- Page 1 Product Manual Produkthåndbok...
- Page 2 RCD type/type A, <30 mA Self-test of the RCD is performed at the Self-tests/Jordfeiltest insertion into the car. The relays are continuously monitored for welding. / Når bilen kobles til utfører RAY en automatisk test av jordfeilbryterne. Reléene overvåkes kontinuerlig for kontaktsveising. Standards/Standarder IEC 61851-1 Ed.3...
- Page 3 See safety precautions for more information To start charging 1. Connect RAY to an outlet socket. Make sure to always do this step first. 2. RAY will start and indicate the selected charging current on the display. 3. Make sure the RAY cable is not creating a coil.
- Page 4 (tannhjulet) og juster effekten med opp-/nedpilene på displayet. Avslutt ved å trykke på OK (det grønne merket). 5. Koble til RAY i bilen. Ladingen startes automatisk. Displayet vil vise et bilde som forteller at lading pågår. Slik avslutter du lading For å...
-
Page 5: Safety Precautions
• Stop using the RAY if a failure or abnormality occurs or the cable is damaged. • Stop using the RAY if the display shows any faults. • Stop using the RAY if it gets very hot. The RAY will get warm during charging, this is normal. - Page 6 Charge Amps AB is not responsible for damages, either direct or indirect, relating to the use of these instructions. Charge Amps AB cannot guarantee completeness, accuracy or timeliness of the information found in this manual, and we reserve the right to make changes at anytime without notice.
