Symcod V3+ Manual page 9

IP Bridge V3/V3+
Command listing
for Bridge 400 mode
With BoardConfig software you can activate Bridge 400 option and use these
commands:
Output number
Output x ON/OFF
><Txy
x = Output number 1 to 4
y = E for or D for
ON
Sequence example, set Relay 2 to ON:
Output x ON during XX second(s)
><TxTyy
x = Output number 1 to 4
yy = Delay
(Two digits from .1 to 99)
Sequence example, set relay 2 to ON during 4 seconds:
Enable or disable the batch mode
><B,Delay,Relay1,Relay2,Buzzer1,Buzzer2
Delay = Delay in seconds (1 to 9) that the PC have to read a Barcode.
*Utiliser 0 pour désactiver le mode Batch.
Relay1 = Delay in seconds (01 to 99) during which the relay 1 will remain open.
Relay2
= Delay in seconds (01 to 99) during which the relay 2 will remain open.
Buzzer1 = Delay in seconds (01 to 99) during which the buzzer 1 will remain open.
Buzzer2 = Delay in seconds (01 to 99) during which the buzzer 1 will remain open.
The computer has
Example:
open for
seconds and Buzzer 2 will remain closed
Logic input #1 (Counter mode):
><T1C Set logic input to counter mode
><T1Bxxx "Debouncing" configuration
xxx= Minimum delay between 2 pulses
Bridge V2 & V2+
If xxx = 001 the delay is 0.003 sec between 2 pulses.
xxx= (1/NbPulseBySec)/0.0015
><T1N Set logic input to normal mode
><T1I Initialize counter value to zero
><T1R Request counter value
On this command the bridge return: CPT: [VALUE][Return]
Example:
Bridge V2 & V2+
* Maximum pulses per seconds: 500
* Possible counter values: 0 to 3, 4E+38
WWW.SYMCOD.COM
Description
1
2
3 Buzzer 1
4 Buzzer 2
or R for
OFF REQUEST STATUS, LOGIC INPUT # 1 or 2
(Supported by version 2.2Y and more)
9 seconds to respond, after that delay; Relay 1 will be
03 seconds, Relay 2 during
CPT:1238
Relay 1
Relay 2
><T2E
><T2T04
:
.4 seconds, Buzzer 1 during
><B,9,03,.4,05,00
:
(3 digits obligatory)
Bridge V3 & V3+
If xxx = 001 the delay is 0.0003 sec between 2 pulses.
xxx= (1/NbPulseBySec)/0.00015
Bridge V3 & V3+
* Maximum pulses per seconds: 3000
* Possible counter values: 0 to 4294967295
05
9
