Summary of Contents for Prochem Steempro SX2000 POWERFLO
- Page 1 Steempro 2000 CARPET SOIL EXTRACTOR SAFETY, OPERATION & MAINTENANCE INSTRUCTIONS MODELS: SX2000 POWERFLO SX2100 POWERMAX SX2700 POWERPLUS SX2750 POWERPLUS 500 CAUTION – READ THE INSTRUCTION MANUAL BEFORE USING THE APPLIANCE Steempro Manual.doc 1/8/09 Page 1 of 31...
-
Page 2: Machine Data
Website: www.prochem.co.uk All information and specifications in this manual are current at the date of issue. However, because of Prochem Europe policy of continual product improvement, we reserve the right to make changes at any time without notice. Please note that this manual applies to all models and explains variations including accessories used. -
Page 3: Table Of Contents
CONTENTS PAGE NO. WARRANTY IMPORTANT SAFETY INSTRUCTIONS IMPORTANT OPERATING INSTRUCTIONS GENERAL OPERATING INSTRUCTIONS UNDERSTANDING YOUR SOIL EXTRACTOR ACCESSORIES & CHEMICALS CONDENSED OPERATING INSTRUCTIONS PRACTICAL CARPET CLEANING GENERAL MAINTENANCE GENERAL FAULT FINDING PARTS DIAGRAM SX2000 / SX2100 UPPER PARTS LIST SX2000 / SX2100 UPPER PARTS DIAGRAM SX2000 / SX2100 BASE PARTS LIST SX2100 / SX2000 BASE PARTS DIAGRAM SX2700 / SX2750 UPPER... - Page 4 Prochem Europe Sales Department Telephone: +44 (0)20 8974 1515 Prochem Europe Ltd. EEE Producer Registration Number: WEE / AJ0044SY European Directive (2002/95/EC) Restriction of use of certain Hazardous Substances in Electrical and Electronic Equipment (RoHS). This equipment does not contain more than the maximum permitted levels by...
-
Page 5: Warranty
Your Prochem unit is designed to give you many years of reliable service. If a problem should arise during or after the warranty period, contact the Prochem Authorised Distributor or the Prochem Service Department, for details of the services available. -
Page 6: Important Safety Instructions
Please read this manual carefully and obtain operating instruction from your !! DO NOT use this machine with or near flammable Prochem Distributor or authorised representative in vapours. These machines can ignite flammable the correct use of this equipment and suitable vapours such as fuels, solvents or thinners. -
Page 7: Important Operating Instructions
! DO NOT use chemicals in the machine other than solution tank. If not properly dissolved, powdered those manufactured or recommended by Prochem cleaning solution may result in damage to the Europe. -
Page 8: General Operating Instructions
Prochem. to the pump system, run clean water through the solution lines after each days use. Prochem carpet soil extraction machines have been • designed with the operator in mind. Provided you All repairs must be carried out by an authorised read the instructions relating to the care of your Prochem distributor. -
Page 9: Understanding Your Soil Extractor
Rinse tank with at least 10 delivers just the right amount of solution to the litres of hot water, or Prochem deodorising solution. carpet. The solution has a short amount of time to If there is unused solution in solution tank, close be forced into the fibres and emulsify the soil drain valve, then switch on the vacuum. -
Page 10: Accessories & Chemicals
Dilute with warm STEEMPRO MACHINE. water at 1 - 4 to 1 - 8 and apply by sprayer. For best results, brush into pile using Prochem carpet STAINLESS STEEL UPHOLSTERY TOOL pile brush before following up with extraction A lightweight stainless steel cleaning tool that, with cleaning process. -
Page 11: Condensed Operating Instructions
CARPET WAND Previously shampooed carpets may have a heavy build-up of old shampoo residue which Important: Use only Prochem wands and hand can cause the vacuum system to ingest foam tools with the Steempro 2000 equipment. They and result in damage to the vacuum motor. - Page 12 Before proceeding, test the fabric for colour- CLEANING UPHOLSTERY fastness. Apply a small amount of ready-to-use cleaning solution on the fabric in an inconspicuous CAUTION – WE STRONGLY RECOMMEND area. Wait for 2 to 3 minutes and blot the area with ATTENDING AN UPHOLSTERY CLEANING a white terry cloth towel.
-
Page 13: Practical Carpet Cleaning
These are all referred to in the Prochem Training Course Manual that is supplied with the course. The speed at which the wand head is drawn back on the cleaning stroke is usually governed by the PREPARATION &... -
Page 14: General Maintenance
GENERAL MAINTENANCE All Prochem machines are engineered and built to Ensure that all connections are secure and require a minimum of maintenance. But like any close machine electrical housing and secure machine, it does require some care to keep it in with tool required. -
Page 15: Weekly Maintenance
Models fitted with continuous running pumps (no Finding Guide page in this manual and contact your pressure switch fitted) should be checked for brush Prochem Distributor. Although some service parts wear every 6 months for normal usage and every 3 are available, we recommend that defective months for heavy usage. -
Page 16: General Fault Finding
GENERAL FAULT FINDING GUIDE CAUTION - Repairs should only be carried out by a QUALIFIED AND FULLY TRAINED PERSON ! NO POWER With both vacuum and pump switches in the 'on' position, the vacuum and pump will not run. PROBABLE CAUSES CORRECTIVE ACTION Defective power cord Replace power cord... -
Page 17: Parts Diagram Sx2000 / Sx2100 Upper
PARTS DIAGRAM SX2000 / SX2100 UPPER Steempro Manual.doc 1/8/09 Page 17 of 31... -
Page 18: Parts List Sx2000 / Sx2100 Upper
PARTS LIST SX2000 / SX2100 UPPER REF. STOCK CODE PART NO. DESCRIPTION E11787-P F11787-P SOLUTION TANK E11870 F11788 RECOVERY TANK E11791 F11791 LID, SOLUTION TANK E11124 E11124 GASKET, RECOVERY TANK 12904A STAND PIPE ASSEMBLY K11965 ELBOW, 180 DEG. FLOAT BALL E00919 K00672 PVC PIPE, 1.5 X 12 IN, SCH 40 WHT... -
Page 19: Parts Diagram Sx2000 / Sx2100 Base
PARTS DIAGRAM SX2000 / SX2100 BASE Steempro Manual.doc 1/8/09 Page 19 of 31... -
Page 20: Parts List Sx2100 / Sx2000 Base
PARTS LIST SX2000 / SX2100 BASE REF. STOCK CODE PART NO. DESCRIPTION C00297 SCREW,#8 X .25 IN, PAN HEAD J11863 HOSE, 3 IN TT00639 J00639 SCREW CLAMP, 1.63 - 2.43IN. E00618 J00618 VACUUM HOSE, 2IN GREY, WIRE, 22 IN LG F11178-BLK INTERCOOLER, GALAXY, BLACK LA4501E... - Page 21 E03518 G03518 CASTER, 4 IN E11789 F11789 BASE E11308 B11308 TERMINAL BLOCK, 8 POLE E11165 C11165 SCREW, # 8 X 1 IN, PAN, BLACK E00613 J00613B SOLUTION HOSE, .375 IN, BLACK X 32 TT00640 J11508 SCREW CLAMP #6, .43 TO .875 IN FJ00051 A00054 ELBOW, 90, .375MP X .375B, NYLON...
-
Page 22: Parts Diagram Sx2700 / Sx2750 Upper
PARTS DIAGRAM SX2700 / SX2750 UPPER Steempro Manual.doc 1/8/09 Page 22 of 31... -
Page 23: Parts List Sx2700 / Sx2750 Upper
PARTS LIST SX2700 / SX2750 UPPER REF. STOCK CODE PART NO. DESCRIPTION E11787-1 F11787-1 SOLUTION TANK E11788-1 F11788-1 RECOVERY TANK E11791-1 F11791-1 LID, SOLUTION TANK E11167 C11167 SCREW ¼ - 20 X ¾ SS E02714 K02714 PLUG 0.500 CH00060 A00060 3/8 BARB X ¼... -
Page 24: Parts Diagram Sx2700 / Sx2750 Base
PARTS DIAGRAM SX2700 / SX2750 BASE Steempro Manual.doc 1/8/09 Page 24 of 31... -
Page 25: Parts List Sx2700 / Sx2750 Base
PARTS LIST SX2700 / SX2750 BASE REF. STOCK CODE PART NO. DESCRIPTION C00297 SCREW,#8 X .25 IN, PAN HEAD J11863 HOSE, 3 IN TT00639 J00639 SCREW CLAMP, 1.63 - 2.43IN. E00618 J00618 VACUUM HOSE, 2IN GREY, WIRE, 22 IN LG JE00273 C00273 LOCK NUT ¼-20 NYLON SS... - Page 26 E02564-2 H02564-2 WARNING LABEL – ELECTRIC SHOCK J11933 HOSE, ½” POLYWIRE PVC 30” K11935 STRAINER IN-LINE 0.5” E11154 J11154 SOLUTION HOSE 3/8” X 27” WIRE REINFORCED E00618 J00618 VACUUM HOSE 2” WIRE X 7” PC807110 E11169 GASKET VAC MOTOR B00179-2 CLOSED END CONNECTOR 16-3 Steempro Manual.doc 1/8/09 Page 26 of 31...
-
Page 27: Wand Parts List
WAND PARTS LIST REF. STOCK CODE PART NO. DESCRIPTION E00526 G00526 KINGSTON VALVE (ASSEMBLY) E00834 M00834 K-VALVE STEM KP4002 BS006 K-VALVE O-RING E00839 M00839 K-VALVE CAGE E00838 M00838 K-VALVE SCREW E00835 M00835 K-VALVE SPRING E00833 M00833 K-VALVE CAP E00836 M00836 K-VALVE PLUNGER ASSEMBLY E00832-A D03424... -
Page 28: Pump Parts List
PUMP PARTS LIST REF. STOCK CODE PART NO. DESCRIPTION FJ4401B D1735H7011 FLOJET PUMP 230V 70 PSI CE FJ4429 20131001 PUMP SCREWS PRESSURE SWITCH ASSEMBLY (SEE ITEM REF.8) FJ5508 20914003 CHECK VALVE ASSEMBLY FJ5007 21006033 DIAPHRAGM / CAM BEARING ASSEMBLY FJ5009 R2039117 MOTOR ASSEMBLY 230V MOTOR REAR END BELL ASSEMBLY (SEE ITEM REF.5) -
Page 29: Wiring Diagram
WIRING DIAGRAM MODELS SX2100 & 2700 220 – 240V 50Hz Steempro Manual.doc 1/8/09 Page 29 of 31... - Page 30 THIS PAGE IS INTENTIONALLY LEFT BLANK Steempro Manual.doc 1/8/09 Page 30 of 31...
-
Page 31: Ce Declaration Of Conformity
2006/95/EC Low Voltage (LVD) Directive 2004/108/EC Electromagnetic Compatibility (EMC) Directive A Technical file is held by Prochem Europe Ltd. Certificate of compliance and test reports have been issued by: ITS Testing and Certfication Ltd. SGS United Kingdom Ltd. ITS House Cleeve Road,...
