50N1 Zone 1 residual instantaneous-overcurrent (0.25-50,000 primary amperes)
Zone 2 residual instantaneous-overcurrent (0.25-50,000 primary amperes)
50N2
50N3 Zone 3 residual instantaneous-overcurrent (0.25-50,000 primary amperes)
Zone 1 delay for ground faults (0-60 cycles in quarter cycle steps)
Z1DG
Z2DG Zone 2 delay for ground faults (0-2000 cycles in quarter cycle steps)
Z3DG Zone 3 delay for ground faults (0-2000 cycles in quarter cycle steps)
TDUR Minimum Trip Duration timer (0-2000 cycles in quarter cycle steps)
52BT 52B time delay (0.5 to 10,000 cycles in quarter cycle steps)
ZONE3 Zone 3 direction (F = forward or R = reverse)
67NE Do you want directional torque control for the residual instantaneous-overcurrent
67PE
Do you want directional torque control for the phase instantaneous-overcurrent
32QE Do you want negative-sequence directional supervision of the ground-overcurrent
32IE Do you want zero-sequence current-polarization for the directional element
TIME1 Timeout for PORT 1 (0-30 minutes)
TIME2 Timeout for PORT 2 (0-30 minutes)
AUTO Autoport (PORT 1 or 2, or 3 for both PORTS 1 and 2)
RINGS The number of rings after which the modem connected to PORT 1 answers (1-30
Refer to the functional description and be sure the settings you choose result in relay
performance appropriate to your application.
As you enter settings, they are compared with setting limits above. Then the relay computes
internal settings from your entries and checks to ensure that they fall within the specified
range.
For example, let CTR= 1000 and 50N1 = 1. Each of these settings is admissible alone, but
together they result in a secondary pickup setting of 1 mA, which is out of range. Internal
setting error messages indicate out-of-range settings after you enable the new settings (refer to
the Specifications for the secondary ranges of the relay elements).
The AUTO setting selects PORT 1, 2, or both of the two serial ports for automatically
transmitted messages. The table below shows the effect of each possible setting:
3-22
elements? (Y or N)
elements? (Y or N)
elements? (Y or N)
enabled? (Y or N)
rings)
Auto
Setting
1
2
3
Commands and Serial Communication
SEL-267D/167D Instruction Manual
Automatic Message
Destination Port
1
2
1 and 2
Date Code 920326
