Repair Instructions
Introduction
Section diagram
Series 51 and 51-1 Bent Axis Motors Repair Instructions
Series 51 bent axis variable motor
Multi-function
Pressure compensator
block
override
Control
(hydraulic proportional)
4-way valve
and sleeve
Control
springs
End cap
Servo piston
11009449 • Rev BA • December 2014
Minimum displacement
limiter
Valve segment
Bearing plate
Tapered roller bearings
Piston
Housing
Charge pressure
relief valve
Minimum angle
servo cover
Motor output shaft
Synchronizing
shaft and rollers
P104 085
7
