Icom IC-9700 Service Manual page 42

[DISPLAY UNIT]
REF PARTS
NO. NO.
EP601 6910019900 S.BEA MPZ1608S601AT
EP602 6910019900 S.BEA MPZ1608S601AT
EP603 6910019900 S.BEA MPZ1608S601AT
EP604 6910016330 S.BEA MMZ1005S 601CT-S
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
.
DESCRIPTION M
LOCATION
B 64.7/67.8
B 67.3/59.9
B 68.3/67.8
B 82.6/67.7
H/V
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
