Billion VoIP ADSL Modem/Router BIPAC 7100SV Quick Start Manual

Voip adsl modem/router
Hide thumbs Also See for VoIP ADSL Modem/Router BIPAC 7100SV:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
BIPAC 7100SV
VoIP ADSL Modem/Router
Quick Start Guid

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VoIP ADSL Modem/Router BIPAC 7100SV and is the answer not in the manual?

Questions and answers

Related Manuals for Billion VoIP ADSL Modem/Router BIPAC 7100SV

Summary of Contents for Billion VoIP ADSL Modem/Router BIPAC 7100SV

  • Page 1 BIPAC 7100SV VoIP ADSL Modem/Router Quick Start Guid...

  • Page 3: Package Contents

    For more detailed instructions on configuring and using the VoIP ADSL Modem/Router, please refer to the on-line manual. Package Contents BIPAC 7100SV ADSL Modem/Router CD-ROM containing the online manual RJ-11 ADSL/telephone Cable Ethernet (CAT-5 LAN) Cable AC-DC power adapter (12VDC, 1.2A) This Quick Start Guide Do not use the BIPAC 7100SV in high humidity or high temperatures.

  • Page 4: The Front Leds

    Quick Start Guide The Front LEDs Power Phone ADSL Lit when power is ON Lit when the system is ready Lit green when the phone is off hook Lit green when the LAN link is connected. When lit, it indicates that the ADSL (Line) port is connected to the DSLAM and working properly.

  • Page 5: The Rear Ports

    The Rear Ports Port Power Switch Power ON/OFF switch RESET VoIP (RJ-45 connector) LINE (RJ-11 connector) Billion BIPAC 7100SV VoIP ADSL Modem/Router Connect the supplied power adapter to this jack. Press it to restore the factory default setting back. Connect RJ-11 cable to this port when connecting to an analog phone set.

  • Page 6: Connecting Your Adsl Router

    Quick Start Guide Connecting Your ADSL Router 1. Connect the Router to a LAN (Local Area Network) and the ADSL/telephone (LINE) network. 2. Power on the device. 3. Make sure the PWR and SYS LEDs are lit steadily and that the LAN LED is lit. 4.

  • Page 7: Configuring Pc In Windows Xp

    Configuring PC in Windows XP 1. Go to Start / Control Panel (in Classic View). In the Control Panel, double-click on Network Connections 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window, click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties.

  • Page 8: Configuring Pc In Windows 2000

    Quick Start Guide Configuring PC in Windows 2000 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window click Properties. 4.

  • Page 9: Configuring Pc In Windows 98/Me

    Configuring PC in Windows 98/Me 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab. 2. Select TCP/IP -> NE2000 Compatible, or the name of your Network Interface Card (NIC) in your PC. 3.
  • Page 10 Quick Start Guide Configuring PC in Windows NT4.0 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties. 3. Select the Obtain an IP address from a DHCP server radio button and click OK.
  • Page 11 Configuring Your VoIP ADSL Router To configure this device, you must have IE 5.0 / Netscape 4.5 or above installed Open the web browser and type http://192.168.1.254 address box. This number is the default IP address for this router. Press Enter. 2.
  • Page 12 Quick Start Guide The parameters are different among different Encapsulations or access methods. The most common are PPPoE and PPPoA. 5. Click Submit to activate all configurations. But if you need this configuration, please click the “Save Config” in the left pane to save the configuration.
  • Page 13 Billion BIPAC 7100SV VoIP ADSL Modem/Router Verifying Your Local Network Connection with the Device To see if this ADSL Router is visible on the local network, go to Start / Run. In the Run dialog box, type “ping 192.168.1.254” then press OK. A command prompt window will pop out.

  • Page 14: Product Support And Contact Information

    Quick Start Guide Product Support and Contact Information Most problems can be solved by referring to the Troubleshooting section in the User’s Manual. If you cannot resolve the problem with the Troubleshooting chapter, please contact the dealer where you purchased this product. Contact Billion WORLDWIDE http://www.billion.com...
