User´s
Manual
IM 01R01B30-00E-E
Model RAKD
Small Metal ROTAMETER
Rota Yokogawa GmbH & Co. KG
Rheinstr. 8
D-79664 Wehr
Germany
IM 01R01B30-00E-E
©
Copyright 2003 (Rü)
6th edition, October 2014 (Rü)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RAKD series and is the answer not in the manual?

Questions and answers

Related Manuals for YOKOGAWA RAKD series

Summary of Contents for YOKOGAWA RAKD series

  • Page 1 Model RAKD User´s Manual Small Metal ROTAMETER IM 01R01B30-00E-E Rota Yokogawa GmbH & Co. KG IM 01R01B30-00E-E © Rheinstr. 8 Copyright 2003 (Rü) D-79664 Wehr 6th edition, October 2014 (Rü) Germany...
  • Page 2 Blank Page...

  • Page 3: Table Of Contents

    4.1 Hints on flow rate measurement ..............4-1 4.2 Pulsation and pressure shock ...............4-1 4.3 Start of operation of electronic transmitter ..........4-1 5. Limit switches (Option /K1 to /K10) ................5-1 All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 4 8.5 Dust proofed limit switches (ATEX) (/KS2) ..........8-9 8.4 Intrinsically safe INMETRO certified RAKD (/US1) ........8-10 8.5 Intrinsically safe "ic" RAKD for Category 3G (ATEX /IECEx) (/KS3, /ES3) 8-11 All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014-00...
  • Page 5 A1.3 Definitions and Abbreviations ..............A1-4 A1.3.1 Definitions ......................A1-4 A1.3.2 Abbreviations ....................A1-4 A1.4 Assessment results ..................A1-5 A1.4.1 Safety related parameters ................A1-5 All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 6: Im 01R01B30-00E-E 6Th Edition October 01,

    <CONTENTS> Blank Page All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014-00...

  • Page 7: Introduction

    Yokogawa for repairs and EXPLOSION PROTECTED RAKD” . The de- modifications. scription in Chapter 8 is prior to other descrip- tions in this instruction manual. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 8 • reason of force measure such as fires, earthquakes, storms/ floods, thunder/lightning, or other reasons not attributable to the instrument in question. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 9: General Description

    YOKOGAWA service centre or sales office. Please describe any defect precisely and indicate model code as well as com. no. number. YOKOGAWA refuses any liability for units which have been repaired by the user without prior consent and do not meet the specifications as a consequence..

  • Page 10: Overview

    Li= 0.73mH Ci= 2.4nF Limit switch Limit Switch: SC2-N0 KEMA 00ATEX 1037X Ex-data limit switch Ex ia IIC T6 see certificate for data F12.EPS All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 11: Precautions

    3-2 and tables 7-2 to 7-5 must be regarded. The minimum ambient temperature is -25°C. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 12 (e.g. by valve). *: Position numbers are illustrated in the explosion drawings in chapter 6. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 13: Installation

    The load resistance of metering or indicating instruments, which are connected serial to the current output, may not exceed (U- 13.5 V) / 20 mA . All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 14 L = 97mH KEMA 00ATEX 1037X PTB 00ATEX 2081 F3.EPS Fig. 3-2 RAKD with 2 limit switches in combination with transmitter relay in Ex- version All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 15 Limit switch MAX, upper MIN (/K9) Lower connector 1 (+) 2 (-) /K1, /K3, /K6, /K8, /K9, /K10 Limit switch MIN, lower MAX (/K10) All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 16 - Slide the rubber seal as far as the rim of the insulation and then slide the cap onto the rubber seal. This provides the strain relief for the conductor (fig. 3-5). All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E...
  • Page 17 (IDC connection system). F9.EPS All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 18: Conductor M12 Connection (Option /A29 Or /A30)

    K10: upper switch, e.g. MIN MAX ==> MAX Lower connector 1 (+) 2 (-) Electronic transmitter, 4-20 mA supply Lower connector 3 (+) 4 (-) Electronic transmitter, pulse output (option /CP) All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 19: Start Of Operation

    Switch on the power supply.. The RAKD is now ready for operation.. The transmitter is prepared and calibrated according to its model code as a 2 wire unit. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 20 <4. START OF INSTALLATION> Blank Page All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 21: Limit Switches (Option /K1 To /K10)

    If other transmitter relays are used as the above mentioned types, the transmitter relay has to be applied as protection technology to ensure functional safety. Please notice chapter 7.2 "Standard specifications". For questions regarding protection technology, please consult your YOKOGAWA service center. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E...
  • Page 22 <5. LIMIT SWITCHES OPTION /K1 TO /K10> Blank Page All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 23: Service

    Assembling the float take care that the lower guide bar of the float is fixed in the middle boring of the lower stop. The guide bar should not be bended. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E...

  • Page 24: Explosion Drawings

    Controller Tube for unit without valve and controller F61.EPS Fig. 6-1 RAKD without valve and controller F62.EPS Fig. 6-2 RAKD with valve and controller All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 25: Electronic Transmitter

    Establish the small cover and fix the scale with the screw. Final actions: · Fix the cover of the indicator. · Switch power on. · Check the unit for a faultless function. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 26: Troubleshooting

    Precision problems with "T" unit: execute test acc. fig. 6-3 If the indicated countermeasure do not remedy the fault or in case of troubles which cannot be remedied by the user, please contact your YOKOGAWA service centre. F63.EPS Fig. 6-3 All Rights Reserved.

  • Page 27: Template For Sending Back To Service

    In case a RAKD has to be sent for repairs or checking to our service, please observe the following: Due to legislation for the protection of the environment and for the safety of our staff, YOKOGAWA may only ship, repair and check sent devices on the condition that this does not constitute any risk to environment and staff.
  • Page 28 Name Date Signature All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 29: Technical Data

    7.1 RAKD Type-, Suffix-codes and Options RAKD with valve and controller (option /R1 and /R3) 1.0 - 100 l/h water / 40 - 3250 l/h air All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 30 <7. TECHNICAL DATA> RAKD with valve 1.0 - 250 l/h water / 40 - 8000 l/h air All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 31 <7. TECHNICAL DATA> RAKD without valve 1.0 - 100 l/h water / 40 - 3250 l/h air All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 32 <7. TECHNICAL DATA> RAKD without valve 160 - 250 l/h water / 5000 - 8000 l/h air All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 33 Special design must be specification on extra sheet *) if no instruction manual is selected, only a DVD with instruction manuals is shipped with the flowmeter All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 34: Standard Specifications

    4 - 20 mA ELECTRICAL CONNECTION (Indicator/Code -E) : Type Quickon Cable diameter 4 – 6 mm Maximum cross section of core Ø 0.34 to 0.75 mm All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 35 /W2F or /W4F must be selected. Signal Function Pointer SJ2-S1N above LV 1 mA below LV 3 mA Fail Safe 1 mA Note: LV = Limit value All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 36 Option /QR1 is for Russia. Option /QR2 is for Kazakhstan. Option /QR3 is for Uzbekistan. For the Ukraine the test certificate of Rota Yokogawa is sufficient. Therefore no special option exists. For Belorussia Rota Yokogawa has no “Pattern Approval Certificate” , that means devices which need primary verification should be calibrated in Belarus by Belorussian special bod- ies.
  • Page 37 - IECEx PTB 11.0091X ( SC2-NO) for /K1 to /K3 Entity parameter : - IECEx PTB 11.0092X (SJ2-S.N) for /K6 to /K10 see table 6 Temperature specification : see table 7 All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 38 Option /KS1 must be selected. PESO- certificate is available at your Yokogawa Sales Office. RAKD with KOSHA- certification (Korea) Option /ES1 must be selected. Same data as for IECEx certification. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 39 Output signal : 4 - 20 mA Control circuit : Intrinsically safe [Ex ia] IIC; group II ; category (1)GD Entity parameters : see fig. 5 All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 40: Dimensions And Weights

    7.3 Dimensions and weights F8.EPS F7.EPS Fig. 7-2 Version without valve Fig. 7-3 Version with flange connection F13.EPS Fig. 7-4 Back view with mounting All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 41 7-13 <7. TECHNICAL DATA> Cutting ring F9.EPS Fig. 7-5 Version with inlet valve Cutting ring F12.EPS Fig. 7-6 Version with outlet valve All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 42 G or NPT thread approx. 135 approx. 113 approx. 60 Cutting ring F11.eps ENG-018555 Fig. 7-8 Version with outlet valve and back pressure controller All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 43 8 mm 182 mm ------ 56.5 mm 166 mm WEIGHTS TABLE 7-14 without valve with valve with controller Weight approx. 600g approx. 1000g approx. 1800g All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 44: Temperature Curves

    For option /NS1 (Ex-i-version NEPSI) the maximum values for ambient and process temperature according to the respective temperature class mentioned in table 11 must be regarded. The minimum ambient temperature is -25°C. Lower temperatures on request. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 45: Explosion-Protected Type Instruments

    <8. EXPLOSION-PROTECTED TYPE INSTRUMENTS> 8. Explosion-protected Type Instruments This is only applicable to the countries in European Union. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 46: General

    (refer to Technical data, section 7). To ensure intrinsically safety, it is not permitted to repair or modify the measuring transmitter. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 47: Intrinsically Safe Atex Certified Rakd (/Ks1)

    = 64 mW 169 mW Inner inductance: = 0.15 mH 0.15 mH = 0.1 mH 0.1 mH Inner capacity: = 150nF 150nF = 30nF 30nF All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 48 For example the type KFA6-SR2-Ex... (option (W2_) according certificate PTB 00 ATEX 2081 (230V AC supply) or the type KFD2-SR2-Ex... (option (W4_) according certificate PTB 00 ATEX 2080 (24V DC supply) can be used. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 49: Installation

    Fig. 8-2 Ex-Version acc. ATEX (Option /KS1) with electronic transmitter in combination with power supply and additional limit switch or pulse output with transmitter relay All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 50: Intrinsically Safe Iecex Certified Rakd (/Es1)

    = 64 mW 169 mW Innere Induktivität: = 0.15 mH 0.15 mH = 0.1 mH 0.1 mH Innere Kapazität: = 150nF 150nF = 30nF 30nF All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 51 For example the type KFA6-SR2-Ex... (option (W2_) according certificate IECEx PTB 11.0031 (230V AC supply) or the type KFD2-SR2-Ex... (option (W4_) according certificate IECEx PTB 11.0034 (24V DC supply) can be used. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E...

  • Page 52: Installation

    Fig. 8-4 Ex-Version acc. IECEx (Option /ES1) with electronic transmitter in combination with power supply and additional limit switch or pulse output with transmitter relay All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 53: Intrinsically Safe Inmetro Certified Rakd (/Us1)

    Used standards: - ABNT NBR IEC 60079-0: 2008 - ABNT NBR IEC 60079-11: 2009 Technical data see IECEx chapter 8.3.1 Installation see IECEx chapter 8.3.2 All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 54: Intrinsically Safe "Ic" Rakd For Category 3G (Atex /Iecex) (/Ks3, /Es3)

    = 64 mW 169 mW Innere Induktivität: = 0.15 mH 0.15 mH = 0.1 mH 0.1 mH Innere Kapazität: = 150nF 150nF = 30nF 30nF All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 55: Intrinsically Safe Fm / Csa (Usa + Canada) Components (/Fs1, /Cs1)

    Maximum Entity Field Wiring Parameters : see CSA drawing 116-0047 on page 8-14 and 8-15 WARNING Only in combination with power supply option /WxA or /WxB. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 56 2010-jun-03 Control Drawing respons. US.DRL change notice 116-0165F approved US.DWR NAMUR SENSORS – FM 150- 1915 Twinsburg norm US.GAP sheet 1 of 8 All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 57 2010-jun-03 Control Drawing respons. US.DRL change notice 116-0165F approved US.DWR NAMUR SENSORS – FM 150- 1915 Twinsburg norm US.GAP sheet 7 of 8 All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 58 8-14 <8. EXPLOSION-PROTECTED TYPE INSTRUMENTS> FM: Limit switches non incendive All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 59 8-15 <8. EXPLOSION-PROTECTED TYPE INSTRUMENTS> CSA: limit switches intrinsically safe (1) All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 60 8-16 <8. EXPLOSION-PROTECTED TYPE INSTRUMENTS> CSA: limit switches intrinsically safe (2) All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 61: Intrinsically Safe Nepsi (China) Certified Rakd (/Ns1)

    Pi [mW] Li [µH] Ci [nF] Max. ambient temperature for T6 [°C] Max. ambient temperature for T5 [°C] Max. ambient temperature for T4-T1 [°C] All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 62: Intrinsically Safe Eac (Russia, Belarus, Kazakhstan) Certified Rakd (/Gs1)

    100°C type 2 73°C 135°C 24°C 65°C 37°C 80°C Indicator "T" 34°C 100°C with limit switch(es) 57°C 80°C type 3 54°C 100°C 48°C 135°C All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 63: Appendix 1. Safety Instrumented Systems Installation

    This document provides an overview of the user responsibilities for installation and operation of the Rota Yokogawa RAKD variable area flow meter in order to maintain the designed safety level. Items that will be addressed are proof testing, repair and replacement of the flow meter, reliability data, lifetime, environmental and application limits, and parameter settings.

  • Page 64: A1.2.2 Diagnostic Response Time

    Maintenance information can be found in section 6, Maintenance of the User’s Manual Model RAKD Small Metal ROTAMETER, IM 01R01B30-00E-E. If repair is to be performed with the process online the Rota Yokogawa RAKD variable area flow meter will need to be bypassed during the repair. The user should setup appropriate bypass procedures for that.

  • Page 65: A1.2.6 Startup Time

    The expected lifetime of the Yokogawa Rota Yokogawa RAKD variable area flow meter is 10 years. The reliability data listed in 2.7 is only valid for this period. The failure rates of the Rota Yokogawa RAKD variable area flow meter may increase sometime after this period. Reliability calculations based on the data listed in A1.2.7 for Rota Yokogawa RAKD variable area flow meter lifetimes beyond 10 years may yield results that...

  • Page 66: A1.3 Definitions And Abbreviations

    IEC 61508-4. A1.3.2 Abbreviations FMEDA Failure Mode, Effects and Diagnostic Analysis Safety Instrumented Function Safety Integrity Level Safety Instrumented System Safety Lifecycle All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...

  • Page 67: A1.4 Assessment Results

    A1.4 Assessment results A1.4.1 Safety related parameters The following results have been obtained from the assessment report Report No.: ROTA YOKOGAWA 08/07-23 R002 Version V2, Revision R1; August 2010 issued by exida. Average PFD values have been calculated assuming a Diagnostic Coverage (DC) of 99%, a mission time of 10 years and a Mean Time To Restoration of 24 hours.
  • Page 68 8.80E-08 1/h 1.58E-07 1/h T[Proof] = 1 year T[Proof] = 5 years T[Proof] = 10 years PFDAVG = 4.01E-04 PFDAVG = 1.86E-03 PFDAVG = 3.68E-03 All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 69 1.68E-07 1/h 2.57E-07 1/h T[Proof] = 1 year T[Proof] = 5 years T[Proof] = 10 years PFDAVG = 7.83E-04 PFDAVG = 3.63E-03 PFDAVG = 7.18E-03 All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 70 7 The switching contact output is connected to a standard switching amplifier (e.g. Pepperl+Fuchs KF**- SR2-Ex*.W). The failure rates of the amplifier are not included in the listed failure rates. All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E...
  • Page 71 Blank Page All Rights Reserved. Copyright © 2003, Rota Yokogawa IM 01R01B30-00E-E 6th edition October 01, 2014 -00...
  • Page 72 Rotameter is a trademark of Rota Yokogawa GmbH & Co. KG, a subsidiary of Yokogawa Electric Corporation, Japan. In the United Kingdom Rotameter is a trademark of Emerson Electric Co. All Rights Reserved. Copyright © 2003, Rota Yokogawa...
