User´s

Manual

IM 01R01B02-00E-E

Model RAMC

Metal Short Stroke ROTAMETER

Rota Yokogawa GmbH & Co. KG

Rheinstr. 8

D-79664 Wehr

Germany

IM 01R01B02-00E-E

12th edition, October 2014 (Rü)

Table of Contents

Troubleshooting

Need help?

Do you have a question about the RAMC and is the answer not in the manual?

Questions and answers

Summary of Contents for YOKOGAWA RAMC

Page 1 Model RAMC User´s Manual Metal Short Stroke ROTAMETER IM 01R01B02-00E-E Rota Yokogawa GmbH & Co. KG IM 01R01B02-00E-E © Rheinstr. 8 Copyright 2003 (Rü) D-79664 Wehr 12th edition, October 2014 (Rü) Germany...
Page 2 Blank Page...
Page 3: Table Of Contents
< > CONTENTS Contents 1. Introduction ..................1-1 1.1 For Safe Use of Rotameter RAMC ..............1-2 1.2 Warranty ......................1-3 1.3 Notices regarding EMC ..................1-3 1.4 General description ..................1-4 1.5 Principle of measurement ................1-4 1.6 Overview ......................1-5 2. Precautions ..................2-1 2.1 Transportation and storage ................2-1 2.2 Installation .......................2-1...
Page 4 7.4.2 Diagnostic- and Service-Menu ................7-7 7.4.3 Basic-Setup Menu ....................7-13 7.4.4 Detailed-Setup Menu ...................7-13 7.4.5 Review ........................7-15 7.5 Maintenance ....................7-16 7.5.1 Function test ......................7-16 7.5.2 Troubleshooting ....................7-16 All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 5 9.1 Model- and suffix-codes .................9-1 9.2 Options ......................9-2 9.3 Standard Specifications .................9-4 9.4 Dimensions and weights................9-15 9.5 Temperature graphs for RAMC metal design, standard and intrinsic safe ............................9-18 10. Explosion-protected Type Instruments .......... 10-1 10.1 General ......................10-2 10.1.1 Intrinsic safety ....................10-2 10.1.2 Flame proof ......................
Page 6 (/KS2) ........................10-26 10.13 Intrinsically safe IECEx certified components in dust proof RAMC- hou- sing (/ES2) ......................10-26 10.14 Flame proof and dust proof NEPSI (China) certified RAMC (/NF1) ..10-27 10.14.1 Technical data ....................10-27 10.14.2 Installation ....................10-27 10.14.3 Operation ...................... 10-28 All Rights Reserved.
Page 7 < > CONTENTS 10.15 Flame proof EAC (Russia, Belarus, Kazakhstan) certified RAMC (/GF1) . 10-28 10.15.1 Technical data ....................10-28 10.15.2 Installation ........................10-28 10.15.3 Operation ........................10-28 11. Instructions for PED ............... 11-1 APPENDIX 1. SOFTWARE CHANGE HISTORY ......... A1-1 APPENDIX 2. Safety Instrumented Systems Installation ....A2-1 A2.1 Scope and Purpose ..................
Page 9: Introduction
The following safety symbols and cautionary Before use, read this manual thoroughly and familiarize yourself fully with the features, notes are used on the product and in this operations and handling of Rotameter RAMC to have manual: the instrument deliver its full capabilities and WARNING to ensure its efficient and correct use.
Page 10: For Safe Use Of Rotameter Ramc
(2) Wiring and by preventing static electrification using • The wiring of the RAMC flowmeter must be per- grounded wrist straps when handing the formed by expert engineer or skilled personnel. No assembly.
Page 11: Warranty
• reason of force measure such as fires, earthquakes, storms/ floods, thunder/lightning, or other reasons not attributable to the instrument in question. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 12: General Description
YOKOGAWA service centre or sales office. Please describe any defect precisely and indicate model code as well as serial number. YOKOGAWA refuses any liability for units which have been repaired by the user without prior consent and do not meet the specifications as a consequence.
Page 13: Overview
- Pressure range of flange and measuring tube e.g. PN40 - Material of wetted parts e.g. 1.4404 - Manufacturing code of flange manufacturer - Lot. No. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 14 1.1 t/m 1 mPas 20 Grad C 1.1 bar abs. Medium data (fluid properties at process conditions) F12.EPS Fig. 1-4 Scale example for -T -type All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 15: Precautions
(such as solenoid valves). Alternating magnetic fields (≥ 10Hz) as well as homogeneous, static magnetic fields (in the area of the RAMC), like the geomagnetic field have no influence. Asymmetric ferromagnetic bodies of considerable mass (e.g. steel girders) should be kept at a distance of at least 250 mm from the RAMC.
Page 17: Installation
Centre gaskets and tighten nuts with a torque appropriate for the pressure range. If contamination or soiling of the RAMC is to be expected, a bypass should be installed to allow the removal of the instrument without interruption of the flow.
Page 18: Wiring Of Electronic Transmitter (-E, -H) And Limit Switches (/K_)
Please regard the drawings on the following pages. On the rear of the RAMC are two cable glands for round cables with a diameter of 6 to 9 mm (not for Ex-d-type option /_F1). Unused glands must be closed with a blind plug M16x1.5.
Page 19 Operation keys Digital display Calibration-EEPROM Pulse output (option /CP) Cable gland Current output Mains connector Angle transmitter Power supply circuit Fig. 3-2 4-wire unit All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 20 Option: /W2B One channel connection like limit MAX Limit MAX Limit MIN KFA6-SR2-Ex2.W F1.EPS Fig. 3-3 RAMC 2-wire unit with limit switches and transmitter relay Rotameter RAMC 0/4 - 20mA Power supply U Power supply U / V RL /...
Page 21 Option: /W2A one channel: KF A6-SR2-Ex1.W One channel connection like limit MAX F5.EPS Fig. 3-6 Ex-version acc. to ATEX (Option /KS1 and /KS2) : RAMC 2-wire unit with power supply, limit switches and transmitter relay All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E...
Page 22 Transmitter Relay Option: /W2B One channel connection like limit MAX F4.EPS Fig. 3-7 RAMC 2-wire unit with HART-communication, with limit switches and transmitter relay All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 23: Start Of Operation
When changing from a 3- to 2-wire configuration, the jumper should be set in place, and the current output has to be adjusted according to section 6-2-6. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 25: Limit Switches (Option /K[])
Use of 2 standard limit switches (option /K3): The MIN-MIN and MAX-MAX functions have been integrated at the factory as MIN-MAX switches in the RAMC. The MIN-MIN or MAX-MAX function is set by adjusting the switching direction of the transmitter relay. The...
Page 27: Electronic Transmitter (-E)
The setting of these parameters is done by two buttons. Digital display Engineering unit of the display Operation keys F61.EPS Fig. 6-1 Operation keys All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 29 F73 : Supervision time F73-1 : 5 Minutes F73-2 : 15 Minutes F74 : Autozero F74-1 : Execute Bold type = Factory Pre-setting *) Option /CP All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 30: Selection Of Indication Function (F11)
After changing the indicating function and measuring units the corresponding measuring unit label should be fixed on the right side next to the display. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 31: Setting The Unit (F12 / F13)
(32°F; 1 Atm.abs = 14.69 psi Standard cubic feet scft (70°F; 1Atm.abs = 14.69 psi Long ton Kilogram Pound Gallon (US) Time unit Hour Minute Second All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 32 A sheet with stickers is included. Attention: When switching the mass/volume unit the totalizer is reset to zero. When changing the time unit the totalizer value remains unchanged. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 33: Totalizer Reset (F14)
If you press “↑" instead of “Enter” , you can return from the selected point to the previous menu without activating the displayed parameter. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 34: Setting Of Damping (F2-)
(Setting current to 20 mA) Decrease F33 in steps of -1 (-20 µA) if 20 mA Enter ↑ Back to display mode ↑ Display mode All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 35: Pulse Output (F34) (Option /Cp)
A perhaps necessary fine adjustment can be carried out with F32 or F33. WARNING Since YOKOGAWA doesn’t have any influence on the custom-designed connection the current output is not automatically adapted, if the connection is changed from 2 wire to 3 wire or vice versa .This must be manually carried out with the functions F32 and F33.
Page 36 Special case : If Qmax is higher than 10000, the pulse rate is increased by factor 10 in both cases.That means: · F34 -2 last but one totalizer digit · F34 -3 third totalizer digit from the right All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 37 • When changing the indication with F11 -3 to ´%´, the totalizer stops and the pulse output is switched off. • After switching power on one pulse is generated at the output. • For 2- respectively 3-wire-units the function F34 is not supported. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 38: Error Messages (F4-)
Float blocking indication realized, Deactivate float-blocking-indication or run Autozero supervision time gone off function In case of error the appropriate remedy has to be taken. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 39: Manual Adjustment (F5-)
1.a ) Calculate the new of flow rate to mm (on scale) relation based on original manufacturers calibration certificate. 1.b ) Place the RAMC (with the measuring tube) horizontally on a table (Note: the distance to any ferro- magnetic parts must be at least higher then 25 cm!).
Page 40 In these cases the following steps have to be performed: 2.a ) Place the RAMC in line with the master meter in an installation allowing controlled flow with the process fluid at process conditions in a flow range from 5% to 105% of the expected flow range.
Page 41 EEPROM for the new fluid and/or new process conditions (this gives new adjustment plus new calibration). All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 42: Revision Indication (F61/F62)
If you press “ ” instead of “Enter” , you can return from the selected point to the previous ↑ menu item without activating the displayed parameter. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 43: Switching Between Standard / Indicator On Extension (F64)
F64 allows switching between the standard calibration table and a calibration table of the remote version (option /A16 for high temperatures). The adjustment has to be performed according to the RAMC type (MS code). This is done as follows: Description...
Page 44: Float Blocking Indication (F7-)
4 bars will flash below the numbers. After approx. 80 seconds the current autozero value appears on the display. This value gets stored and will not be lost after power off / on the RAMC or after switching off / on the Float-Move-Detection-function.
Page 45 - 3 - wire 4-20 mA: Error condition: IA < 0.0 mA - 3 - wire 0-20 mA: Error condition: IA = 0.0 mA All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 46 Check float in tube, clean tube if necessary. Supervision time gone off Deactivate float blocking indication or run Autozero function. Factory defaults / Master Reset (F65) The RAMC is adjusted at delivery (Factory Setting): - F71 - 1 Float-Move-Detection OFF - F72 - 1...
Page 47 3 x → Selection Autozero Enter Inquire autozero value (80s) Enter 0.000 Display autozero value (10s) 0.xxx ↑ Back to display mode ↑ Display mode All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 49: Hart ® - Communication
7. HART - Communication ® 7.1 General ® RAMC with indication unit type -H have, additional to the current output, the possibility for HART ® ® Communication. Also without HART - Communication the units are fully able to work. The HART Communication does not influence the current output, except in Multidrop-Mode (see below).
Page 50: Connection
The minimum power supply is 13.5V + (RL*20mA) ; RL = load resistor The maximum power supply is 30V. As connection cable a protected twisted cable pair is recommended. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 51: Hart5 Menu (Rev 01 Dd Rev 02)
4 mA/ 20mA calib table Std version Dist version Manual calib Status mancal ON / OFF Activate/deactiv ON / OFF Set mancal points 5%/15%/ ... /95%/105% All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 52 Snsr s/n Final assy no MS - Code Configure signal Flow damping Flow damp 0.25 sec Set damping 1.00 sec 5.00 sec 10.00 sec All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 53 Manufacturer Distributor Snsr s/n Final assy no Write protect Descriptor Message Date Poll addr Num req preams Num resp preams Long tag MS Code All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 54: Description Of The Hart5 ® - Parameter
Current output in mA Flow URV Upper range value related to the current output Flow LRV Lower range value related to the current output All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 55: Process Variables
OFF/ON Float blocking autozero on Power fail warn OFF/ON Power off has happened Oper timer error OFF/ON Operation timer fault Mancal active OFF/ON Manual calibration activated All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 57 Set as 20mA value: Current flow is set to 20mA. Read new value: Read current flow for 20mA. Leave as found: No change Exit Leave parameter All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 58 By switching Temp max log off the values are not cleared. When exceeding the maximum temperature of 70°C the error message “Temp over limit” appears. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 59 Read out - delta-T1 - MAX Value - Status delta-T1 (day; h; min) Reset to actual value - on Clear MAX valu Time [h] Temperature All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 60 At power off the time from parameter Operation time is stored in parameter Oper time shadow. After power off/on the power fail warning is set. It can be cleared by Reset power fail. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E...
Page 61: Basic-Setup Menu
MetTon/h CuFt/h Kg/h Lton/h StdCuFt/h Lb/h ImpGal/h gal/h Cum/min Cum/min L/min NmlCum/min NmlCum/min Kg/min NmlL/min StdCuFt/min MetTon/min CuFt/min Kg/min Lton/min StdCuFt/min Lb/min ImpGal/min gal/min All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 62 Selection of measuring value on display, Different if manual calibration is activated. For standard calibration table: Flow / Totalizer / Temperature For manual calibration table: Percent / Temperature All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 63: Review
Universal rev.: Fld. Dev. rev.: Field device Revision HW rev.: Hardware Revision FW rev.: Firmware Revision ADJ-EE rev.: Adjustment-EEPROM Revision CAL-EE rev.: Calibration-EEPROM Revision All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 64: Maintenance
Load HART ® -DD for contain DD for RAMC? RAMC in communicator. (Yokogawa Service) Communicator OK ? Change communicator. RAMC to Yokogawa Service T76.EPS All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 65: Service
The RAMC is maintenance-free. If contamination of the measuring tube impairs the mobility of the float, the tube and the float have to be cleaned. To do this, the RAMC has to be removed from the pipe. Replacement or cleaning of the float: - Remove RAMC from the pipe.
Page 66: Explosion Drawing
<8. SERVICE> 8.1.3 Explosion drawing Number Part Circlip Float stop Float Float stop welded in Cone Indicator All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 67: Electronic Transmitter
66 and the 2 buttons click in in the accompanying holes for unit with electronic transmitter. · Fasten the scale with the 2 screws. Exchange scale at units with limit switches: Please, consult to this the service department of ROTA YOKOGAWA. Final jobs : · Connect the cover of the indicator. - For RAMC with housing type 91 lock the safety screw.
Page 68: Exchange Of Indicator
8.1.7 Troubleshooting In case the RAMC does not work properly, use the following flow charts for troubleshooting, then check, isolate and remedy the fault. Precision problems with "T" unit: execute test 1 Precision problems with "E"...
Page 70: Template For Sending Back To Service
RAMC Due to legislation for the protection of the environment and for the safety of our staff, YOKOGAWA may only ship, repair and check sent devices on the condition that this does not constitute any risk to environment and staff.
Page 73: Technical Data
Profibus PA; 9 ... 32 V DC Only with indicator G; not with limit switches Without power supply Only with indicator T or N All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 74: Options
WQC acc. DIN EN 287-1 (Welder Qualification Certificate), manual welding (SS) WQC acc. DIN EN ISO 6906-4 (Welder Qualification Certificate), manual welding (nickel alloy) All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 75 Special design must be specified separately *) if no instruction manual is selected, only a DVD with instruction manuals is shipped with the flowmeter All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 76: Standard Specifications
CANADIAN REGISTRATION NUMBERS (CRN ) available - AI block for volume flow or mass flow upon request - Configurable with PDM DD - Supports I&M- functions All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 77 - Thread ½” NPT (option /A5) Cable diameter : 6 – 9 mm Maximum cross section of core : Ø 1.5 mm² referenced to 20°C ambient temperature All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 78 <9. TECHNICAL DATA> COMPLIANCE WITH IEC 61508 SWITCHING LEVELS FOR LIMIT SWITCHES Table 2 Min, Max and Min-Max-contact in standard version RAMC with local indicator and fail safe limit switches (-T[] []NNN /K6 ... /K10): Option /K1 Option /K2 Option /K3 Suitable for application in safety functions up to and including SIL2.
Page 79 Comment *6) For USA and Canada; power supply must be option /WxA or /WxB (x=1 or 2 or 4) Comment *7) Only with housing 91 All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 80 Entity parameter of electronic transmitter : see table 6 Limit switches : option /K1 to /K10 Entity parameter of limit switches : see certificate NEPSI GYJ06542X All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 81 NEPSI : GYJ091350 Control circuit (ATEX) : [Ex ia] IIC; group II ; category (1)GD Entity parameter : see fig. 4 (ATEX) and certificate All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 82 9-10 <9. TECHNICAL DATA> FLAME PROOF AND DUST PROOF RAMC Flame proof RAMC with EAC- certificate (Russia, Belorussia, Kazakhstan) (option /GF1): Flame proof and dust proof RAMC with ATEX- Certificate : certificate (option /KF1): RU С-DЕ.ГБО8.В.00317 Certificate : Flame proof : IBExU 05 ATEX 1086 1Ex d IIC T1 ...
Page 83 Ambient temperature : -20 °C to 60 °C Minimum process temperature : -20°C Threads for cable glands : - M20x1.5 (standard) - ½” NPT (option /A5) All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 84 9-12 <9. TECHNICAL DATA> RAMC PROCESS CONNECTION TABLE FOR METAL TUBES Table 9-10 L = face to face length Accuracy 2.5% instead of 1.6% (q = 50%) All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 85 Flow in Standard cubic feet per minute referred to 60°F and 14,7 PSI at operation conditions of 70°F und 14,7 PSI abs. For your special application please use the Rota Yokogawa Sizing-Program. All Rights Reserved. Copyright © 2003, Rota Yokogawa...
Page 86 9-14 <9. TECHNICAL DATA> RAMC PROCESS CONNECTION- AND FLOW-TABLE FOR TUBES WITH PTFE LINING Table 9-12 (1) L = Mounting length a) Pressure loss at the float with water or air. b) As from this viscosity the specified precision is no more guaranteed.
Page 87: Dimensions And Weights
Fig. 9-2. Front view RAMC type 91 T15.EPS T14.EPS Fig. 9-3 RAMC metal measuring tube Fig. 9-4 RAMC metal measuring tube with lining Housing type 90 Housing type 91 standard Housing type 91 flame proof , option /KF1 Housing type 66 All Rights Reserved.
Page 88 110.0 see table 9.10, 9.11, 9.12 T26.EPS T25.EPS Fig. 9-5 RAMC type 91 and option /A16 and /T2 Fig. 9-6 RAMC with connection R4 / T4 All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 89 9-17 <9. TECHNICAL DATA> T18.EPS T19.EPS Fig. 9-7 RAMC with connection T6/ G6 Fig. 9-8 RAMC with connection S2 Table 9.15 Diameter for RAMC connection sizes S4 Position Size [mm] di [mm] da [mm] DN25 / 1´´ 50.5 DN32 50.5 DN40 / 1 ½...
Page 90: Temperature Graphs For Ramc Metal Design, Standard And Intrinsic Safe
9-18 <9. TECHNICAL DATA> 9.5 Temperature graphs for RAMC metal design, standard and intrinsic safe Ambient temperature [°C] Ambient temperature [°C] without option /A16 without option /A16 with option /A16 and insulation with option /A16 and insulation with option /A16, no insulation with option /A16, no insulation fig.
Page 91 RAMCxx-xxxx-xxxx-TxxNNN -25°C; -40°C with option /A26 *) RAMC with standard limit switches RAMCxx-xxxx-xxxx-xxxxxx /K1.../K3 -25°C RAMC with fail safe limit switches /K6.../K8 RAMCxx-xxxx-xxxx-xxxxxx /K6.../K8 -25°C; -40°C with option /A26 *) RAMC with fail safe limit switches /K9.../K10 RAMCxx-xxxx-xxxx-xxxxxx /K9.../K10 -25°C RAMCxx-xxxx-xxxx-Exx1xx -25°C...
Page 92 9-20 <9. TECHNICAL DATA> PRESSURE RATING The pressure relevant temperature limits of the RAMC are: -200 to 370°C for units with SS wetted parts -80 to 130°C for units with PTFE wetted parts. These limits are reduced by metrological boundary conditions (see temperature curves and table).
Page 93: Explosion-Protected Type Instruments
10-1 <10. EXPLOSION-PROTECTED TYPE INSTRUMENTS> 10. Explosion-protected Type Instruments This is only applicable to the countries in European Union. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 94: General
(refer to Technical data, chapter 9). 10.1.2 Flame proof In the RAMC with option /KF1, /EF1, /NF1, /GF1 the transmitter and the limit switches are mounted in a flame proof housing. Wait 2 minutes after switching power off before opening the cover.
Page 95: Intrinsically Safe Atex Certified Components (/Ks1)
Ci [nF] Li [µH] max. ambient temp. [°C] for T6 max. ambient temp. [°C] for T5 max. ambient temp. [°C] for T4 - T1 All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 96: Installation
Rota Yokogawa Ex ia IIC T6 Gb D-79664 Wehr PTB 12ATEX2003 WT-MAG Mat. No. 16-8040 Ui=30V Ii=101mA Pi=1.4W Serial No, xxxxxxxx Li=0.15mH Ci=4.16nF II 2G All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 97: Intrinsically Safe Atex Certified Components For Category 3G (/Ks3)
Ci [nF] Li [µH] max. ambient temp. [°C] for T6 max. ambient temp. [°C] for T5 max. ambient temp. [°C] for T4 - T1 All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 98: Marking
Name plates of electronic transmitter : Rota Yokogawa Ex ic IIC T6 Gc D-79664 Wehr WT-MAG Mat. No. 16-8040 Ui=30V Ii=101mA Pi=1.4W Serial No, xxxxxxxx Li=0.15mH Ci=4.16nF II 3G All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 99: Intrinsically Safe Iecex- Certified Components (/Es1)
For example the type KFA6-SR2-Ex... (option (W2_) according certificate IECEx PTB 11.0031 (230V AC supply) or the type KFD2-SR2-Ex... (option (W4_) according certificate IECEx PTB 11.0032 (24V DC supply) can be used. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E...
Page 100: Installation
Rota Yokogawa Ex ia IIC T6 Gb D-79664 Wehr IECEx PTB 12.0020 WT-MAG Mat. No. 16-8040 Ui=30V Ii=101mA Pi=1.4W Serial No, xxxxxxxx Li=0.15mH Ci=4.16nF All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 101: Intrinsically Safe Iecex- Components For Category 3G (/Es3)
For example the type KFA6-SR2-Ex... (option (W2_) according certificate IECEx PTB 11.0031 (230V AC supply) or the type KFD2-SR2-Ex... (option (W4_) according certificate IECEx PTB 11.0032 (24V DC supply) can be used. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E...
Page 102: Marking
Used standards: - ABNT NBR IEC 60079-0: 2008 - ABNT NBR IEC 60079-11: 2009 Technical data see IECEx chapter 10.4.1 Installation see IECEx chapter 10.4.2 All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 103: Intrinsically Safe Fm / Csa (Usa + Canada) Components (/Fs1, /Cs1)
Control Equipment Maintenance and repair: WARNING The instrument modification or part replacements by other than authorized representative of Rota Yokogawa is prohibited and will void the approval of FM Approvals. Marking: Name plates of electronic transmitter : IS-Cl.
Page 104 10-12 <10. EXPLOSION-PROTECTED TYPE INSTRUMENTS> Control Drawings: Electronic transmitter intrinsically safe All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 105 07.11.2000 Amann DRAWED WT-MAG 07.11.2000 Slotwinski CKECKED 08.09.06 Rü YOKOGAWA 09.06.06 Rü DWG. No.: 79664 WEHR 8160191 GERMANY UPDATE No. Rev. DATE EDITOR CHECKED All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 106: Limit Switches Option /K1
Maximum Entity Field Wiring Parameters : see CSA drawing 116-0047 on page 10-18 and 10-19 WARNING Only in combination with power supply option /WxA or /WxB. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 107 2010-jun-03 Control Drawing respons. US.DRL change notice 116-0165F approved US.DWR NAMUR SENSORS – FM 150- 1915 Twinsburg norm US.GAP sheet 1 of 8 All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 108 2010-jun-03 Control Drawing respons. US.DRL change notice 116-0165F approved US.DWR NAMUR SENSORS – FM 150- 1915 Twinsburg norm US.GAP sheet 7 of 8 All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 112: Intrinsically Safe Nepsi (China) Certified Ramc (/Ns1)
10-20 <10. EXPLOSION-PROTECTED TYPE INSTRUMENTS> 10.8 Intrinsically safe NEPSI (China) certified RAMC (/NS1) The RAMC with electronic transmitter (-E, -H) with or without limit switches is certified as intrinsic safe unit with NEPSI approval. Certificate Nr. : GYJ101551 Type of protection...
Page 113: Intrinsically Safe Eac (Russia, Belarus, Kazakhstan)Certified Ramc (/Gs1)
<10. EXPLOSION-PROTECTED TYPE INSTRUMENTS> 10.9 Intrinsically safe EAC (Russia, Belarus, Kazakhstan) certified RAMC (/GS1) The RAMC with electronic transmitter (-E, -H) with or without limit switches is certified as intrinsic safe unit with EAC approval. Certificate Nr. : RU С-DЕ.ГБО8.В.00317...
Page 114: Flame Proof And Dust Proof Atex Certified Ramc (/Kf1)
10-22 <10. EXPLOSION-PROTECTED TYPE INSTRUMENTS> 10.10 Flame proof and dust proof ATEX certified RAMC (/KF1) 10.10.1 Technical data Certificate : IBExU 05 ATEX 1086 Flame proof : Ex d IIC T6 Gb Dust proof : Ex tb IIIC TX Db Max.
Page 115: Installation
100°C. Cable glands and entry fittings (screwed conduit entries) as well as stopping plugs of simple design may not be used. On connection of the RAMC /KF1 using a conduit entry approved for the purpose, the associated sealing facility must be arranged directly on the housing.
Page 116: Flame Proof And Dust Proof Iecex Certified Ramc (/Ef1)
On extension (option /A16) On extension (option /A16) and thermal insulation 85°C 85°C 85°C 100°C 100°C 100°C 120°C 135°C 135°C 120°C 200°C 200°C 120°C 300°C 300°C 120°C 370°C 350°C All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 117: Installation
100°C. Cable glands and entry fittings (screwed conduit entries) as well as stopping plugs of simple design may not be used. On connection of the RAMC /EF1 using a conduit entry approved for the purpose, the associated sealing facility must be arranged directly on the housing.
Page 118: Intrinsically Safe Atex Certified Components In Dust Proof Ramc-Housing (/Ks2)
See chapter 10.10 CAUTION RAMC with /A5 (threads for cable gland 1/2´´NPT) are delivered without cable glands. Please install suitable cable glands or blind stopper according to the dust category where the flowmeter is installed. 10.13 Intrinsically safe IECEx certified components in...
Page 119: Flame Proof And Dust Proof Nepsi (China) Certified Ramc (/Nf1)
100°C. Cable glands and entry fittings (screwed conduit entries) as well as stopping plugs of simple design may not be used. On connection of the RAMC /NF1 using a conduit entry approved for the purpose, the associated sealing facility must be arranged directly on the housing.
Page 120: Operation
The instrument modification or parts replacement by other than authorized representatives of YOKOGAWA is prohibited and will void the certification. WARNING If the window of the cover is damaged the RAMC must be set out of operation. 10.15 Flame proof EAC (Russia, Belarus, Kazakhstan) cer- tified RAMC (/GF1) 10.15.1 Technical data...
Page 121: Instructions For Ped
ID-No. 0038 IMPORTANT The user is responsible for the use of our flowmeters regarding suitability and use as agreed. PED-Data on RAMC 0038 F110.EPS All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 122 <11. INSTRUCTIONS FOR PED> Dependence of the permissible max. effective pressure of the operating temperature: The pressure relevant temperature limits of the RAMC are: -200 to 370°C for units made from 1.4571/1.4404. -80 to 130°C for units made from PTFE.
Page 123 The connection measurements of the flanges remain the same. That means that DIN and EN fit one to another. The facing of the flanges has changed. This may effect the gaskets. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E...
Page 125 Any repair, modification or supplements or the installation of spare-parts is only permitted if it is done in accordance to this instruction manual. Other work must be agreed by YOKOGAWA beforehand. YOKOGAWA will not take over any liability for damages caused by unauthorized work on the instrument or prohibited usage of the instrument.
Page 127: Appendix 1. Software Change History
HART parameter „Detailed Setup / Device information / Revision #´s / FW rev.: x.xx (e.g.x.xx = 5.00), see also chapter 7.4.4 in HART- communicator All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B02-00E-E 12th edition October 01, 2014 -00...
Page 129: Appendix 2. Safety Instrumented Systems Installation
This document provides an overview of the user responsibilities for installation and operation of the Rota Yokogawa RAMC variable area flow meter in order to maintain the designed safety level. Items that will be addressed are proof testing, repair and replacement of the flow meter, reliability data, lifetime, environmental and application limits, and parameter settings.
Page 130: A2.2.2 Diagnostic Response Time
Perform a two-point calibration of the variable area flow meter RAMC Force the variable area flow meter RAMC to go to the high alarm current output and verify that the analog current reaches that value. Note: it is only possible to set RAMC to the high alarm current mode via HART communication! This tests for compliance voltage problems such as a low loop power supply voltage or increased wiring resistance.
Page 131: A2.2.5 Repair And Replacement
Maintenance information can be found in section 8, Maintenance of the User’s Manual Model RAMC Short Stroke ROTAMETER, IM 01R01B02-00E-E. If repair is to be performed with the process online the Rota Yokogawa RAMC variable area flow meter will need to be bypassed during the repair. The user should setup appropriate bypass procedures for that.
Page 132: A2.2.11 Environmental Limits
Manual, Model RAMC Short Stroke ROTAMETER IM 01R01B02-00E-E. A2.2.12 Application limits The application limits of the Rota Yokogawa RAMC variable area flow meter are specified in the User’s Manual, Model RAMC Short Stroke ROTAMETER, IM 01R01B02-00E-E. If the flow meter is used outside of the application limits the reliability data listed in A2.2.9 becomes invalid.
Page 133: A2.4 Assessment Results
A2.4 Assessment results A2.4.1 Safety related parameters The following results have been obtained from the assessment report Report No.: ROTA YOKOGAWA 05/04- 20 R001 Version V4, Revision R1; August 2010 issued by exida. Average PFD values have been calculated assuming a Diagnostic Coverage (DC) of 99%, a mission time of 10 years and a Mean Time To Restoration of 24 hours.
Page 134 A2-6 <A2. SAFETY INSTRUMENTED SYSTEMS INSTALLATION> Table A2.24: Summary for RAMC ([V2]) with 4-20mA output – Failure rates Profile 2 Profile 4 Fail Safe Detected (λSD) 0 FIT 0 FIT Fail Safe Undetected (λSU) 60 FIT 60 FIT Fail Dangerous Detected (λDD)
Page 136 Rotameter is a trademark of Rota Yokogawa GmbH & Co. KG, a subsidiary of Yokogawa Electric Corporation, Japan. In the United Kingdom Rotameter is a trademark of Emerson Electric Co. All Rights Reserved. Copyright © 2003, Rota Yokogawa...

YOKOGAWA RAMC User Manual

1 Introduction

2 Precautions

3 Installation

4 Start of Operation

5 Limit Switches (Option /K[])

6 Electronic Transmitter (-E)

7 HART ® - Communication

8 Service

9 Technical Data

10 Explosion-Protected Type Instruments

11 Instructions for PED

Appendix 1. Software Change History

APPENDIX 2. Safety Instrumented Systems Installation

A2.1 Scope and Purpose

A2.2 Using RAMC for a SIS Application

A2.3 Definitions and Abbreviations

A2.4 Assessment Results

Quick Links

Troubleshooting

Need help?

Questions and answers

Related Manuals for YOKOGAWA RAMC

Summary of Contents for YOKOGAWA RAMC

Table of Contents
