Notice that, instead of "CANLOGxt.txt", the real file name will be shown.
Data-logging will end in the following cases:



U
After pressing ESC, the console will ask to wait a couple of seconds to
finalize data writing inside the flash drive: when this time is elapsed, USB
stick can be removed.
U
Don't remove USB stick during this time or during datalog process
otherwise the output file will be empty or corrupted!
4
During data-logging the led will blink slowly to indicate the console is still running.
When data-log has finished USB stick can be unplugged safely.

5.3 GRAPHICAL TESTER

Coming soon.

5.4 DATALOG OF TESTER VARIABLES

Coming soon.

5.5 PROGRAMMING A CONTROLLER

Coming soon.

5.6 FORCED RESET

In any menu, the simultaneous keystroke of F2 and F3 for 5 seconds will force a
console reset and the return to the HOME SCREEN.
Any function, which was underway prior to this reset, is interrupted.
When internal batteries are used, the console will switch off (this method is an
alternative to the ON button)
Use this function when console seems stuck or it does not respond properly to
commands.
U
Notice that interrupting any function which was operating with USB will
likely cause the corruption of the output file.
AFGZP0BA - SMART CONSOLE - User Manual
Esc button has been pressed
Error while reading CAN or CANBUS is ko
Error while writing on USB or USB stick has been unplugged
Page - 41/50
