Repair Instructions
Disassembly
Shaft assembly, cartridge version
Prior to
N94-42
L95
N98-33
and beyond
B10
Endcap disassembly
12
Series 51 and 51-1 Bent Axis Motors Repair Instructions
10. Press shaft assembly out of bearing housing, taking care to not damage the shaft, piston sockets, and
speed sensor ring (if installed).
L35
N94-42
thru
L85
N98-32
L90
L95
L81
L82
L95
L81
L90
L85
060 frame
1. Remove end cap plug (G80). Remove O-ring (G80A) from plug; discard.
2. Remove lock screws (F28) from servo piston (F12).
3. Remove cone-point set screws (F26) from servo piston.
4. Remove feedback fork (F30) through the hole in the end cap.
11009449 • Rev BA • December 2014
L40
L50
L80
B80
L35
L35
P104 088
L80
L750
L70
060 and 080: 6mm
110: 8mm
160: 10mm
250: 12mm
