IP Bridge V3/V3+

Main Characteristics

MODEL
Product # DESCRIPTION
IP Bridge
020-01071 V3 w/o power
020-01072 V3+ w/o power
020-01075 V3 with 9V power supply 1
V3+ with 9V power
020-01077
supply
1
The "Virtual serial port" driver can be used to create a Virtual Serial port (RS-232 COMx).
2
The number of bits must be specified at the order. A standard 26Bits Wiegand card includes:
a facility code from 0 to 255
o
a card identifier 0 to 65535.
o
Symcod can program the Wiegand decoder of the Bridge so only the card identifier will be
transmitted (order product # 020-01348). It is also possible to program the decoder according
to your specifications if you use another type of Wiegand format (ex: 37 Wiegand bits). If you
use the "facility code" and the card identifier, the transmitted code will be combined and will
have to be converted by the software (Method provided by Symcod).
3
A serial port is used by the external biometric reader (biometric reader not included).
4
The buzzer output is normally inactive, it is temporarily activated when a card is read, it is also possible
to control it by software.

Environmental specifications

Product
IP Bridge V3
0.21Kg
0.46lb
IP Bridge V3+
1
Without connectors
WARNING: indoor use only
This equipment is intended for an interior use only.
WWW.SYMCOD.COM
Commu-
Inputs
nication
1 1 1 1 1
1 2 2 2 2
1 1 1 1
1 2 2 2 2
X
11.1cm 7.75cm 3.5cm
4.37po 3.05po 1.38po
X
Logical Logical
inputs outputs
2 1 1 1
2 2 2 2
2 1 1 1
2 2 2 2
X X 0°C
X X 0°C
Input power
with or without
peripheral
125mA 1A 650mA
125mA 1A 650mA
125mA 1A 650mA
125mA 1A 650mA
40°C 85%
40°C 85%
4
