[VR-B UNIT]
REF
PARTS
NO.
NO.
R1
7210003880 VAR
RK0972214C04
J1
6510029480 S.CON 06FH-SM1-TB (LF) (SN)
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
.
DESCRIPTION
M
LOCATION
T
H/V
20.0/5.6
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5-23
