SAFETY, OPERATION & MAINTENANCE
•
CAUTION – READ THE INSTRUCTION MANUAL BEFORE USING THE APPLIANCE
•
ORIGINAL INSTRUCTIONS
•
MANUAL ALSO AVAILABLE ON LINE AT
Endeavor Manual 1/11/16
Endeavor
CARPET SOIL EXTRACTOR
INSTRUCTIONS
MODELS:
SX9000 ENDEAVOR
SX9500 ENDEAVOR 500
WWW.PROCHEM.CO.UK
Page 1 of 35

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Endeavor Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Prochem Endeavor Series

Summary of Contents for Prochem Endeavor Series

  • Page 1 SAFETY, OPERATION & MAINTENANCE INSTRUCTIONS MODELS: SX9000 ENDEAVOR SX9500 ENDEAVOR 500 • CAUTION – READ THE INSTRUCTION MANUAL BEFORE USING THE APPLIANCE • ORIGINAL INSTRUCTIONS • MANUAL ALSO AVAILABLE ON LINE AT WWW.PROCHEM.CO.UK Endeavor Manual 1/11/16 Page 1 of 35...
  • Page 2 All information and specifications in this manual are current at the date of issue. However, because of Prochem Europe policy of continual product improvement, we reserve the right to make changes at any time without notice. Please note that this manual applies to all models and explains variations including accessories used.

  • Page 3: Table Of Contents

    CONTENTS PAGE NO. WARRANTY WARNING SECTION IMPORTANT SAFETY INSTRUCTIONS GENERAL DESCRIPTION OF APPLIANCE & IMPORTANT OPERATING INSTRUCTIONS GENERAL OPERATING INSTRUCTIONS UNDERSTANDING YOUR SOIL EXTRACTOR ACCESSORIES & CHEMICALS OPERATING INSTRUCTIONS PRACTICAL CARPET CLEANING GENERAL MAINTENANCE GENERAL FAULT FINDING PARTS DIAGRAMS PARTS LIST PUMP PARTS LIST WAND PARTS LIST HAND TOOL PARTS LIST...
  • Page 4 Prochem Europe Sales Department Telephone: +44 (0)20 8974 1515 Prochem Europe Ltd. EEE Producer Registration Number: WEE / AJ0044SY European Directive (2011/65/EU) Restriction of use of certain Hazardous Substances in Electrical and Electronic Equipment (RoHS2). This equipment does not contain more than the maximum permitted levels by...

  • Page 5: Warranty

    Your Prochem unit is designed to give you many years of reliable service. If a problem should arise during or after the warranty period, contact the Prochem Authorised Distributor or the Prochem Service Department, for details of the services available. Only the original purchaser of the new equipment may seek performance of this warranty –...

  • Page 6: Warning Section

    WARNING! • Warning! Machines shall not be used by children. Children should be supervised to ensure that they do not play with the appliance. This machine can be used by people with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the machine in a safe way and understand the hazards involved.

  • Page 7: Important Safety Instructions

    Please read this manual hoses. carefully and obtain operating instruction from your Prochem Distributor or authorised representative in !! DO NOT use this machine with or near flammable the correct use of this equipment and suitable vapours. These machines can ignite flammable chemicals before attempting to clean.

  • Page 8: General Description Of Appliance

    ! DO NOT use chemicals in the machine other than solution tank. If not properly dissolved, powdered those manufactured or recommended by Prochem cleaning solution may result in damage to the Europe.

  • Page 9: General Operating Instructions

    Prochem. to the pump system, run clean water through the solution lines after each days use. Prochem carpet soil extraction machines have been • designed with the operator in mind. Provided you All repairs must be carried out by an authorised read the instructions relating to the care of your Prochem distributor.

  • Page 10: Understanding Your Soil Extractor

    Rinse tank with at least 10 be forced into the fibres and emulsify the soil litres of hot water, or Prochem deodorising solution. particles before it is extracted by the powerful If there is unused solution in solution tank, close suction of the vacuum motor.

  • Page 11: Accessories & Chemicals

    1 - 4 to 1 - 8 and apply by sprayer. For ALWAYS USE THE HIGH PRESSURE SOLUTION best results, brush into pile using Prochem carpet HOSES SUPPLIED WITH THE MACHINE. pile brush before following up with extraction cleaning process.

  • Page 12: Operating Instructions

    OPERATING INSTRUCTIONS CARPET WAND Important: Use only Prochem wands and hand tools with the Endeavor. They are designed to deliver and maintain the correct amount of solution and pressure when attached to the Endeavor pump system. Use of other manufacturers wands may cause over-wetting of carpet, damage to the pump system and lack of pressure.
  • Page 13 Clean with the upholstery tool using as little solution as possible. Make overlapping passes to prevent streaking. Go over the area you just cleaned without depressing the lever (vacuum only) and gauge the amount of moisture extracted for dryness. On heavily soiled areas like arm rests, pre-treat with a recommended pre-spray. STORAGE AND TRANSPORTATION The machine can be prepared for storage (indoors only), by ensuring the power cord is coiled and secured using the velcro strap provided.

  • Page 14: Practical Carpet Cleaning

    These are all referred to in the Prochem Training Course Manual that is supplied with the course. The speed at which the wand head is drawn back on the cleaning stroke is usually governed by the PREPARATION &...

  • Page 15: General Maintenance

    GENERAL MAINTENANCE All Prochem machines are engineered and built to SOLUTION TANK require a minimum of maintenance. But like any Flush the solution tank and pump through with 10 machine, it does require some care to keep it in litres of hot water. Check the filter and clean if optimum working condition.
  • Page 16 Finding Guide page in this manual and contact your The 220 psi pump is a DC type motor and this unit Prochem Distributor. Although some service parts is fitted with carbon brushes in an end bell kit which are available, we recommend that defective is a replacement part.

  • Page 17: General Fault Finding

    GENERAL FAULT FINDING GUIDE CAUTION - Repairs should only be carried out by a QUALIFIED AND FULLY TRAINED PERSON ! NO POWER With both vacuum and pump switches in the 'on' position, the vacuum and pump will not run. PROBABLE CAUSES CORRECTIVE ACTION Defective power cord Replace power cord...

  • Page 18: Parts Diagrams

    PARTS DIAGRAMS Endeavor Front Endeavor Rear Endeavor Manual 1/11/16 Page 18 of 35...
  • Page 19 Endeavor Side Internal Vacuum Section Endeavor Manual 1/11/16 Page 19 of 35...
  • Page 20 Internal Pump Parts Endeavor Manual 1/11/16 Page 20 of 35...
  • Page 21 Solution Inlet SX9000 220 psi Solution Inlet & Inlet Return SX9500 500 psi Endeavor Manual 1/11/16 Page 21 of 35...
  • Page 22 Relief Valve & Solution Outlet Endeavor Manual 1/11/16 Page 22 of 35...
  • Page 23 500 psi solution set-up Prime valve parts Endeavor Manual 1/11/16 Page 23 of 35...
  • Page 24 Heat n Run Unit Endeavor Manual 1/11/16 Page 24 of 35...

  • Page 25: Parts List

    PARTS LIST STOCK NO PART NO DESCRIPTION G02531-1 Castor (back, top) Bolt (retains handle) EN00711 K00711 Gate Valve E00711-2 K00711-2 Gate Valve Handle E00711RK K00711-1 Seal, Drain Valve EACH Bolt,Hinge Nut,Hinge AC620 620hrp Heat and Run (Endeavor) Blanking Plate (non heat machine) D13350 Axle (top wheels) E02305-1...
  • Page 26 G13748 Pneumatic Stabilising Rod G13435 Ball Mount ,Gas Spring G13436 Ball Socket ,10mm D13437 Eyelet , Gas Spring Bolt Spacer E90001A B13600 Filter EMI-RFI 250V E13723 G13723 Vacuum Motor 2 stage 6.6" 240v E13796-1 G13796-1 8.4” vacuum motor (for SX9500) D13682 Vacuum Mounting Plate E90007-A...
  • Page 27 Vacuum Hose 1 1/2" per ft. CF5201 POWER CONVERTER 240V AC TO 12V DC IA5201 FLOAT SWITCH SET * = Currently awaiting stock code from supplier .Please see future updates on website or contact Prochem service department Endeavor Manual 1/11/16 Page 27 of 35...

  • Page 28: Pump Parts List

    REAR END BELL ASSEMBLY FOR E13639-1 E13803 - 500PSI PUMP 230V AC MOTOR PROCHEM STOCK CODES (All parts listed here are held on stock , for non stock part enquiries please contact Prochem service department ) Diagram Diagram Description Stock Code...
  • Page 29 500PSI PUMP PARTS LIST Endeavor Manual 1/11/16 Page 29 of 35...

  • Page 30: Wand Parts List

    AC1034 WAND PARTS LIST WAND HANDLE PARTS LIST Endeavor Manual 1/11/16 Page 30 of 35...

  • Page 31: Hand Tool Parts List

    HAND TOOL PARTS LIST Endeavor Manual 1/11/16 Page 31 of 35...
  • Page 32 Endeavor Manual 1/11/16 Page 32 of 35...

  • Page 33: Wiring Diagrams

    WIRING DIAGRAMS MODEL SX9000 220 – 240V 50Hz Endeavor Manual 1/11/16 Page 33 of 35...
  • Page 34 MODEL SX9500 220 – 240V 50Hz Endeavor Manual 1/11/16 Page 34 of 35...

  • Page 35: Ce Declaration Of Conformity

    2006/95/EC Low Voltage (LVD) Directive 2004/108/EC Electromagnetic Compatibility (EMC) Directive A Technical file is held by Prochem Europe Ltd. Certificate of compliance and test reports issued by: SGS United Kingdom Ltd. Unit 10, Bowburn South Industrial Estate Bowburn, Durham DH6 5AD...
