Fig. 2- 1

Short Delayhstantaneous Pick-Up Settings

Ground
Fault
Pick-up
Fig. 2-3

Ground Fault Pick-Up Settings

Effective February 2006
Courtesy of NationalSwitchgear.com
Available Settings
5 , 6, 7, 8 Multiples
in
of Rating Plug Amperes
not available o n 2500A Trip Units)
Available Settings
Specific Amperes
Given i n Table 1-2
Short Delay
Time
I
I
Fig. 2-2 Short Delay Time Settings
I
I
Available Settings
0.15, 0.3, 0.5 Seconds
with Flat Response
Fig. 2-4

Ground Fault Time Settings

I.L. 29C883E
Available Settings
I,
.l, .2, Seconds
w i t h Flat Response
Ground Fault
Time
I
