat floor vents. • : Distributes air through the windshield defroster vents, de-mister vents, floor vents and rear seat floor vents. The system will automatically provide outside air to reduce window fogging. To return to full automatic control, press AUTO on the main bezel.
Page 59: Rear Window Defroster
Climate Controls For maximum cooling performance: • Automatic operation: 1. Press AUTO for full automatic operation. 2. Do not override A/C or (recirculated air). 3. Set the temperature to 60°F (16°C). • Manual operation: 1. Select MAX A/C. 2. Select (panel) or (panel/floor).
Page 60 Climate Controls CABIN AIR FILTER The cabin air filter element is designed to reduce the concentration of airborne particles such as dust, spores and pollen in the air being supplied to the interior of the vehicle. The presence of a particulate filter element provides the following benefits: •...
Page 61: Lights
Lights HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps. Turns the low beam headlamps Autolamp control (if equipped) The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control.
Page 62 Lights 4. Turn the headlamp control to the autolamp position. The headlamps will turn on. 5. Wait the desired amount of time for the exit delay you want (up to three minutes), then turn the headlamps off. High beams Push the lever toward the instrument panel to activate.
Page 63 Lights Scenario 3: Conditions - The automatic high beam system is set to ON in the message center. The headlamp switch is in (off), (park lamps), (on). Operation - The high beam switch can be used to turn the high beams on and off.
Page 64 Lights • The camera is blocked. Note: Activating the multi-function lever will put the headlamps in manual high beam mode (constant or flash-to-pass) until the lever is returned to the neutral position. To manually override the auto high beam and go to low beam, the headlamp control must be taken out of (autolamp) position.
Page 65 Lights For significant blockages (e.g. bird dropping, bug splatter, snow, or ice), the automatic high beam system uses a blocked sensor computer program. If a blockage is detected and no changes are observed, the system will go into low beam mode until the blockage is cleared. If blockages are repeatedly detected, the system will stay in low beam mode for the remainder of the ignition cycle unless the system is able to begin detecting other vehicles again.
Page 66 Lights PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel and all applicable lit components in the vehicle during headlamp and parking lamp operation. • Tap the top or bottom of the control to brighten/dim all interior lit components incrementally, or •...
Page 67 Lights 3. Turn on the low beam headlamps to illuminate the wall or screen and open the hood. To see a clearer light pattern for adjusting, you may want to block the light from one headlamp while adjusting the other. For vehicles with halogen headlamps: On the wall or screen you will observe a flat zone of high intensity...
Page 68: Turn Signal Control
Lights TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. INTERIOR LAMPS Dome lamps and map lamps The map lamps are located on the overhead console. Press the controls on either side of each map lamp to turn on the lamps.
Page 69: Bulb Replacement
Lights Ambient lighting (if equipped) Illuminates footwells and cupholders with a choice of several colors. The ambient lighting control is located in the center console storage area. To activate, press and release the left side of the control to cycle through the color choices plus the off state.
Page 70 Lights Using the right bulbs Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.” for North America and an “E” for Europe to ensure lamp performance, light brightness and pattern and safe visibility. The correct bulbs will not damage the lamp assembly or void the lamp assembly warranty and will provide quality bulb burn time.
Page 71 Lights Replacing headlamp (low/high beam) bulbs 1. Make sure the headlamp switch is in the off position, then open the hood. 2. Reach in behind the headlamp assembly to access the bulbs and connectors. 3. Remove the outboard rubber boot from the lamp assembly by pulling rearward.
Page 72 Lights 3. Remove the bulb socket by turning it counterclockwise and pulling it straight out. 4. To remove the bulb, pull it straight out of the bulb socket. Install the new bulb(s) in reverse order. Replacing rear brake/tail/turn and side marker lamp bulbs The brake/tail/turn and side marker lamp bulbs are located in the tail lamp assembly.
Page 73 Lights 4. Remove the bulb socket by rotating it counterclockwise, then pulling it out of the lamp assembly. 5. Pull the bulb straight from the socket. Install new bulb(s) in reverse order. Replacing backup lamp bulbs The backup lamp bulbs are located in the deck lid assembly. 1.
Page 74 Lights Replacing high-mount brake lamp bulbs Your vehicle is equipped with an LED high-mount brake lamp. It is designed to last the life of the vehicle. If replacement is required, it is recommended that you see your authorized dealer. Replacing license plate lamp bulbs 1.
Page 75: Driver Controls
Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Rain sensing wipers (if equipped): The rain sensing wipers will automatically activate when moisture is present on the windshield and the multi-function...
Page 76 Driver Controls Windshield washer: Push the end of the stalk: • briefly: causes a single swipe of the wipers without washer fluid. • a quick push and hold: the wipers will swipe three times with washer fluid. • a long push and hold: the wipers and washer fluid will be activated for up to ten seconds.
Page 77 Driver Controls TILT/TELESCOPE STEERING WHEEL To adjust the steering wheel: 1. Pull the lever down to unlock the steering column. 2. While the lever is in the down position, move the steering wheel up or down and in or out until you find the desired position.
Page 78 Driver Controls OVERHEAD CONSOLE The appearance of your vehicle’s overhead console will vary according to your option package. Storage compartment The storage compartment may be used to store a pair of sunglasses. Press the release area on the rear edge of the bin door to open the storage compartment.
Page 79 Driver Controls Compass zone adjustment 1. Determine which magnetic zone you are in for your geographic location by referring to the zone map. 2. Turn ignition to the on position. 7 8 9 1011 3. Press and hold the 7 and 9 radio preset buttons together for approximately five seconds until ZONE XX appears in the CID.
Page 80 Driver Controls 2. To calibrate, press and hold the 7 and 9 radio preset buttons together for approximately 10 seconds until CAL appears. Release the buttons. 3. Slowly drive the vehicle in a circle (less than 3 mph [5 km/h]) until the CAL display changes to the direction value (N, S, E, W, etc.).
Page 81 Driver Controls Some consoles will have panel doors covering the cupholders and switches. Press the doors to open them. Some cupholders will be equipped with a divider. Pull up on the divider and move it in the slots right or left for the best fit with the cup you are using.
Page 82: Power Windows
Driver Controls • do not leave battery chargers, video game adapters, computers and other devices plugged in overnight or when the vehicle is parked for extended periods. Always keep the power point caps closed when not being used. POWER WINDOWS WARNING: Do not leave children unattended in the vehicle and do not let children play with the power windows.
Page 83 Driver Controls Driver’s window one-touch up or down Driver’s and passenger’s window one-touch up or down (if equipped) To operate one touch-down: • Press the switch completely down to the second detent and release quickly. The window will open fully. Momentarily press the switch to any position to stop the window operation.
Page 84 Driver Controls Bounce-Back (one-touch up or down windows only) When an obstacle has been detected in the window opening as the window is moving upward, the window will automatically reverse direction and move down. This is known as “bounce-back”. If the ignition is turned off (without accessory delay being active) during bounce-back, the window will move down until the bounce-back position is reached.
Page 85: Mirrors
Driver Controls POWER REAR SUNSHADE (IF EQUIPPED) Your vehicle may be equipped with a power rear sunshade that covers the rear window of your vehicle. The control is located in the center console access bin next to the power point. Press the control to move the shade up or down.
Page 86 Driver Controls Do not clean the housing or glass of any mirror with harsh abrasives, fuel or other petroleum-based cleaning products. Note: If equipped with a rear view camera system, a video image will be displayed in the mirror or the navigation system display (if equipped) when the vehicle is put in R (Reverse).
Page 87: Speed Control
Driver Controls Fold-away mirrors Pull the side mirrors in carefully when driving through a narrow space, like an automatic car wash. POWER ADJUSTABLE FOOT PEDALS (IF EQUIPPED) The accelerator and brake pedal should only be adjusted when the vehicle is stopped and the gearshift lever is in the P (Park) position.
Page 88 Driver Controls Using speed control The speed controls are located on the steering wheel. The following buttons work with speed control: RESUME: Press to resume a set speed. SET +: Press to increase the set speed. SET – : Press to decrease the set speed.
Page 89: Adaptive Cruise Control
Driver Controls Increasing speed while using speed control To set a higher speed: • Press and hold SET + until you get to the desired speed, then release. You can also use SET + to operate the tap-up function. Press and release SET + to increase the vehicle set speed in 1 mph (1.6 km/h) increments.
Page 90 Driver Controls WARNING: Always pay close attention to changing road conditions, especially when using Adaptive Cruise Control. Adaptive Cruise Control cannot replace attentive driving. Failing to follow any of the warnings below or failing to pay attention to the road may result in a collision, serious injury or death.
Page 91 Driver Controls 3. Press and release the SET + control. The vehicle speed will be stored in the memory and the message center will display SET XXX MPH (your desired speed). 4. Take your foot off the accelerator pedal. 5. The green cruise indicator light on the instrument cluster will illuminate if there are no vehicles...
Page 92 Driver Controls The vehicle brakes will be automatically applied to slow the vehicle to maintain a safe distance between the vehicle in front. The maximum braking which is applied by the ACC system is limited and can be overridden by the driver applying the brakes. If the ACC system predicts that its maximum braking level will not be sufficient, an audible warning will...
Page 93 Driver Controls Each time the vehicle is restarted, the last chosen gap will be automatically selected. Note: It is the driver’s responsibility to select a gap appropriate to the driving conditions. Disengaging adaptive cruise control Press the brake pedal to disengage the adaptive cruise control. CRUISE CANCELLED will be displayed in the message center.
Page 94 Driver Controls Resuming the set speed Press and release the RESUME control. This will automatically return the vehicle to the previously set speed. The set speed will display continuously in the message center while ACC is active. Note: RESUME should only be used if the driver is aware of the set speed and intends to return to it.
Page 95 Driver Controls Turning off cruise control Press the OFF button to turn off the cruise control. Note: When you turn off the cruise control or the ignition, your cruise control set speed memory is erased. Detection issues The radar sensor has a limited field of vision. In some situations it may not detect vehicles at all or detect a vehicle later than expected.
Page 96 Driver Controls • There may be issues with the detection of vehicles in front when driving into and coming out of a bend or curve in the road. In these cases ACC may brake late or unexpectedly. The driver should stay alert and intervene when necessary.
Page 97 Driver Controls Cause Action The surface of the radar in the Clean the grille surface in front of grille is dirty or obstructed in the radar or remove the object some way causing the obstruction The surface of the radar in the Wait a short time.
Page 98 Driver Controls STEERING WHEEL CONTROLS (IF EQUIPPED) Radio control features VOL + (Volume): Press to increase the volume. VOL – (Volume): Press to decrease the volume. (Seek): Press to select the previous/next radio station preset, CD track or satellite radio channel preset depending on which media mode you are in.
Page 99: Moon Roof
Driver Controls SYNC system hands-free control feature (if equipped) Press briefly to use the voice command feature. You will hear a tone and LISTENING will appear in the radio display. Press and hold to exit voice command. Press to activate phone mode or answer a phone call.
Page 100 Driver Controls To open the moon roof: Press and release the SLIDE control, the moon roof will open automatically. Press the switch again to stop the moon roof. WARNING: When closing the moon roof, you should verify that it is free of obstructions and ensure that children and/or pets are not in the proximity of the moon roof opening.
Page 101 Driver Controls HomeLink Car2U Home Automation System HomeLink Wireless Control System (if equipped) The HomeLink Wireless Control System, located on the driver’s visor, provides a convenient way to replace up to three hand-held transmitters with a single built-in device. This feature will learn the radio frequency codes of most transmitters to operate garage doors, entry gate operators, security systems, entry door locks, and...
Page 102 Driver Controls Retain the original transmitter for use in other vehicles as well as for future programming procedures (i.e. new HomeLink equipped vehicle purchase). It is also suggested that upon the sale of the vehicle, the programmed Homelink buttons be erased for security purposes, refer to Programming in this section.
Page 103 Driver Controls 5. Firmly press and release the “learn” or “smart” button. (The name and color of the button may vary by manufacturer.) Note: There are 30 seconds in which to initiate Step 6. 6. Return to the vehicle and firmly press, hold for two seconds and release the programmed HomeLink button.
Page 104 Driver Controls Operating the HomeLink Wireless Control System To operate, simply press and release the appropriate HomeLink button. Activation will now occur for the trained product (garage door, gate operator, security system, entry door lock, or home or office lighting etc.).
Page 105 Driver Controls Car2U Home Automation System (if equipped) The Car2U Home Automation System is a universal transmitter located in the driver’s visor that includes two primary features – a garage door opener and a platform for remote activation of devices within the home.
Page 106 Driver Controls • Fixed code garage door openers were produced prior to 1996. Fixed code uses the same coded signal every time. It is manually programmed by setting DIP switches for a unique personal code. If you do not know if your garage door opener is a rolling code or fixed code device, open your garage door opener’s remote control battery...
Page 107 Driver Controls 2. Go to the garage to locate the garage door opener motor and its “learn” button. You may need a ladder to reach the unit and you may need to remove the unit’s cover or light lens to locate the “learn” button.
Page 108 Driver Controls Note: The Car2U system allows for three devices to be programmed. If you need to change or replace any of the three devices after it has been initially programmed, it is necessary to erase the current settings using the Erasing the Car2U Home Automation System buttons procedure and then programming all of the devices being used.
Page 109 Driver Controls 3. To input these positions into the Car2U system, simultaneously press all three Car2U system buttons for a few seconds and then release to put the device into programming mode. The indicator lights will blink slowly. Within 2.5 minutes enter your corresponding DIP switch settings from left to right into your Car2U system by pressing and releasing the buttons corresponding to the settings you circled.
Page 110 Driver Controls To erase programming on the Car2U system (individual buttons cannot be erased), use the following procedure: 1. Firmly press the two outside Car2U system buttons simultaneously for approximately 20 seconds until the indicator lights begin to blink rapidly. The indicator lights are located directly above the buttons.
Page 111 Driver Controls INTERIOR TRUNK CONTROL The trunk release button is located on the instrument panel near the radio. Press the button to open the trunk. CARGO AREA FEATURES Cargo net (if equipped) The cargo net secures lightweight objects in the cargo area. Attach the net to the anchors provided.
Page 112: Locks And Security
Locks and Security KEYS Integrated keyhead transmitters (IKTs) (If equipped) Your vehicle may be equipped with two integrated keyhead transmitters (IKTs). The key blade starts the vehicle and unlocks/locks all the doors. The transmitter portion functions as the remote entry transmitter.
Page 113 Locks and Security Intelligent Access Key (IA key) (if equipped) Your vehicle may be equipped with two intelligent access keys which operate the power locks and the remote entry system. You have to have the IA key in the vehicle to activate the push button start system.
Page 114 Locks and Security MYKEY™ The MyKey™ feature allows you to program a restricted driving mode to promote good driving habits. All but one of the keys programmed to the vehicle can be activated as a MyKey™. The key will remain restricted until MyKey™...
Page 115 Locks and Security Create a MyKey™ To program MyKey™ on one of the keys programmed to the vehicle, insert the key that you want to make a MyKey™ into the ignition. For vehicles equipped with push button start, put the intelligent access key in the backup slot;...
Page 116 Using MyKey™ with remote start systems MyKey™ is not compatible with non-Ford approved aftermarket remote start systems. If you choose to install a remote start system please see your authorized dealer for a Ford approved remote start system. 2010 Taurus (500) Owners Guide, 3rd Printing...
Page 117 Locks and Security Vehicles equipped with traditional keys: When using a Ford-approved remote start system, the default settings will recognize the remote start system as an additional admin key with its associated privileges. Owners of vehicles equipped with traditional keys should program the remote start system as a MyKey™ in addition to the key that they have already programmed as a MyKey™.
Page 118 Locks and Security Troubleshooting Condition Potential Causes • Key in the ignition is already a Can’t create a MyKey™ MyKey™. • Key in the ignition is the last remaining admin key (there always has to be at least one admin key). •...
Page 119 Locks and Security Condition Potential Causes • For programming spare keys, refer to Lost any key the Programming spare keys section in this chapter. • Vehicle has a remote start system that I accidentally programmed all keys as MyKeys™ is recognized as an admin key. Refer to the Using MyKey™...
Page 120: Locks
Locks and Security POWER DOOR LOCKS • Press the control to unlock all doors. • Press the control to lock all doors. Smart unlocks This feature helps to prevent you from locking yourself out of the vehicle if your key is still in the ignition. When you open one of the front doors and you lock the vehicle with the power door lock control (on the driver or passenger door trim panel), all the doors will lock, then all doors will automatically unlock reminding...
Page 121 Locks and Security automatically be released when you attempt to close it, and the horn will chirp, as a reminder that the IA key is inside. If you would like to intentionally lock your IA key in the trunk of your vehicle, first disarm the perimeter alarm by unlocking the vehicle, then place the IA key in the trunk, close the trunk, and rearm your perimeter alarm system by locking the vehicle using your keyless entry keypad or another IA key.
Page 122 Locks and Security Note: The autolock feature can be activated/deactivated independently of the autounlock feature. Power door lock switch autolock enable/disable procedure Before starting, ensure the ignition is off and all vehicle doors are closed. You must complete Steps 1–5 within 30 seconds or the procedure will have to be repeated.
Page 123 Locks and Security Keyless entry keypad autolock enable/disable procedure 1. Turn the ignition off. 2. Close all the doors. 3. Enter factory–set 5–digit entry code. 4. Press and hold the 3 • 4. While holding the 3 • 4 press the 7 • 8. 5.
Page 124 Locks and Security Note: The autounlock feature can be activated/deactivated independently of the autolock feature. Power door lock switch autounlock enable/disable procedure Before starting, ensure the ignition is off and all vehicle doors are closed. You must complete Steps 1–5 within 30 seconds or the procedure will have to be repeated.
Page 125 Locks and Security Keyless entry keypad autounlock enable/disable procedure 1. Turn the ignition off. 2. Close all the doors. 3. Enter factory–set 5–digit entry code. 4. Press and hold the 3 • 4. While holding the 3 • 4, press and release the 7 •...
Page 126 Locks and Security INTERIOR LUGGAGE COMPARTMENT RELEASE Your vehicle is equipped with a mechanical interior luggage compartment release handle that provides a means of escape for children and adults in the event they become locked inside the luggage compartment. Adults are advised to familiarize themselves with the operation and location of the release handle.
Page 127 Locks and Security WARNING: Do not leave children, unreliable adults, or animals unattended in the vehicle. On hot days, the temperature in the trunk or vehicle interior can rise very quickly. Exposure of people or animals to these high temperatures for even a short time can cause death or serious heat-related injuries, including brain damage.
Page 128 Locks and Security Intelligent access key Refer to Intelligent Access in this section for more features. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The typical operating range for your transmitter is approximately 33 feet (10 meters).
Page 129 Locks and Security Intelligent access (if equipped) WARNING: Radio waves from the intelligent access system transmitters in the vehicle may affect certain implanted medical devices such as pacemakers or cardiac defibrillators. People having such implanted medical devices should ask the medical device manufacturer or their physician whether the intelligent access system may affect the equipment before coming into close proximity with a vehicle equipped with intelligent access.
Page 130 Locks and Security Push button start: Your vehicle is equipped with a push button start system, which allows you to start your vehicle without using a key. To operate the push button start system and start your vehicle, your IA key must be present inside the vehicle, either in the passenger compartment or in the trunk.
Page 131 Locks and Security Car finder Press twice within three seconds. The horn will chirp and the turn lamps will flash. It is recommended that this method be used to locate your vehicle, rather than using the panic alarm. Sounding a panic alarm Press to activate the alarm.
Page 132 Locks and Security • 10–way power seats • 8–way power seats 2. Press and hold control button 1 for five seconds. A tone will be heard after two seconds confirming memory position has been set. Continue to hold until a second tone is heard after five seconds. 3.
Page 133 Locks and Security Replacing the battery The integrated keyhead transmitter (IKT) or intelligent access key (IA key) uses one coin type three-volt lithium battery CR2032 or equivalent. To replace the battery: Integrated keyhead transmitter (IKT) 1. Twist a thin coin in the slot near the key ring to remove the battery cover.
Page 134 Locks and Security 2. Remove the old battery. Note: Please refer to local regulations when disposing of transmitter batteries. 3. Insert the new battery. Refer to the instructions inside the IA key for the correct orientation of the battery. Press the battery down to ensure that the battery is fully seated in the battery housing cavity.
Page 135 Locks and Security • after 25 seconds of illumination. The lights will not turn off if: • they have been turned on with the dimmer control, or • any door is open. Illuminated exit • When all vehicle doors are closed, the ignition is turned off and the key is removed from the ignition (IKT only), the interior dome lamps, parking lamps and the puddle lamps (if equipped) will illuminate.
Page 136 Locks and Security SECURICODE™ KEYLESS ENTRY SYSTEM The keypad, located near the driver’s window, is invisible until touched and then it lights up so you can see and touch the appropriate buttons. Note: If you enter your entry code too fast on the keypad, the unlock function may not work.
Page 137 Locks and Security 4. For memory recall feature, enter the sixth digit 1 • 2 to store driver 1 settings or 3 • 4 to store driver 2 settings. Note: Touching 5 • 6, 7 • 8, or 9 • 0 keypad numbers as a sixth digit will not recall a driver memory setting.
Page 138: Anti-Theft System
Note: The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Large metallic objects, electronic devices that are used to purchase gasoline or similar items, or a second coded key on the same key chain may cause vehicle starting issues.
Page 139 Locks and Security engine. If a problem occurs, turn the ignition off, remove all objects on the key chain away from the coded key and restart the engine. Note: Do not leave a duplicate coded key in the vehicle. Always take your keys and lock all doors when leaving the vehicle.
Page 140 Locks and Security Replacement integrated keyhead transmitters (IKT) or intelligent access keys Note: Your vehicle comes equipped with two integrated keyhead transmitters (IKTs) or two intelligent access keys. The integrated keyhead transmitter (IKT) functions as both a programmed ignition key that operates all the locks and starts the vehicle, as well as a remote keyless entry transmitter.
Page 141 Locks and Security Please read and understand the entire procedure before you begin. 1. Insert the first previously programmed coded key into the ignition. 2. Turn the ignition from off to on. Keep the ignition on for at least three seconds, but no more than 10 seconds.
Page 142 Locks and Security Note: A maximum of four intelligent access keys can be programmed to your vehicle. If you would like to replace a previously programmed access key with a new access key, or if you already have four access keys programmed to your vehicle, you must take your vehicle and all access keys to your authorized dealer to be erased and reprogrammed.
Page 143 Locks and Security PERIMETER ALARM SYSTEM (IF EQUIPPED) The perimeter anti-theft system will help protect your vehicle from unauthorized entry. If there is any potential perimeter anti-theft problem with your vehicle, ensure ALL integrated keyhead transmitters or intelligent access keys are brought to the authorized dealer to aid in troubleshooting. Arming the system When armed, this system will respond if unauthorized entry is attempted.
Page 144 Locks and Security • Press and hold the 7 • 8 and 9 • 0 controls on the keyless entry pad at the same time to lock the doors (driver’s door must be closed). There is a 20 second countdown when any of the above actions occur before the vehicle becomes armed.
Page 145: Seating And Safety Restraints
Seating and Safety Restraints SEATING WARNING: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. WARNING: Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
Page 146 Seating and Safety Restraints To adjust the head restraint, do the following: 1. Adjust the seatback to an upright driving/riding position. 2. Raise the head restraint by pulling up on the head restraint. 3. Lower the head restraint by pressing and holding the guide sleeve adjust/release button and pushing down on the head restraint.
Page 147 Seating and Safety Restraints To remove the adjustable head restraint, do the following: 1. Pull up the head restraint until it reaches the highest adjustment position. 2. Simultaneously press and hold both the adjust/release button and the unlock/remove button, then pull up on the head restraint.
Page 148 Seating and Safety Restraints WARNING: To minimize the risk of neck injury in the event of a crash, head restraints must be installed properly. Using the manual lumbar support (if equipped) The lumbar support control is located on the outboard side shield. Rotate the knob clockwise or counter clockwise to adjust lumbar support.
Page 149 Seating and Safety Restraints WARNING: Before returning the seatback to its original position, make sure that cargo or any objects are not trapped behind the seatback. After returning the seatback to its original position, pull on the seatback to ensure that it has fully latched. An unlatched seat may become dangerous in the event of a sudden stop or collision.
Page 150 Seating and Safety Restraints Press either up or down on the lumbar control to select the top, middle, or bottom part of the seat back. Push and hold the front of the lumbar control to increase the firmness of the selected portion of the seatback or push and hold the rear of the lumbar to decrease the firmness.
Page 151 Seating and Safety Restraints WARNING: Sitting improperly out of position or with the seat back reclined too far can take off weight from the seat cushion and affect the decision of the passenger sensing system, resulting in serious injury or death in a crash. Always sit upright against your seatback, with your feet on the floor.
Page 152 Seating and Safety Restraints Press the control to recline the seatback forward or rearward. Note: On vehicles with memory seats, to prevent damage to the seat, the power seats are designed to set a stopping position just short of the end of the seat track.
Page 153 Seating and Safety Restraints WARNING: Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion, or other physical conditions, must exercise care when using the seat heater. The seat heater may cause burns even at low temperatures, especially if used for long periods of time.
Page 154 Seating and Safety Restraints Note: Do not do the following: • Place heavy objects on the seat • Operate the seat heater if water or any other liquid is spilled on the seat. Allow the seat to dry thoroughly. To operate the heated seats: Press once to activate the high heat setting (three indicator lights).
Page 155 Seating and Safety Restraints • There is a filter located under each front seat. • The filter can be accessed from the rear of the seat. Move the front seat to full up to ease access. To remove an air filter: 1.
Page 156 Seating and Safety Restraints To install a filter: 1. First, position the filter in it’s housing making sure that the far forward end is all the way up in the housing. 2. Push in on the center of the outside edge of the filter and rotate up into the housing until it clips into position.
Page 157 Seating and Safety Restraints A programmed memory position can be recalled: • in any gearshift position if the ignition is not on. • only in P (Park) or N (Neutral) if the ignition is on. The memory positions are also recalled when you press your remote entry transmitter (unlock) control (if the transmitter is programmed to a memory position) or, when you enter a valid personal entry code...
Page 158 Seating and Safety Restraints The non-adjustable head restraints consist of : • a trimmed energy absorbing foam and structure (1), • two steel stems (2), • and two guide sleeve unlock/remove buttons (3). To remove the non-adjustable head restraint, do the following: 1.
Page 159 Seating and Safety Restraints WARNING: To minimize the risk of neck injury in the event of a crash, head restraints must be installed properly. Adjustable second row center head restraint Your vehicle is equipped with a head restraint in the second row center seating position that is vertically adjustable.
Page 160 Seating and Safety Restraints 2. Lower the head restraint by pressing and holding the guide sleeve adjust/release button and pushing down on the head restraint. Properly adjust the head restraint so that the top of the head restraint is even with the top of your head and positioned as close as possible to the back of your head.
Page 161 Seating and Safety Restraints 2. Simultaneously press and hold both the adjust/release button and the unlock/remove button, then pull up on the head restraint. To reinstall the adjustable head restraint, do the following: 1. Insert the two stems into the guide sleeve collars.
Page 162 Seating and Safety Restraints To lower the seatback(s) from inside the vehicle, pull the strap located on the outboard side of the seatback to release it, and then fold seatback down. When raising the seatback(s), make sure you hear the seat latch into place.
Page 163 Seating and Safety Restraints Rear heated seats (if equipped) WARNING: Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion, or other physical conditions, must exercise care when using the seat heater. The seat heater may cause burns even at low temperatures, especially if used for long periods of time.
Page 164: Safety Restraints
Seating and Safety Restraints The indicator light will illuminate when the heated seats have been activated. SAFETY RESTRAINTS Personal Safety System™ The Personal Safety System™ provides an improved overall level of frontal crash protection to front seat occupants and is designed to help further reduce the risk of airbag-related injuries.
Page 165 Seating and Safety Restraints appropriate to activate these safety devices. Front airbags are designed to activate only in frontal and near-frontal collisions (not rollovers, side impacts or rear impacts) unless the collision causes sufficient longitudinal deceleration. The pretensioners are designed to activate in frontal and near-frontal collisions, and in side collisions and rollovers.
Page 166 Seating and Safety Restraints WARNING: Always transport children 12 years old and under in the back seat and always properly use appropriate child restraints. The front passenger sensing system can automatically turn off the passenger front airbag. The system is designed to help protect small (child size) occupants from airbag deployments when they are improperly seated or restrained in the front passenger seat contrary to proper child-seating or restraint usage recommendations.
Page 167 Seating and Safety Restraints The Restraints Control Module (RCM) monitors its own internal circuits and the circuits for the airbag supplemental restraints, crash sensor(s), safety belt pretensioners, front safety belt buckle sensors, driver seat position sensor, and front passenger sensing system. In addition, the RCM also monitors the restraints warning light in the instrument cluster.
Page 168 Seating and Safety Restraints WARNING: In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt. WARNING: Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair.
Page 169 Seating and Safety Restraints 2. To unfasten, press the release button and remove the tongue from the buckle. Energy management feature — front outboard • This vehicle has a safety belt system with an energy management feature at the front seats to help further reduce the risk of injury in the event of a head-on collision.
Page 170 Seating and Safety Restraints When to use the automatic locking mode This mode should be used any time a child safety seat (except a booster) is installed in a passenger front or rear seating position with a combination lap/shoulder safety belt. Children 12 years old and under should be properly restrained in a rear seating position whenever possible.
Page 171 Seating and Safety Restraints How to disengage the automatic locking mode WARNING: Ford Motor Company recommends that all passenger safety belt assemblies and attaching hardware should be inspected by an authorized dealer after any collision to verify that the automatic locking retractor feature for child seats is still working properly.
Page 172 Seating and Safety Restraints WARNING: The driver and front passenger safety belt system (including retractors, buckles and height adjusters) must be replaced if the vehicle is involved in a collision that results in deployment of front airbags, seat-mounted side airbags and Safety Canopy , and safety belt pretensioners.
Page 173 Seating and Safety Restraints Belt-Minder The Belt-Minder feature is a supplemental warning to the safety belt warning function. This feature provides additional reminders by intermittently sounding a chime and illuminating the safety belt warning light in the instrument cluster when the driver’s and front passenger’s safety belt is unbuckled.
Page 174 Seating and Safety Restraints If... Then... The driver’s or front The Belt-Minder feature is activated passenger’s safety belt becomes - the safety belt warning light unbuckled for approximately illuminates and the warning chime 1 minute while the vehicle is sounds for six seconds every traveling at least 3 mph 30 seconds, repeating for (5 km/h) and more than...
Page 175 Seating and Safety Restraints Reasons given... Consider... “Traffic is light” Nearly 1 of 2 deaths occur in single-vehicle crashes, many when no other vehicles are around. “Belts wrinkle my clothes” Possibly, but a serious crash can do much more than wrinkle your clothes, particularly if you are unbelted.
Page 176 Seating and Safety Restraints Note: If you are using MyKey™, the Belt-Minder cannot be disabled. Also, if the Belt-Minder has been previously disabled, it will be re-enabled during the use of MyKey™. Refer to MyKey™ in the Locks and Security chapter. The driver and front passenger Belt-Minder features can be deactivated/activated by performing the following procedure: Before following the procedure, make sure that:...
Page 177: Airbags
Seating and Safety Restraints • This will enable the Belt-Minder feature for that seating position if it is currently disabled. As confirmation, the safety belt warning light will flash four times per second for three seconds, followed by three seconds with the light off, then followed by the safety belt warning light flashing four times per second for three seconds again.
Page 178 Seating and Safety Restraints Important supplemental restraint system precautions Airbags DO NOT inflate slowly or gently and the risk of injury from a deploying airbag is greatest close to the trim covering the airbag module. WARNING: All occupants of the vehicle, including the driver, should always properly wear their safety belts, even when an air bag supplemental restraint system (SRS) is provided.
Page 179 Seating and Safety Restraints WARNING: Do not put anything on or over the airbag module. Placing objects on or over the airbag inflation area may cause those objects to be propelled by the airbag into your face and torso causing serious injury. WARNING: Do not attempt to service, repair, or modify the airbag supplemental restraint system (SRS) or its fuses.
Page 180 Seating and Safety Restraints How does the airbag supplemental restraint system work? The airbag SRS is designed to activate when the vehicle sustains longitudinal deceleration sufficient to cause the sensors to close an electrical circuit that initiates airbag inflation. The fact that the airbags did not inflate in a collision does not mean that something is wrong with the system.
Page 181 Seating and Safety Restraints WARNING: If the air bag has deployed, the air bag will not function again and must be replaced immediately. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision. The SRS consists of: •...
Page 182 Seating and Safety Restraints • the system determines that an infant is present in a rear-facing infant seat that is installed according to the manufacturer’s instructions, • the system determines that a small child is present in a forward-facing child restraint that is installed according to the manufacturer’s instructions, •...
Page 183 Seating and Safety Restraints • When the front passenger sensing system enables the front passenger frontal airbag (may inflate), the indicator will be unlit and stay unlit. If a person of adult size is sitting in the front passenger’s seat, but the passenger airbag off or pass airbag off indicator lamp is lit, it is possible that the person isn’t sitting properly in the seat.
Page 184 Seating and Safety Restraints WARNING: Sitting improperly out of position or with the seat back reclined too far can take off weight from the seat cushion and affect the decision of the front passenger sensing system, resulting in serious injury or death in a crash. Always sit upright against your seatback, with your feet on the floor.
Page 185 If it is necessary to modify an advanced front airbag system to accommodate a person with disabilities, contact the Ford Customer Relationship Center at the phone number shown in the Customer Assistance chapter of this Owner’s Guide.
Page 186 Seating and Safety Restraints WARNING: Any alteration/modification to the front passenger seat may affect the performance of the front passenger sensing system. Determining if the system is operational The supplemental restraint system uses a warning indicator light in the instrument cluster or a back-up tone to indicate the condition of the system.
Page 187 Seating and Safety Restraints WARNING: Do not attempt to service, repair, or modify the airbag SRS, its fuses or the seat cover on a seat containing an airbag. Contact your authorized dealer as soon as possible. WARNING: All occupants of the vehicle should always wear their safety belts even when an airbag SRS is provided.
Page 188 Seating and Safety Restraints The fact that the airbags did not inflate in a collision does not mean that something is wrong with the system. Rather, it means the forces were not of the type sufficient to cause activation. Side airbags are designed to inflate in side-impact collisions, not roll-over, rear-impact, frontal or near-frontal collisions, unless the collision causes sufficient lateral deceleration.
Page 189 Seating and Safety Restraints WARNING: Do not attempt to service, repair, or modify the Safety Canopy system, its fuses, the A, B, or C pillar trim, or the headliner on a vehicle containing a Safety Canopy . See your authorized dealer. WARNING: All occupants of the vehicle including the driver should always wear their safety belts even when an airbag SRS and Safety Canopy system is provided.
Page 190 Seating and Safety Restraints • Two crash sensors mounted on the B pillar (one on each side of the vehicle). • Two crash sensors located at the C pillar behind the rear doors (one on each side of the vehicle). •...
Page 191 Seating and Safety Restraints WARNING: If the Safety Canopy system has deployed, the Safety Canopy will not function again unless replaced. The Safety Canopy system (including the A, B, C, and D pillar trim and headliner) must be inspected and serviced by an authorized dealer.
Page 192: Child Restraints
Recommendations for Safety Restraints are based on probable child height, age and weight thresholds from NHTSA and other safety organizations or are the minimum requirements of law. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and consult your pediatrician to make sure your child seat is appropriate for your child, and is compatible with and properly installed in the vehicle.
Page 193 Seating and Safety Restraints Recommendations for Safety Restraints for Children Recommended Child size, height, weight, or age restraint type Infants or Children weighing 40 lb (18 kg) or less Use a child safety toddlers (generally age four or younger) seat (sometimes called an infant carrier, convertible seat,...
Page 194 Seating and Safety Restraints Recommendations for attaching child safety restraints for children Use any attachment method as indicated below by “X” LATCH LATCH Safety Safety Safety (lower (lower belt belt and belt Restraint Child anchors anchors LATCH only Type Weight only) (lower tether...
Page 195 Seating and Safety Restraints WARNING: Always carefully follow the instructions and warnings provided by the manufacturer of any child restraint to determine if the restraint device is appropriate for your child’s size, height, weight, or age. Follow the child restraint manufacturer’s instructions and warnings provided for installation and use in conjunction with the instructions and warnings provided by the vehicle manufacturer.
Page 196 Highway Traffic Safety Administration (NHTSA) provides education and training to ensure that all children ages 0 to 16 are properly restrained in the correct restraint system. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and your pediatrician to make sure your seat is appropriate for your child and properly installed in the vehicle.
Page 197 Seating and Safety Restraints SAFETY SEATS FOR CHILDREN Infant and/or toddler seats Use a safety seat that is recommended for the size and weight of the child. When installing a child safety seat: • Review and follow the information presented in the Airbag supplemental restraint system (SRS) section in this chapter.
Page 198 Seating and Safety Restraints • Place vehicle seat back in upright position. • Put the safety belt in the automatic locking mode. Refer to Step 5 below. This vehicle does not require the use of a locking clip. WARNING: Depending on where you secure a child restraint, and depending on the child restraint design, you may block access to certain safety belt buckle assemblies and/or LATCH lower anchors, rendering those features potentially unusable.
Page 199 Seating and Safety Restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
Page 200 1 inch (2.5 cm) of movement for proper installation. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) to make certain the child restraint is properly installed. In Canada, check with your local St. John Ambulance office for referral to a CPST.
Page 201 Ford Motor Company recommends the use of a child safety seat having a top tether strap. See Attaching child safety seats with tether straps and Recommendations for attaching safety restraints for children in this chapter for more information.
Page 202 Seating and Safety Restraints All the LATCH lower anchors are equally spaced, 280 mm (11 inches) apart, so that a single LATCH child seat can be installed at any rear seating position. If two child safety seats are installed using the LATCH lower anchors, they must be placed in the outboard seating positions only.
Page 203 Seating and Safety Restraints Combining safety belt and LATCH lower anchors for attaching child safety seats When used in combination, either the safety belt or the LATCH lower anchors may be attached first, provided a proper installation is achieved. Attach the tether strap afterward, if included with the child seat. Refer to Recommendations for attaching child safety restraints for children in this chapter.
Page 204 If the safety seat is not anchored properly, the risk of a child being injured in a collision greatly increases. If your child restraint system is equipped with a tether strap, and the child restraint manufacturer recommends its use, Ford also recommends its use. Child booster seats The belt-positioning booster (booster seat) is used to improve the fit of the vehicle safety belt.
Page 205 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that vehicle lap/shoulder safety belts fit better.
Page 206 Seating and Safety Restraints Types of booster seats There are generally two types of belt-positioning booster seats: backless and high back. Always use booster seats in conjunction with the vehicle lap/shoulder belt. • Backless booster seats If your backless booster seat has a removable shield, remove the shield.
Page 207 Seating and Safety Restraints Children and booster seats vary in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
Page 208 Refer to the child restraint manufacturer’s instructions for additional inspection and maintenance information specific to the child restraint. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
Page 209: Tires, Wheels And Loading
Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
Page 210 Tires, Wheels and Loading WARNING: The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. Temperature A B C The temperature grades are A (the highest), B and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 211 Ford Motor Company. You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial-type tire pressure gauge rather than a stick-type tire pressure gauge.
Page 212: Tire Inflation
Always inflate your tires to the Ford recommended inflation pressure even if it is less than the maximum inflation pressure information found on the tire. The Ford recommended tire inflation pressure is found on the Safety Compliance Certification Label or Tire Label which is located on the B-Pillar or the edge of the driver’s door.
Page 213 Tires, Wheels and Loading Note: If you have to drive a distance to get air for your tire(s), check and record the tire pressure first and add the appropriate air pressure when you get to the pump. It is normal for tires to heat up and the air pressure inside to go up as you drive.
Page 214 Tires, Wheels and Loading Improper or inadequate vehicle maintenance can cause tires to wear abnormally. Inspect all your tires, including the spare, frequently, and replace them if one or more of the following conditions exist: Tire wear When the tread is worn down to 1/16th of an inch (2 mm), tires must be replaced to help prevent your vehicle from skidding and...
Page 215 (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. The recommended tire and wheel size may be found on either the Safety Compliance Certification Label or the Tire Label which is located on the B-Pillar or edge of the driver’s door.
Page 216 The tire pressure sensors mounted in the wheels (originally installed on your vehicle) are not designed to be used in aftermarket wheels. The use of wheels or tires not recommended by Ford Motor Company may affect the operation of your tire pressure monitoring system.
Page 217 Tires, Wheels and Loading • Do not run over curbs or hit the tire against a curb when parking WARNING: If your vehicle is stuck in snow, mud, sand, etc., do not rapidly spin the tires; spinning the tires can tear the tire and cause an explosion.
Page 218 Tires, Wheels and Loading • Front-wheel drive (FWD) vehicles (front tires at top of diagram) • Rear-wheel drive (RWD) vehicles/Four-wheel drive (4WD)/All-wheel drive (AWD) vehicles (front tires at top of diagram) 2010 Taurus (500) Owners Guide, 3rd Printing USA (fus)
Page 219 Tires, Wheels and Loading Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask an authorized dealer to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation. Note: Your vehicle may be equipped with a dissimilar spare tire/wheel.
Page 220 Tires, Wheels and Loading 3. 65: Indicates the aspect ratio which gives the tire’s ratio of height to width. 4. R: Indicates a “radial” type tire. 5. 15: Indicates the wheel or rim diameter in inches. If you change your wheel size, you will have to purchase new tires to match the new wheel diameter.
Page 221 Tires, Wheels and Loading 8. U.S. DOT Tire Identification Number (TIN): This begins with the letters “DOT” and indicates that the tire meets all federal standards. The next two numbers or letters are the plant code designating where it was manufactured, the next two are the tire size code and the last four numbers represent the week and year the tire was built.
Page 222 Tires, Wheels and Loading 13. Maximum Permissible Inflation Pressure: Indicates the tire manufacturers’ maximum permissible pressure and/or the pressure at which the maximum load can be carried by the tire. This pressure is normally higher than the manufacturer’s recommended cold inflation pressure which can be found on the Safety Compliance Certification Label or Tire Label which is located on the B-Pillar or the edge of the driver’s door.
Page 223 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
Page 224: Tire Pressure Monitoring System (Tpms)
Tires, Wheels and Loading TIRE PRESSURE MONITORING SYSTEM (TPMS) Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.)
Page 225 Tires, Wheels and Loading The tire pressure monitoring system complies with part 15 of the FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 226 Tires, Wheels and Loading Understanding your tire pressure monitoring system (TPMS) The tire pressure monitoring system measures pressure in your four road tires and sends the tire pressure readings to your vehicle. The low tire pressure warning lamp will turn on if the tire pressure is significantly low.
Page 227 Tires, Wheels and Loading When you believe your system is not operating properly The main function of the tire pressure monitoring system is to warn you when your tires need air. It can also warn you in the event the system is no longer capable of functioning as intended.
Page 228 Tires, Wheels and Loading Low tire pressure Possible cause Customer action required warning light Flashing warning Spare tire in use Your temporary spare tire is in light use. Repair the damaged road wheel and re-mount it on the vehicle to restore system functionality.
Page 229 SNOW TIRES AND CHAINS WARNING: Snow tires must be the same size, load index, speed rating as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 230: Vehicle Loading
All-season or Snow tires, Ford does not recommend using summer tires when temperatures are below 40°F (5°C) or in snow / ice conditions. If you must drive in those conditions, Ford recommends using Mud & Snow (M+S or M/S), All-season or Snow tires.
Page 231 Tires, Wheels and Loading Payload – is the combined weight of cargo and passengers that the vehicle is carrying. The maximum payload for your vehicle can be found on the Tire Label on the B-Pillar or the edge of the driver’s door (vehicles exported outside the US and Canada may not have a Tire Label).
Page 232 Tires, Wheels and Loading Example only: Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load weight is also part of cargo weight. 2010 Taurus (500) Owners Guide, 3rd Printing USA (fus)
Page 233 Tires, Wheels and Loading GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) – including vehicle curb weight and all payload. GAWR (Gross Axle Weight Rating) – is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door.
Page 234 Tires, Wheels and Loading • Example only: WARNING: Exceeding the Safety Compliance Certification Label vehicle weight rating limits could result in substandard vehicle handling or performance, engine, transmission and/or structural damage, serious damage to the vehicle, loss of control and personal injury.
Page 235 Tires, Wheels and Loading GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) – is the maximum allowable weight of the vehicle and the loaded trailer – including all cargo and passengers –...
Page 236 Tires, Wheels and Loading 2. Determine the combined weight of the driver and passengers that will be riding in your vehicle. 3. Subtract the combined weight of the driver and passengers from XXX kg or XXX lbs. 4. The resulting figure equals the available amount of cargo and luggage load capacity.
Page 237: Trailer Towing
Tires, Wheels and Loading 1,400 - (2 x 220) - (9 x 100) = 1,400 - 440 - 900 = 60 lb. Now you have the load capacity to transport the cement and your friend home. In metric units, the calculation would be: 635 kg - (2 x 99 kg) - (9 x 45 kg) = 635 - 198 - 405 = 32 kg.
Page 238 Tires, Wheels and Loading If you use a rental trailer, follow the instructions that the rental agency gives to you. Do not attach safety chains to the bumper. Trailer brakes Electric brakes and manual, automatic or surge-type trailer brakes are safe if installed properly and adjusted to the manufacturer’s specifications.
Page 239: Recreational Towing
Tires, Wheels and Loading • Allow more distance for stopping with a trailer attached; anticipate stops and brake gradually. Servicing after towing If you tow a trailer for long distances, your vehicle will require more frequent service intervals. Refer to your scheduled maintenance information for more information.
Page 240 Tires, Wheels and Loading Front-wheel drive (FWD) vehicles: Tow your FWD vehicle with all four wheels on the ground or with the front wheels off the ground by using a tow dolly. If you are using a tow dolly follow the instructions specified by the equipment provider. All-wheel drive (AWD) vehicles: Tow your AWD vehicle with all four wheels on the ground or with all four wheels off the ground using a vehicle transport trailer.
Page 241: Driving
Driving STARTING Positions of the ignition (if equipped) If your vehicle is equipped with a push button start system, refer to Push button start system in this section for ignition modes. 1. Off— locks the gearshift lever and allows key removal. This position also shuts the engine and all electrical accessories off.
Page 242 Driving WARNING: Do not start your vehicle in a closed garage or in other enclosed areas. Exhaust fumes can be toxic. Always open the garage door before you start the engine. See Guarding against exhaust fumes in this chapter for more instructions. WARNING: If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately.
Page 243 Driving • Make sure the gearshift lever is in P (Park). 3. Turn the key to 3 (on) without turning the key to 4 (start). If your vehicle is equipped with a push button start system, refer to Push button start system in this section for ignition modes.
Page 244 Driving 3. After idling for a few seconds, release the parking brake, apply the brake, shift into gear and drive. Note: If the engine does not start on the first try, turn the vehicle to the off position, wait 10 seconds and try Step 2 again. If the engine still fails to start, press the accelerator to the floor and try Step 2 again, keeping the accelerator on the floor until the engine begins to accelerate above cranking speeds;...
Page 245 Driving 3. On — press and hold the START/STOP button for at least one second without applying the brake pedal. This will power your vehicle’s electrical system and the warning lights in the instrument cluster will illuminate, but the engine will remain off. Note: You cannot immediately start your vehicle from the on mode.
Page 246 Driving Fast Restart Feature: The Fast Restart feature allows you to re-start your vehicle within 20 seconds of switching the vehicle off, if a valid IA key is not present when the vehicle is switched off. When you switch your vehicle off without an IA key in the passenger compartment or trunk, the message RESTART NOW OR KEY IS NEEDED will be displayed in the message center.
Page 247 Driving Important ventilating information If the engine is idling while the vehicle is stopped for a long period of time, open the windows at least 1 inch (2.5 cm) or adjust the heating or air conditioning to bring in fresh air. ENGINE BLOCK HEATER (IF EQUIPPED) An engine block heater warms the engine coolant which aids in starting and allows the heater/defroster system to respond quickly.
Page 248: Brakes
Driving • To reduce the risk of electrical shock, do not use your heater with ungrounded electrical systems or two pronged (cheater) adapters. Also ensure that the block heater, especially the cord, is in good condition before use. • Make sure that when in operation, the extension cord plug/engine block heater cord plug connection is free and clear of water in order to prevent possible shock or fire.
Page 249 Driving Refer to Warning lights and chimes in the Instrument Cluster chapter for information on the brake BRAKE system warning light. Four-wheel anti-lock brake system (ABS) Your vehicle is equipped with an anti-lock braking system (ABS). This system helps you maintain steering control during emergency stops by keeping the brakes from locking.
Page 250 Driving Even when the ABS is disabled, normal braking is still effective. If your BRAKE warning lamp BRAKE illuminates with the parking brake released, have your brake system serviced immediately. Parking brake Apply the parking brake whenever the vehicle is parked. To set the parking brake, press the parking brake pedal down until the pedal stops.
Page 251: Advancetrac
Driving Press the parking brake pedal downward again to release the parking brake. Driving with the parking brake on will cause the brakes to wear out quickly and reduce fuel economy. Note: If the vehicle is driven with the parking brake applied, a chime will sound.
Page 252 Driving WARNING: Remember that even advanced technology cannot defy the laws of physics. It’s always possible to lose control of a vehicle due to inappropriate driver input for the conditions. Aggressive driving on any road condition can cause you to lose control of your vehicle increasing the risk of personal injury or property damage.
Page 253 Driving When an event occurs that activates AdvanceTrac , you may experience the following: • A slight deceleration of the vehicle • The stability control light will flash. • If your foot is on the brake pedal, a vibration in the pedal •...
Page 254 Driving During ESC events the stability control light in the instrument cluster will flash. Certain adverse driving maneuvers may activate the ESC system, which include but are not limited to: • Taking a turn too fast • Maneuvering quickly to avoid an accident, pedestrian or obstacle •...
Page 255 Driving AdvanceTrac Features Stabil- Message Control ity con- center dis- switch Mode trol off play (if functions equipped) light Turns on Default at System Ini- during Nothing Enabled Enabled start-up tialization bulb Displayed check Control switch TRACTION Traction pressed CONTROL Enabled Disabled control OFF once mo-...
Page 256 Driving AdvanceTrac sport mode The AdvanceTrac system provides an available sport mode on some models. This can be selected utilizing the AdvanceTrac off control switch as shown in the table above. Sport mode is not intended for use on public roadways as this mode provides less AdvanceTrac system intervention than when the default ESC and traction control systems are on.
Page 257 Driving WARNING: If the message SERVICE POWER STEERING is displayed in the message center, the EPS system has detected a problem with the system function. On the next key cycle the message SERVICE POWER STEERING NOW will be displayed and steering assist will be removed until the steering system is serviced.
Page 258 Driving If you cannot move the gearshift lever out of P (Park) with the ignition in the on position and the brake pedal pressed, it is possible that a fuse has blown or the vehicle’s brake lamps are not operating properly. Refer to Fuses and relays in the Roadside Emergencies chapter.
Page 259: Transmission Operation
Driving AUTOMATIC TRANSMISSION OPERATION Automatic transmission adaptive learning Your transmission is equipped with an adaptive learning strategy found in the vehicle computer. This feature is designed to increase durability and provide consistent shift feel over the life of the vehicle. A new vehicle or transmission may have firm and/or soft shifts.
Page 260 Driving R (Reverse) With the gearshift lever in R (Reverse), the vehicle will move backward. Always come to a complete stop before shifting into and out of R (Reverse). N (Neutral) With the gearshift lever in N (Neutral), the vehicle can be started and is free to roll.
Page 261 Driving To return to O/D (overdrive mode), press the transmission control switch again. • The Grade Assist lamp in the instrument cluster will not be illuminated. • The transmission will operate in gears one through six. L (Low) • Provides maximum engine braking. •...
Page 262 Driving R (Reverse) With the gearshift lever in R (Reverse), the vehicle will move backward. Always come to a complete stop before shifting into and out of R (Reverse). N (Neutral) With the gearshift lever in N (Neutral), the vehicle can be started and is free to roll.
Page 263: Reverse Sensing System
Driving Recommended shift speeds Upshift according to the following chart: Upshifts when accelerating (recommended for best fuel economy) Shift from: 1 - 2 15 mph (24 km/h) 2 - 3 25 mph (40 km/h) 3 - 4 40 mph (64 km/h) 4 - 5 45 mph (72 km/h) 5 - 6...
Page 264 Driving WARNING: To help avoid personal injury, always use caution when in R (Reverse) and when using the RSS. WARNING: This system is not designed to prevent contact with small or moving objects. The system is designed to provide a warning to assist the driver in detecting large stationary objects to avoid damaging the vehicle.
Page 265: Rear-View Camera System
REARVIEW CAMERA SYSTEM (IF EQUIPPED) The rearview camera is located on the trunk, under the spoiler for the SHO, or under the Ford badge for all other models. The camera system provides a video image which appears in the rear view mirror or...
Page 266 Driving Image delay if displayed through the rear view mirror: When shifting out of R (Reverse) and into any other gear, the image in the rear view mirror will remain on for a few seconds before it shuts off to assist in parking or trailer hookup. Image delay if displayed through the navigation screen: After shifting out of R (Reverse) and into any gear other than P (Park), the image in the navigation screen will remain until the vehicle speed...
Page 267 Driving Night time and dark area use At night time or in dark areas, the camera system relies on the reverse lamp lighting to produce an image. Therefore it is necessary that both reverse lamps are operating in order to get a clear image in the dark. If either of the lamps are not operating, stop using the camera system, at least in the dark, until the lamp(s) are replaced and functioning.
Page 268 Driving Operation The radar sensor detects vehicles ahead that are moving in the same direction as your vehicle. If the radar detects that your vehicle is rapidly closing on another vehicle a red warning light will illuminate and an audible warning chime will sound.
Page 269 Driving WARNING: The collision warning system’s brake support can only help reduce the speed at which a collision occurs if the driver applies the vehicle’s brakes. The brake pedal must be pressed just like for any typical braking situation. Blocked sensor If a message regarding a blocked sensor is displayed, the radar signals from the sensor, located behind a...
Page 270 Driving Activating/deactivating collision warning system To turn the warning system and/or chime on or off and set the warning sensitivity <– –>, refer to Message center in the Instrument Cluster chapter. Note: If the system cannot be turned off in a MyKey™ equipped vehicle, refer to MyKey™...
Page 271 Driving The BLIS and CTA has a yellow indicator (also referred to as the alert) located in the left and right exterior mirrors. When the vehicle is started, the BLIS automatically illuminates both indicators for several seconds indicating the system is operating. The first time you place the transmission in D (Drive) after starting the engine and drive forward at a speed greater than 3 mph (5 km/h) the BLIS system becomes active.
Page 272 Driving BLIS detection limitations: Due to the nature of radar technology, there may be certain instances where vehicles entering and exiting the blind spot zones may not be detected. Below is a list of circumstances that may cause non-detection: • Debris build-up on the rear quarter panel fascias •...
Page 273 Driving The CTA system detects vehicles approaching up to 45 feet (14 meters) away. Coverage decreases when vehicles and objects in close proximity block the CTA sensors (refer to figure for approximate zone coverage areas [sensor obstructed for vehicle on left]). Backing slowly from the parking spot in these situations helps to increase the sensor coverage and effectiveness.
Page 274 Driving CTA detection limitations: Due to the nature of radar technology, there may be certain instances where vehicles entering and exiting the blind spot zones may not be detected. Below is a list of circumstances that may cause non-detection: • Debris build-up on the rear quarter panel fascias •...
Page 275 Driving BLIS and/or CTA fault operation If the BLIS and/or CTA senses a fault on either the left or right sensor, the BLIS alert indicator will go on and remain on and the message center will display BLIND SPOT SYSTEM FAULT or CROSS TRAFFIC SYSTEM FAULT.
Page 276 Driving The following table lists possible causes and actions for this message being displayed: The surface of the radar is dirty or Clean the fascia area in front of obstructed in some way the radar, either side, or remove obstruction. The surface of the radar is not Drive normally in traffic for a few dirty or obstructed...
Page 277 Driving ALL WHEEL DRIVE (AWD) SYSTEM (IF EQUIPPED) Your vehicle may be equipped with a full-time All Wheel Drive (AWD) system. The AWD system is an active system, meaning it not only responds to wheel slip between the front and rear axles but also has the ability to anticipate wheel slip and transfer torque to the rear wheels before slip occurs.
Page 278 Driving Driving on slippery surfaces with AWD vehicles AWD vehicles are specially equipped for driving on sand, snow, mud and rough roads and have operating characteristics that are somewhat different from conventional vehicles, both on and off the highway. When driving at slow speeds off-highway under high outside temperatures, use L (Low) gear when possible.
Page 279 Driving Do not rock the vehicle for more than a few minutes or damage to the transmission and tires may occur or the engine may overheat. WARNING: Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the off position and remove the key whenever you leave your vehicle.
Page 280 Driving Sand When driving over sand, try to keep all four wheels on the most solid area of the trail. Avoid reducing the tire pressures but shift to a lower gear and drive steadily through the terrain. Apply the accelerator slowly and avoid spinning the wheels.
Page 281 Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
Page 282 The suspension and steering systems on your vehicle have been designed and tested to provide predictable performance whether loaded or empty and durable load carrying capability. For this reason, Ford Motor Company strongly recommends that you do not make modifications such as adding or removing parts (such as lift kits or stabilizer bars) or by using replacement parts not equivalent to the original factory equipment.
Page 283 Any modifications to a vehicle that raise the center of gravity can make it more likely the vehicle will rollover as a result of a loss of control. Ford Motor Company recommends that caution be used with any vehicle equipped with a high load or device (such as ladder or luggage racks).
Page 284: Roadside Emergencies
Roadside Emergencies ROADSIDE ASSISTANCE Getting roadside assistance To fully assist you should you have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: •...
Page 285: Hazard Flasher Control
Assistance, call 1-800-241-3673. Canadian customers who require roadside assistance, call 1-800-665-2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount for towing to the nearest dealership within 35 miles (56 km). To obtain reimbursement information, U.S.
Page 286: Fuel Pump Shut-Off
WARNING: Failure to inspect and if necessary repair fuel leaks after a collision may increase the risk of fire and serious injury. Ford Motor Company recommends that the fuel system be inspected by an authorized dealer after any collision. FUSES AND RELAYS...
Page 287 Roadside Emergencies Standard fuse amperage rating and color COLOR Cartridge Fuse Mini Standard Maxi Fuse link maxi rating fuses fuses fuses cartridge fuses Grey Grey — — — Violet Violet — — — Pink Pink — — — — — —...
Page 288 Roadside Emergencies Passenger compartment fuse panel The fuse panel is located under the instrument panel to the left of the steering wheel. The fuses are coded as follows. Fuse/Relay Fuse Amp Protected Circuits Location Rating Left front power window, Smart window motor Brake on/off switch Driver power seat...
Page 289 Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating Low beam headlamps (right) Interior lights, Cargo lamps Switch illumination, Puddle lamps All wheel drive (AWD) module 7.5A Passive entry/passive start (PEPS) module Memory seats, Mirrors, Keypad, PEPS receiver, Driver’s door module Navigation display, Memory seat, SYNC , Center information...
Page 290 Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating Ignition switch, PEPS, Front wipers, One-touch integrated start (OTIS) Start relay/Audio mute Instrument panel cluster, Heads-up display Not used (spare) Not used (spare) Airbag module Not used (spare) Anti-lock brake system (ABS), Electronic power steering Rear heated seats, AWD, Rear park assist, Steering angle sensor,...
Page 291 Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating 30A Circuit Front passenger power window, Breaker Rear power windows — Delayed accessory relay Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads.
Page 292 Roadside Emergencies The high-current fuses are coded as follows: Fuse/Relay Fuse Amp Power Circuits Location Rating 80A** Passenger compartment fuse panel power 80A** Passenger compartment fuse panel power — Not used 30A** Front wiper 30A** Passenger seat 20A** Cigar lighter —...
Page 293 Roadside Emergencies Fuse/Relay Fuse Amp Power Circuits Location Rating 10A* Backup relay 25A* Fuel pump 80A** Engine cooling fan — Not used — Not used — Not used 30A** Driver seat 30A** Passive entry/passive start (PEPS) — Not used 40A** Front heater blower 20A* Passenger compartment fuse...
Page 294: Changing Tires
Roadside Emergencies Fuse/Relay Fuse Amp Power Circuits Location Rating Half ISO relay PCM power relay — Not used Half ISO relay Front wiper relay Half ISO relay Rear window defroster relay — Not used — Not used Half ISO relay Left halogen headlamp relay Half ISO relay Right halogen headlamp relay...
Page 295 Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
Page 296 Roadside Emergencies Use of one of the dissimilar spare tires listed above at any one wheel location can lead to impairment of the following: • Handling, stability and braking performance • Comfort and noise • Ground clearance and parking at curbs •...
Page 297 Roadside Emergencies Stopping and securing the vehicle 1. Park on a level surface, set the parking brake and activate hazard flashers. 2. Place gearshift lever in P (Park) and turn engine off. Removing the spare tire and jack 1. Lift the trunk cargo cover, and remove the wing nut that secures the spare tire by turning it counterclockwise.
Page 298 Roadside Emergencies WARNING: To help prevent the vehicle from moving when you change a tire, be sure to place the transmission in P (Park), set the parking brake and block (in both directions) the wheel that is diagonally opposite (other side and end of the vehicle) to the tire being changed.
Page 299 Roadside Emergencies 3. Put the jack in the jack notch next to the tire you are changing. Turn the jack handle clockwise until the wheel is completely off the ground. Note: DO NOT LIFT ON THE PLASTIC MOLDING, as this could damage the molding.
Page 300 Roadside Emergencies Stowing the tire and jack 1. Fully collapse the jack, fold the lug wrench socket into the handle and place the jack and wrench into the felt bag as shown. Place the extension bolt into the external pocket of the felt bag. Take care to position the jack as shown to ensure that the locating holes in the jack base can be placed on the locating...
Page 301: Temporary Mobility Kit
120 miles (200 km) at a maximum speed of 50 mph (80 km/h). Note: The temporary mobility kit sealant compound in the canister is to be used for one tire only. See your Ford authorized dealer for additional replacement sealant canisters. 2010 Taurus (500)
Page 302 • Do not drive the vehicle above 50 mph (80 km/h). • Do not drive further than 120 miles (200 km). Drive only to the closest Ford Motor Company authorized dealer or tire repair shop to have your tire inspected.
Page 303 Always store the kit in its original location. • After sealant use, the TPMS sensor and valve stem on the wheel must be replaced by an authorized Ford dealer. 2010 Taurus (500) Owners Guide, 3rd Printing...
Page 304 Roadside Emergencies • When inflating a tire or other objects, use the black air hose only. Do not use the transparent hose which is designed for sealant application only. • Operating the temporary mobility kit could cause an electrical disturbance in radio and DVD player operation. What to do when a tire is punctured A tire puncture within the tire’s tread area can be repaired in two stages with the temporary mobility kit:...
Page 305 Roadside Emergencies 4. Plug the power cable into the 12V power point in the vehicle. 5. Remove the warning sticker found on the canister and place it on the top of the instrument panel or the center of the dash. 6.
Page 306 Roadside Emergencies Note: When the sealing compound is first added into the tire, the air pressure gauge reading on the compressor unit may indicate a higher value; this is normal and should be no reason for concern. The pressure will drop after about 30 seconds of operation. The tire pressure has to be checked with the compressor in the OFF position to get the correct tire pressure reading.
Page 307 After using the temporary mobility kit to seal your tire, you will need to replace the sealant canister and clear tube (hose). Sealing compound and spare parts can be obtained and replaced at an authorized Ford Motor Company dealership or tire dealer. Empty sealant bottles may be disposed of at home;...
Page 308 Roadside Emergencies Removal of the Sealant Canister from the Temporary Mobility Kit 1. Unwrap the clear tube from the compressor housing. 2. Press the button located on the temporary mobility kit compressor housing below the canister while pulling up on the sealant canister. Installation of the Sealant Canister to the Temporary Mobility 1.
Page 309: Wheel Lug Nut Torque
3. Wrap the clear tube around the compressor housing. Note: If you experience any difficulties with the removal or installation of the sealant canister, consult your Ford Motor Company authorized dealer for assistance. Be sure to check the sealant compound’s “use by” date regularly.
Page 310 1/2-20 UNF * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. WARNING: When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel.
Page 311: Jump Starting
Roadside Emergencies WARNING: Do not insert the nozzle of portable fuel containers or aftermarket funnels into the Easy Fuel™ system. This could damage the fuel system and its seal, and may cause fuel to run onto the ground instead of filling the tank, all of which could result in serious personal injury.
Page 312 Roadside Emergencies Connecting the jumper cables 1. Connect the positive (+) jumper cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery.
Page 313 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 314 Roadside Emergencies Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables.
Page 315 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 316: Wrecker Towing
It is recommended that your vehicle be towed with a wheel lift and dollies or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. On FWD vehicles, if your vehicle is to be towed from the front, ensure proper wheel lift equipment is used to raise the front wheels off the ground.
Page 317 If the vehicle is towed by other means or incorrectly, vehicle damage may occur. Ford Motor Company produces a towing manual for all authorized tow truck operators. Have your tow truck operator refer to this manual for proper hook-up and towing procedures for your vehicle.
Page 318: Customer Assistance
A reasonable time must be allowed to perform a repair after taking your vehicle to the authorized dealer. Repairs will be made using Ford or Motorcraft parts, or remanufactured or other parts that are authorized by Ford.
Page 319 • The name of the authorized dealer and city where located • The vehicle’s current odometer reading In some states, you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states.
Page 320 In the case of 1 or 2 above, the consumer must also notify the manufacturer of the need for the repair of the nonconformity at the following address: Ford Motor Company 16800 Executive Plaza Drive Mail Drop 3NE-B Dearborn, MI 48126...
Page 321 THE BETTER BUSINESS BUREAU (BBB) AUTO LINE PROGRAM (U.S. ONLY) Your satisfaction is important to Ford Motor Company and to your dealer. If a warranty concern has not been resolved using the three-step procedure outlined on the first page of the Customer Assistance section, you may be eligible to participate in the BBB AUTO LINE program.
Page 322 (CANADA ONLY) For vehicles delivered to authorized Canadian dealers. In those cases where you continue to feel that the efforts by Ford of Canada and the authorized dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 323 If you are in another foreign country, contact the nearest authorized dealer. If the authorized dealer employees cannot help you, they can direct you to the nearest Ford affiliate office. If you buy your vehicle in North America and then relocate outside of the U.S.
Page 324: Reporting Safety Defects (U.s. Only)
However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236 (TTY: 1–800–424–9153);...
Page 325: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3-A), which is available from your authorized dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 326 Cleaning WAXING • Wash the vehicle first. • Do not use waxes that contain abrasives; use Motorcraft Premium Liquid Wax (ZC-53-A), which is available from your authorized dealer, or an equivalent quality product. • Do not allow paint sealant to come in contact with any non-body (low-gloss black) colored trim, such as grained door handles, roof racks, bumpers, side moldings, mirror housings or the windshield cowl area.
Page 327 Cleaning ENGINE Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal. When washing: • Take care when using a power washer to clean the engine. The high-pressure fluid could penetrate the sealed parts and cause damage.
Page 328 Cleaning 3.5L V6 ENGINE 3.5L V6 SHO ENGINE 2010 Taurus (500) Owners Guide, 3rd Printing USA (fus)
Page 329 Cleaning PLASTIC (NON-PAINTED) EXTERIOR PARTS Use only approved products to clean plastic parts. These products are available from your authorized dealer. • For routine cleaning, use Motorcraft Detail Wash (ZC-3-A). • If tar or grease spots are present, use Motorcraft Bug and Tar Remover (ZC-42).
Page 330 Cleaning INSTRUMENT PANEL/INTERIOR TRIM AND CLUSTER LENS Clean the instrument panel, interior trim areas and cluster lens with a clean, damp, white cotton cloth, then use a clean and dry white cotton cloth to dry these areas. • Avoid cleaners or polishes that increase the gloss of the upper portion of the instrument panel.
Page 331 Cleaning • If grease or tar is present on the material, spot-clean the area first with Motorcraft Spot and Stain Remover (ZC-14). In Canada, use Motorcraft Multi-Purpose Cleaner (CXC-101). • If a ring forms on the fabric after spot cleaning, clean the entire area immediately (but do not oversaturate) or the ring will set.
Page 332 Cleaning FORD AND LINCOLN MERCURY CAR CARE PRODUCTS Your Ford or Lincoln Mercury authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 333: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle, we provide scheduled maintenance information which makes tracking routine service easy. If your vehicle requires professional service, your authorized dealer can provide the necessary parts and service. Check your Warranty Guide/Customer Information Guide to find out which parts and services are covered.
Page 334 Maintenance and Specifications OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom of the instrument panel near the steering column. 2. Go to the front of the vehicle and release the auxiliary latch that is located under the front center of the hood.
Page 335: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 3.5L V6 engine 1. Power steering fluid reservoir 2. Engine coolant reservoir 3. Brake fluid reservoir 4. Battery 5. Power distribution box 6. Air filter assembly 7. Automatic transmission fluid dipstick 8.
Page 336 Maintenance and Specifications 3.5L V6 SHO engine 1. Engine coolant reservoir 2. Brake fluid reservoir 3. Battery 4. Power distribution box 5. Air filter assembly 6. Automatic transmission fluid dipstick (out of view) 7. Engine oil dipstick 8. Engine oil filler cap 9.
Page 337 In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specifications. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing.
Page 338: Engine Oil
Maintenance and Specifications CHANGING THE WIPER BLADES 1. Pull the wiper blade and arm away from the glass. 2. Squeeze the locking tabs to release the blade from the arm and pull the blade away from the arm to remove it. 3.
Page 339 Maintenance and Specifications 5. Locate and carefully remove the engine oil level dipstick. 6. Wipe the dipstick clean. Insert the dipstick fully, then remove it again. • If the oil level is within this range, the oil level is acceptable. DO NOT ADD OIL.
Page 340 Maintenance and Specifications • Do not overfill the engine with oil. Oil levels above this mark may cause engine damage. If the engine is overfilled, some oil must be removed from the engine by an authorized dealer. 7. Put the dipstick back in and ensure it is fully seated. Adding engine oil 1.
Page 341: Battery
Approval Committee (ILSAC), comprised of U.S. and Japanese automobile manufacturers. To protect your engine and engine’s warranty, use Motorcraft SAE 5W-20 or an equivalent SAE 5W-20 oil meeting Ford specification WSS-M2C930-A. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.
Page 342 Maintenance and Specifications For longer, trouble-free operation, keep the top of the battery clean and dry. Also, make certain the battery cables are always tightly fastened to the battery terminals. If you see any corrosion on the battery or terminals, remove the cables from the terminals and clean with a wire brush.
Page 343 Maintenance and Specifications Because your vehicle’s engine is electronically controlled by a computer, some control conditions are maintained by power from the battery. When the battery is disconnected or a new battery is installed, the engine must relearn its idle and fuel trim strategy for optimum driveability and performance.
Page 344: Engine Coolant
Maintenance and Specifications ENGINE COOLANT Checking engine coolant The concentration and level of engine coolant should be checked at the intervals listed in scheduled maintenance information. The coolant concentration should be maintained at 50/50 coolant and distilled water, which equates to a freeze point of -34°F (-36°C). Coolant concentration testing is possible with a hydrometer or antifreeze tester.
Page 345 Maintenance and Specifications Note: Automotive fluids are not interchangeable; do not use engine coolant/antifreeze or windshield washer fluid outside of its specified function and vehicle location. Adding engine coolant When adding coolant, make sure it is a 50/50 mixture of engine coolant and distilled water.
Page 346 Maintenance and Specifications • Do not add extra inhibitors or additives to the coolant. These can be harmful and compromise the corrosion protection of the engine coolant. For vehicles with overflow coolant systems with a non-pressurized cap on the coolant recovery system, add coolant to the coolant recovery reservoir when the engine is cool.
Page 347 Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant since a Ford-approved recycling process is not yet available. Used engine coolant should be disposed of in an appropriate manner.
Page 348 Maintenance and Specifications • Refer to the chart on the coolant container to ensure the coolant concentration in your vehicle will provide adequate protection at the temperatures in which you drive. Vehicles driven year-round in non-extreme climates should use a 50/50 mixture of engine coolant and distilled water for optimum cooling system and engine protection.
Page 349 Maintenance and Specifications 2. Arrange for the vehicle to be taken to a service facility. 3. If this is not possible, wait a short period for the engine to cool. 4. Check the coolant level and replenish if low. WARNING: Fail-safe mode is for use during emergencies only. Operate the vehicle in fail-safe mode only as long as necessary to bring the vehicle to rest in a safe location and seek immediate repairs.
Page 350 Maintenance and Specifications WARNING: Automotive fuels can cause serious injury or death if misused or mishandled. WARNING: Gasoline may contain benzene, which is a cancer-causing agent. Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before refueling your vehicle.
Page 351 Maintenance and Specifications WARNING: When refueling always shut the engine off and never allow sparks or open flames near the filler neck. Never smoke while refueling. Fuel vapor is extremely hazardous under certain conditions. Care should be taken to avoid inhaling excess fumes. WARNING: The flow of fuel through a fuel pump nozzle can produce static electricity, which can cause a fire if fuel is pumped into an ungrounded fuel container.
Page 352 Maintenance and Specifications Easy Fuel™ “no cap” fuel system Your fuel tank is equipped with an Easy Fuel™ “no cap” fuel filler system. This allows you to simply open the fuel filler door and insert the fuel filler nozzle into the fuel system. The Easy Fuel™ system is self-sealing and protected against dust, dirt, water and snow/ice.
Page 353 Maintenance and Specifications WARNING: The fuel system may be under pressure. If you hear a hissing sound near the fuel filler door (Easy Fuel™ “no cap” fuel system), do not refuel until the sound stops. Otherwise, fuel may spray out, which could cause serious personal injury. Choosing the right fuel Use only UNLEADED fuel or UNLEADED fuel blended with a maximum of 10% ethanol.
Page 354 Ask your fuel supplier about gasolines that meet the World-Wide Fuel Charter. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality, per the recommendations in the Choosing the right fuel section. Running out of fuel Avoid running out of fuel because this situation may have an adverse effect on powertrain components.
Page 355 Maintenance and Specifications • Normally, adding 1 gallon (3.8L) of fuel is enough to restart the engine. If the vehicle is out of fuel and on a steep grade, more than 1 gallon (3.8L) may be required. • The service engine soon indicator may come on.
Page 356 Maintenance and Specifications 2. Slowly insert the funnel into the Easy Fuel™ system. 3. Fill the vehicle with fuel from the portable fuel container. 4. When done, clean the funnel or properly dispose of it. Extra funnels can be purchased from your authorized dealer if you choose to dispose of the funnel.
Page 357 Maintenance and Specifications The amount of usable fuel in the empty reserve varies and should not be relied upon to increase driving range. When refueling your vehicle after the fuel gauge indicates empty, you might not be able to refuel the full amount of the advertised capacity of the fuel tank due to the empty reserve still present in the tank.
Page 358 Maintenance and Specifications Driving style — good driving and fuel economy habits Give consideration to the lists that follow and you may be able to change a number of variables and improve your fuel economy. Habits • Smooth, moderate operation can yield up to 10% savings in fuel. •...
Page 359 Maintenance and Specifications • Carrying unnecessary weight may reduce fuel economy (approximately 1 mpg [0.4 km/L] is lost for every 400 lb [180 kg] of weight carried). • Adding certain accessories to your vehicle (for example bug deflectors, rollbars/light bars, running boards, ski racks) may reduce fuel economy.
Page 360 Maintenance and Specifications If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 361 Maintenance and Specifications 2. Poor fuel quality or water in the fuel—the engine may misfire or run poorly. 3. The fuel fill inlet may not have been properly closed. See Easy Fuel™ “no cap” fuel system in this chapter. 4. Driving through deep water—the electrical system may be wet. These temporary malfunctions can be corrected by filling the fuel tank with good quality fuel, properly closing the fuel fill inlet or letting the electrical system dry out.
Page 362 Maintenance and Specifications The OBD-II system is designed to check the emission control system during normal driving. A complete check may take several days. If the vehicle is not ready for I/M testing, the following driving cycle consisting of mixed city and highway driving may be performed: 15 minutes of steady driving on an expressway/highway followed by 20 minutes of stop-and-go driving with at least four 30-second idle periods.
Page 363 Maintenance and Specifications BRAKE FLUID The fluid level will drop slowly as the brakes wear, and will rise when the brake components are replaced. Fluid levels between the MIN and MAX lines are within the normal operating range; there is no need to add fluid.
Page 364 Maintenance and Specifications 5. Remove the dipstick, wiping it clean with a clean, dry lint free rag. If necessary, refer to Identifying components in the engine compartment in this chapter for the location of the dipstick. (For vehicles with the EcoBoost™...
Page 365 Maintenance and Specifications C. Remove the bolt cover (if equipped). D. Remove two bolts that attach the air filter assembly to the front of the vehicle (2). E. Loosen the clamp holding the air filter assembly to the rubber hose (1).
Page 366 Maintenance and Specifications WARNING: Do not run engine with the air filter disconnected. Start the engine and continue with Step 6. 6. Install the dipstick making sure it is fully seated in the filler tube by turning it to the locked position. 7.
Page 367 Maintenance and Specifications Adjusting automatic transmission fluid levels Before adding any fluid, make sure the correct type is used. The type of fluid used is normally indicated on the dipstick and also in the Maintenance product specifications and capacities section in this chapter.
Page 368: Air Filter(S)
Maintenance and Specifications AIR FILTER Refer to scheduled maintenance information for the appropriate intervals for changing the air filter element. When changing the air filter element, use only the air filter element listed. Refer to Motorcraft part numbers in this chapter. WARNING: To reduce the risk of vehicle damage and/or personal burn injuries do not start your engine with the air cleaner removed and do not remove it while the engine is running.
Page 369: Part Numbers
Replace the spark plugs with ones that meet Ford material and design specifications for your vehicle, such as Motorcraft or equivalent replacement parts. The customer warranty may be void for any damage to the engine if such spark plugs are not used.
Page 370 Maintenance and Specifications 2010 Taurus (500) Owners Guide, 3rd Printing USA (fus)
Page 371 Maintenance and Specifications 2010 Taurus (500) Owners Guide, 3rd Printing USA (fus)
Page 372 Maintenance and Specifications 2010 Taurus (500) Owners Guide, 3rd Printing USA (fus)
Page 373: Engine Data
Maintenance and Specifications ENGINE DATA Engine 3.5L V6 engine 3.5L V6 SHO engine Cubic inches See Octane See Octane Fuel recommendations recommendations earlier earlier in this chapter. in this chapter. Firing order 1–4–2–5–3–6 1–4–2–5–3–6 0.052–0.056 inch 0.033–0.037 inch Ignition system (1.32–1.42 mm) (.838–.939 mm) Spark plug gap...
Page 374 Maintenance and Specifications 3.5L V6 SHO engine IDENTIFYING YOUR VEHICLE Safety Compliance Certification Label The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located.
Page 375 Maintenance and Specifications Vehicle identification number (VIN) The vehicle identification number is located on the driver side instrument panel. XXXXXXXXXXXXXXXXX Please note that in the graphic, XXXX is representative of your vehicle identification number. The Vehicle Identification Number (VIN) contains the following information: 1.
Page 376 Maintenance and Specifications TRANSMISSION CODE DESIGNATIONS You can find a transmission code on the Safety Compliance Certification Label. The following table tells you which transmission each code represents. Description Code 6F50 6-Speed Automatic Transmission 6F55 6–Speed Automatic Transmission (with EcoBoost) 2010 Taurus (500) Owners Guide, 3rd Printing USA (fus)
Page 377: Accessories
GENUINE FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of Genuine Ford Accessories are available for your vehicle through your local Ford or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 378 Accessories Peace of mind Remote start Vehicle security systems Wheel locks For maximum vehicle performance, keep the following information in mind when adding accessories or equipment to your vehicle: • When adding accessories, equipment, passengers and luggage to your vehicle, do not exceed the total weight capacity of the vehicle or of the front or rear axle (GVWR or GAWR as indicated on the Safety Compliance Certification label).
Page 379: Ford Extended Service Plan
FORD ESP EXTENDED SERVICE PLANS More than 30 million Ford, Lincoln, and Mercury owners have discovered the powerful protection of Ford ESP. It is the only extended service plan backed by Ford Motor Company, and provides “peace of mind” protection beyond the New Vehicle Limited Warranty coverage.
Page 380 Ford ESP Can Quickly Pay for Itself One service bill – the cost of parts and labor – can easily exceed the price of your Ford ESP Service Contract. With Ford ESP, you minimize your risk for unexpected repair bills and rising repair costs.
Page 381 Ford Extended Service Plan 2010 Taurus (500) Owners Guide, 3rd Printing USA (fus)
Page 382: Index
Index Automatic transaxle fluid, refill capacities ....370 fluid, specification ....370 Accessory delay ......84 Automatic transmission Adaptive Cruise Control .....89 driving an automatic overdrive ......259, 261 AdvanceTrac ......251 fluid, adding ......363 AdvanceTrac Sport Mode ..256 fluid, checking ......363 Selectshift (SST) ....262 Air cleaner filter ....368–369 Auxiliary input jack (Line in) ..40 Air conditioning ....50, 53...
Page 383 (see Speed control) ....87 Child safety seats ......197 Cupholder(s) ......162 attaching with tether straps ..203 Customer Assistance ....284 in front seat ......197 Ford Extended Service in rear seat ......197 Plan ..........379 Getting assistance outside LATCH ........200 the U.S. and Canada ....322 recommendations ....194...
Page 384 Index through water ....280, 283 calculating fuel economy .21, 356 cap ...........352 capacity ........370 choosing the right fuel ...353 Electronic message center ..19 comparisons with EPA fuel economy estimates ....359 Emergencies, roadside detergent in fuel .....354 jump-starting ......311 filler funnel ......354 running out of fuel ..310, 354 filling your vehicle with Emission control system ..359...
Page 385 Index Heating positions of the ignition ..241 heating and air conditioning system ......50, 53, 55 Homelink wireless control Lamps system ........101 autolamp system .......61 Hood ..........334 bulb replacement specifications chart ....70 daytime running light ....65 headlamps .........61 Ignition .......241, 373 headlamps, flash to pass ..65 instrument panel, dimming ..66 Illuminated visor mirror .....77...
Page 386 Index Motorcraft parts ....332, 369 Power windows opening using remote entry Multi-contour seats ....149 system ........130 MyKey ........114 Push button start system ..244 Navigation system .......49 Radio ..........31 6-CD in dash ......31 Rear heated seats .....163 Rear-view camera system ..265 Octane rating ......353 Oil (see Engine oil) ....338 Recommendations for...
Page 387 Index Occupant Classification Stereo Sensor ........165 6-CD in dash ......31 warning light and chime ..172 CD-MP3 ........31 Safety restraints - LATCH SYNC ..........49 anchors ........200 Safety seats for children ..197 Safety Compliance Temporary mobility kit .....301 Certification Label ....374 Tilt steering wheel ......77 Satellite Radio Information ..46 Tire Pressure Monitoring Seats ..........145...
Page 388 Index fluid, checking and adding (automatic) ......363 Warning lights (see Lights) ..12 Trunk .........126 remote release ....111, 131 Washer fluid ......337 Turn signal ........68 Water, Driving through .....283 Windows Universal garage door opener ..100 opening using remote entry system ........130 USB port ........42 power .........82 Windshield washer fluid and...

Ford Taurus 2010 Owner's Manual

Introduction

Instrument Cluster

Entertainment Systems

Climate Controls

Lights

Driver Controls

Locks and Security

Seating and Safety Restraints

Quick Links

Table of Contents

Troubleshooting

Related Manuals for Ford Taurus 2010

Summary of Contents for Ford Taurus 2010

Table of Contents
