IP Bridge V3/V3+
1. Insert a small flat screwdriver in the opening (square) of the corresponding wire.
2. Insert the wire into the round opening.
3. Remove the screwdriver and pull lightly the wire to make sure that it is properly
attach.

Ethernet port

Ethernet Activity DEL (Yellow)
GND input DC injector
12 V DC input DC injector
Ethernet pin out (connects only at 10 Megabits)
The IP Bridge communicates through an Ethernet 100BaseT network.
connector is a standard RJ-45 type. It as 2 LED's, the green one shows the active link
with the network and the yellow one shows the activity. The IP Bridge can be powered
by an individual power supply, a single or 16 ports DC-Injector (use only SYMCOD DC-
Injector). As all the standard 100BaseT Ethernet devices, it uses a UTP CAT5 cable. A
maximum length of 300 feet (91.44 meters) is allowed between the HUB or the SWITCH
and the Bridge/IP. For more information on cabling issue, please download «
wiring and recommendations TCPIP v.31-03-2005
website at www.symcod.com
WWW.SYMCOD.COM
How to use the connectors JS3, JS4
RX- Ethernet
.
Ethernet Link DEL (Green)
TX+ Ethernet
TX- Ethernet
RX+ Ethernet
» available free of charge on our
The
Ethernet
18
