Load; Ex Connection Data - Endress+Hauser Proline Promag H 200 Technical Information

Proline Promag H 200

Load

Ex connection data

Endress+Hauser
Load for current output: 0 to 500 Ω, depending on the external supply voltage of the power supply
unit
Calculation of the maximum load
Depending on the supply voltage of the power supply unit (U
line resistance must be observed to ensure adequate terminal voltage at the device. In doing so,
observe the minimum terminal voltage
• For U = 18 to 18.9 V: R
S B
• For U = 18.9 to 24.5 V: R
S
• For U = 24.5 to 30 V: R ≤ 500 Ω
S B
W
R [ ]
b
500
400
300
200
100
0
14 16 18
1 Operating range
1.1 For order code for "Output", option A "4-20 mA HART"/option B "4-20 mA HART, pulse/frequency/switch
output" with Ex i
1.2 For order code for "Output", option A "4-20 mA HART"/option B "4-20 mA HART, pulse/frequency/switch
output" with non-Ex and Ex d
Sample calculation
Supply voltage of the power supply unit: U
Maximum load: R ≤ (19 V - 13.5 V): 0.022 A = 250 Ω
B
Safety-related values
Type of protection Ex d
Order code for "Output"
Option A
Option B
Option E
≤ (U - 18 V): 0.0036 A
S
≤ (U - 13.5 V): 0.022 A
B S
1
20 22 24 26
= 19 V
S
Output type
4-20mA HART
4-20mA HART
Pulse/frequency/switch output
FOUNDATION Fieldbus
Pulse/frequency/switch output
), the maximum load (R
S
1.1 1.2
28 30 32 34 36
Safety-related values
U = DC 35 V
nom
U = 250 V
max
U = DC 35 V
nom
U = 250 V
max
U = DC 35 V
nom
U = 250 V
max
1)
P = 1 W
max
U = DC 32 V
nom
U = 250 V
max
P = 0.88 W
max
U = DC 35 V
nom
U = 250 V
max
1)
P = 1 W
max
) including
B
U [V]
s
A0013563
9
