Summary of Contents for Eaton EX RT7
- Page 1 ИБП Eaton / MGE EX RT - Eaton EX RT - EMC Filter - Установка и эксплуатация Постоянная ссылка на страницу: https://eaton-power.ru/catalog/eaton-mge-ex-rt/...
- Page 2 Kit Navy Low Frequency Filter Module Installation & User Manual EX RT 7/11...
- Page 3 Installation & User Manual Kit Navy Low Frequency Filter Module SUMMARY 1 – PRODUCT DEFINITION 2 – CERTIFICATION 3 – PACKING DESCRIPTION 4 – TECHNICAL CHARACTERISTICS 5 – POWER DERATING TABLE 6 – DIMENSIONS & WEIGHT 7 – INSTALLATION 8 – LOW FREQUENCY FILTER MODULE CONNECTION 8.1 –...
- Page 4 Installation & User Manual Kit Navy Low Frequency Filter Module 1. PRODUCT DEFINITION This filter module has to be associated with an UPS : - EX RT 7 - EX RT 11 This complete installation will met IEC 60945 standards. 2.
- Page 5 Installation & User Manual Kit Navy Low Frequency Filter Module 5. POWER DERATING TABLE WITH EX RT 11 Input Voltage / Ambient Temperature 0 °C – 25 °C 25 °C – 35 °C 35 °C – 45 °C 220 – 280 Volts AC 100 % 100 % 100 %...
- Page 6 Installation & User Manual Kit Navy Low Frequency Filter Module 8.1 EX RT 7 ET EX RT 11 The cable to connect the filter module to the UPS is not provided. Achieve the connections on the different terminals (input and output) of the filter module, comply with the cable capacity as recommended here under.
