Page 5 13.2 Measuring and test equipment ... 159 13.3 Endress+Hauser services ....159 Repair ......160 14.1 General notes .
Page 6: About This Document
About this document Proline Promag H 300 HART About this document Document function These Operating Instructions contain all the information required in the various life cycle phases of the device: from product identification, incoming acceptance and storage, to installation, connection, operation and commissioning, through to troubleshooting, maintenance and disposal.
Page 7: Tool Symbols
Proline Promag H 300 HART About this document 1.2.4 Tool symbols Symbol Meaning Flat-blade screwdriver Allen key Open-ended wrench 1.2.5 Symbols for certain types of information Symbol Meaning Permitted Procedures, processes or actions that are permitted. Preferred Procedures, processes or actions that are preferred.
Page 8: Documentation
• Device Viewer (www.endress.com/deviceviewer): Enter the serial number from the nameplate • Endress+Hauser Operations app: Enter serial number from nameplate or scan matrix code on nameplate. The following documentation may be available depending on the device version ordered: Document type...
Page 9: Safety Instructions
Proline Promag H 300 HART Safety instructions Safety instructions Requirements for the personnel The personnel for installation, commissioning, diagnostics and maintenance must fulfill the following requirements: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task.
Page 10: Workplace Safety
Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties.
Page 11: Device-Specific It Security
Proline Promag H 300 HART Safety instructions Device-specific IT security The device offers a range of specific functions to support protective measures on the operator' s side. These functions can be configured by the user and guarantee greater in- operation safety if used correctly. The following list provides an overview of the most...
Page 12: Infrastructure Mode
Safety instructions Proline Promag H 300 HART WLAN passphrase: Operation as WLAN access point A connection between an operating unit (e.g. notebook or tablet) and the device via the WLAN interface (→  66), which can be ordered as an optional extra, is protected by the network key.
Page 13 Proline Promag H 300 HART Safety instructions The use of relevant industrial standards and guidelines that have been defined by national and international safety committees, such as IEC/ISA62443 or the IEEE, is recommended. This includes organizational security measures such as the assignment of access authorization as well as technical measures such as network segmentation.
Page 14: Product Description
Product description Proline Promag H 300 HART Product description The device consists of a transmitter and a sensor. The device is available as a compact version: The transmitter and sensor form a mechanical unit. Product design N ic te r e rg ö...
Page 15: Incoming Acceptance And Product
• Enter the serial numbers from the nameplates in the Device Viewer (www.endress.com/deviceviewer): all the information about the device is displayed. • Enter the serial numbers from the nameplates into the Endress+Hauser Operations app or scan the DataMatrix code on the nameplate with the Endress+Hauser Operations app: all the information about the device is displayed.
Page 16: Transmitter Nameplate
Incoming acceptance and product identification Proline Promag H 300 HART 4.2.1 Transmitter nameplate 3 4 5 Order code: Ser. no.: Ext. ord. cd.: Date: A0029192  2 Example of a transmitter nameplate Manufacturer address/certificate holder Name of the transmitter Order code...
Page 17: Sensor Nameplate
Proline Promag H 300 HART Incoming acceptance and product identification 4.2.2 Sensor nameplate Order code: Ser. no.: Ext. ord. cd.: Date: A0029204  3 Example of sensor nameplate Name of sensor Manufacturer address/certificate holder Order code Serial number (Ser. no.) Extended order code (Ext.
Page 18: Symbols On The Device
Incoming acceptance and product identification Proline Promag H 300 HART 4.2.3 Symbols on the device Symbol Meaning WARNING! This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury. Please consult the documentation for the measuring instrument to discover the type of potential danger and measures to avoid it.
Page 19: Storage And Transport
Proline Promag H 300 HART Storage and transport Storage and transport Storage conditions Observe the following notes for storage: ‣ Store in the original packaging to ensure protection from shock. ‣ Do not remove protective covers or protective caps installed on process connections.
Page 20: Measuring Devices With Lifting Lugs
Mounting Proline Promag H 300 HART 5.2.2 Measuring devices with lifting lugs CAUTION Special transportation instructions for devices with lifting lugs ‣ Only use the lifting lugs fitted on the device or flanges to transport the device. ‣ The device must always be secured at two lifting lugs at least.
Page 21 Proline Promag H 300 HART Mounting A0042131 The device should ideally be installed in an ascending pipe. A0042317 Installation upstream from a down pipe NOTICE Negative pressure in the measuring pipe can damage the liner! ‣ If installing upstream of down pipes whose length h ≥ 5 m (16.4 ft): install a siphon with a vent valve downstream of the device.
Page 22 Mounting Proline Promag H 300 HART A0041088 Installation near pumps NOTICE Negative pressure in the measuring tube can damage the liner! ‣ In order to maintain the system pressure, install the device in the flow direction downstream from the pump.
Page 23 Proline Promag H 300 HART Mounting Orientation The direction of the arrow on the nameplate helps you to install the measuring device according to the flow direction (direction of medium flow through the piping). Orientation Recommendation Vertical orientation A0015591 Horizontal orientation α...
Page 24: Inlet And Outlet Runs
Mounting Proline Promag H 300 HART A0028998 EPD electrode for empty pipe detection, available from ≥ DN 15 (½") Measuring electrodes for signal detection Measuring instruments with a nominal diameter < DN 15 (½") do not have an EPD electrode. In this case, empty pipe detection is performed via the measuring electrodes.
Page 25: Environmental And Process Requirements
Proline Promag H 300 HART Mounting 6.1.2 Environmental and process requirements Ambient temperature range Transmitter Standard: –40 to +60 °C (–40 to +140 °F) Local display –20 to +60 °C (–4 to +140 °F), the readability of the display may be impaired at temperatures outside the temperature range.
Page 26: Special Mounting Instructions
Mounting Proline Promag H 300 HART 6.1.3 Special mounting instructions Weather protection cover 280 (11.0) 255 (10.0) 146 (5.75) 134 (5.3) 12 (0.47) 30 (1.18) A0029553  4 Engineering unit mm (in) Hygienic compatibility • When installing in hygienic applications, please refer to the information in the "Certificates and approvals/hygienic compatibility"...
Page 27: Turning The Display Module
Proline Promag H 300 HART Mounting – – 3 mm 4 mm 7 Nm (5.2 lbf ft) A0029993  5 Housing in non-Ex version 1. Depending on the device version: Loosen the securing clamp of the connection compartment cover. 2. Unscrew the connection compartment cover.
Page 28: Post-Mounting Check
Mounting Proline Promag H 300 HART – – – 3 mm A0030035 1. Depending on the device version: Loosen the securing clamp of the connection compartment cover. 2. Unscrew the connection compartment cover. 3. Turn the display module to the desired position: max. 8 × 45° in each direction.
Page 29: Electrical Connection
Proline Promag H 300 HART Electrical connection Electrical connection WARNING Live parts! Incorrect work performed on the electrical connections can result in an electric shock. ‣ Set up a disconnecting device (switch or power-circuit breaker) to easily disconnect the device from the supply voltage.
Page 30 Electrical connection Proline Promag H 300 HART Double pulse output Standard installation cable is sufficient. Relay output Standard installation cable is sufficient. Current input 0/4 to 20 mA Standard installation cable is sufficient. Status input Standard installation cable is sufficient.
Page 31: Endress+Hauser
Proline Promag H 300 HART Electrical connection Cable length Maximum 300 m (1 000 ft), maximum loop impedance 20 Ω Capacitance: core/shield Maximum 1 000 nF for Zone 1, Class I, Division 1 Maximum 24 µH/Ω for Zone 1, Class I, Division 1...
Page 32: Terminal Assignment
Electrical connection Proline Promag H 300 HART 7.2.3 Terminal assignment Transmitter: supply voltage, input/outputs The terminal assignment of the inputs and outputs depends on the individual order version of the device. The device-specific terminal assignment is documented on an adhesive label in the terminal cover.
Page 33 Proline Promag H 300 HART Electrical connection – – – 3 mm A0029813 1. Loosen the securing clamp of the connection compartment cover. 2. Unscrew the connection compartment cover. 3. Squeeze the tabs of the display module holder together. 4. Remove the display module holder.
Page 34 Electrical connection Proline Promag H 300 HART 22 mm 24 mm – A0029816 10. Connect the cable according to the terminal assignment.  Signal cable terminal assignment: The device-specific terminal assignment is documented on an adhesive label in the terminal cover.
Page 35: Connecting The Remote Display And Operating Module Dkx001
Proline Promag H 300 HART Electrical connection 7.3.2 Connecting the remote display and operating module DKX001 The remote display and operating module DKX001 is available as an optional extra →  162.. • The remote display and operating module DKX001 is only available for the following housing version: order code for "Housing": option A "Aluminum, coated"...
Page 36: Connection Example In Special Situations
• Grounding rings can be ordered separately as accessory DK5HR* from Endress+Hauser (does not contain any seals). When ordering make sure that the grounding rings are...
Page 37: Special Connection Instructions
Proline Promag H 300 HART Electrical connection Potential equalization via grounding electrodes on process connection A0028972 Hexagonal-headed bolts of process connection Integrated grounding electrodes O-ring seal Sensor Special connection instructions 7.5.1 Connection examples Current output 4 to 20 mA HART 4...20 mA...
Page 38: Hart Input
Electrical connection Proline Promag H 300 HART 4...20 mA A0028762  9 Connection example for 4 to 20 mA HART current output (passive) Automation system with current input (e.g. PLC) Power supply Ground cable shield at one end. The cable shield must be grounded at both ends to comply with EMC requirements;...
Page 39: Pulse/Frequency Output
Proline Promag H 300 HART Electrical connection 4...20 mA A0028759  12 Connection example for 4-20 mA current output (passive) Automation system with current input (e.g. PLC) Active barrier for power supply (e.g. RN221N) Analog display unit: observe maximum load →  170...
Page 40: Relay Output
Electrical connection Proline Promag H 300 HART Double pulse output A0029280  15 Connection example for double pulse output (active) Automation system with double pulse input (e.g. PLC) Transmitter: observe input values →  173 Double pulse output Double pulse output (slave), phase-shifted A0029279 ...
Page 41: Current Input
Proline Promag H 300 HART Electrical connection Current input A0028915  18 Connection example for 4 to 20 mA current input Power supply Terminal box External measuring device (to read in pressure or temperature, for instance) Transmitter Status input A0028764 ...
Page 42: Post-Connection Check
Electrical connection Proline Promag H 300 HART 5. To ensure that moisture does not enter the cable entry: Route the cable so that it loops down before the cable entry ("water trap").  A0029278 6. The cable glands supplied do not ensure housing protection when not in use. They must therefore be replaced by dummy plugs corresponding to the housing protection.
Page 43: Operation Options
Proline Promag H 300 HART Operation options Operation options Overview of operation options A0034513 Local operation via display module Computer with web browser or operating tool (e.g. FieldCare, DeviceCare, AMS Device Manager, SIMATIC PDM) Field Xpert SFX350 or SFX370 Field Xpert SMT70 Mobile handheld terminal Automation system (e.g.
Page 44: Structure And Function Of The Operating Menu
Operation options Proline Promag H 300 HART Structure and function of the operating menu 8.2.1 Structure of the operating menu For an overview of the operating menu for experts: see the "Description of Device Parameters" document supplied with the device →  195...
Page 45: Operating Philosophy
Proline Promag H 300 HART Operation options 8.2.2 Operating philosophy The individual parts of the operating menu are assigned to certain user roles (e.g. operator, maintenance etc.). Each user role contains typical tasks within the device life cycle. Menu/parameter User role and tasks...
Page 46: Access To Operating Menu Via Local Display
Operation options Proline Promag H 300 HART Access to operating menu via local display 8.3.1 Operational display X X X X X X X 1120.50 A0029346 Operational display Device tag →  78 Status area Display range for measured values (up to 4 lines) Operating elements →...
Page 47 Proline Promag H 300 HART Operation options Measured variables Symbol Meaning Conductivity Mass flow The number and display format of the measured variables can be configured via the Format display parameter (→  93). Totalizer Symbol Meaning Totalizer  The measurement channel number indicates which of the three totalizers is displayed.
Page 48: Navigation View
Operation options Proline Promag H 300 HART 8.3.2 Navigation view In the submenu In the wizard /../Operation 0091-1 /../Curr. output 1 Access stat.disp Assign curr. Operator Volume flow Locking status Display A0013993-EN A0016327-EN Navigation view Navigation path to current position...
Page 49: Locking Procedure
Proline Promag H 300 HART Operation options Setup Is displayed: • In the menu next to the "Setup" selection • At the left in the navigation path in the Setup menu Diagnosis Is displayed: • In the menu next to the "Diagnostics" selection •...
Page 50: Editing View
Operation options Proline Promag H 300 HART 8.3.3 Editing view Numeric editor +0.000 Xx – A0034250  21 For entering values in parameters (e.g. limit values) Entry display area Input screen Confirm, delete or reject entry Operating elements Text editor...
Page 51 Proline Promag H 300 HART Operation options Operating key Meaning Enter key • Pressing the key briefly confirms your selection. • Pressing the key for 2 s confirms your entry. Escape key combination (press keys simultaneously) Close the editing view without accepting a change.
Page 52: Operating Elements
Operation options Proline Promag H 300 HART 8.3.4 Operating elements Operating key Meaning Minus key In menu, submenu Moves the selection bar upwards in a picklist In wizards Goes to previous parameter In the text and numeric editor Move the entry position to the left.
Page 53 Proline Promag H 300 HART Operation options Calling up and closing the context menu The user is in the operational display. 1. Press the  and  keys for longer than 3 seconds.  The context menu opens. XXXXXXXXXX Setup Conf.backup...
Page 54: Navigating And Selecting From List
Operation options Proline Promag H 300 HART 8.3.6 Navigating and selecting from list Different operating elements are used to navigate through the operating menu. The navigation path is displayed on the left in the header. Icons are displayed in front of the individual menus.
Page 55: Calling Up Help Text
Proline Promag H 300 HART Operation options The direct access code consists of a 5-digit number (at maximum) and the channel number, which identifies the channel of a process variable: e.g. 00914-2. In the navigation view, this appears on the right-hand side in the header of the selected parameter.
Page 56: User Roles And Related Access Authorization
Operation options Proline Promag H 300 HART Ent. access code Invalid or out of range input value Min:0 Max:9999 A0014049-EN For a description of the editing view - consisting of the text editor and numeric editor - with symbols →  50, for a description of the operating elements →  52 8.3.10...
Page 57: Enabling And Disabling The Keypad
Proline Promag H 300 HART Operation options 2. Enter the access code.  The -symbol in front of the parameters disappears; all previously write- protected parameters are now re-enabled. 8.3.12 Enabling and disabling the keypad lock The keypad lock makes it possible to block access to the entire operating menu via local operation.
Page 58: Requirements
Operation options Proline Promag H 300 HART 8.4.2 Requirements Computer hardware Hardware Interface CDI-RJ45 WLAN Interface The computer must have a RJ45 The operating unit must have a WLAN interface. interface. Connection Standard Ethernet cable Connection via Wireless LAN. Screen Recommended size: ≥12"...
Page 59: Connecting The Device
Proline Promag H 300 HART Operation options Measuring device: Via CDI-RJ45 service interface Device CDI-RJ45 service interface Measuring device The measuring device has an RJ45 interface. Web server Web server must be enabled; factory setting: ON  For information on enabling the Web server →  63...
Page 60 Operation options Proline Promag H 300 HART NOTICE Note the following to avoid a network conflict: ‣ Avoid accessing the measuring device simultaneously from the same mobile terminal via the service interface (CDI-RJ45) and the WLAN interface. ‣ Only activate one service interface (CDI-RJ45 or WLAN interface).
Page 61: Logging On
Proline Promag H 300 HART Operation options 2. Enter the IP address of the web server in the address line of the web browser: 192.168.1.212  The login page appears. 2 3 4 Device name: Device tag: Signal Status: Web server language...
Page 62: User Interface
Operation options Proline Promag H 300 HART 8.4.5 User interface A0029418 Function row Local display language Navigation area Header The following information appears in the header: • Device name • Device tag • Device status with status signal →  140 •...
Page 63: Disabling The Web Server
Proline Promag H 300 HART Operation options Working area Depending on the selected function and the related submenus, various actions can be performed in this area: • Configuring parameters • Reading measured values • Calling up help text • Starting an upload/download 8.4.6...
Page 64: Access To The Operating Menu Via The Operating Tool
Operation options Proline Promag H 300 HART Access to the operating menu via the operating tool The structure of the operating menu in the operating tools is the same as for operation via the local display. 8.5.1 Connecting the operating tool Via HART protocol This communication interface is available in device versions with a HART output.
Page 65: Service Interface
Proline Promag H 300 HART Operation options A0028746  25 Options for remote operation via HART protocol (passive) Control system (e.g. PLC) Transmitter power supply unit, e.g. RN221N (with communication resistor) Connection for Commubox FXA195 and Field Communicator 475 Field Communicator 475 Computer with web browser (e.g.
Page 66 Operation options Proline Promag H 300 HART Via WLAN interface The optional WLAN interface is available on the following device version: Order code for "Display; operation", option G "4-line, illuminated; touch control + WLAN" A0034570 Transmitter with integrated WLAN antenna...
Page 67: Field Xpert Sfx350, Sfx370
FieldCare Function range FDT-based (Field Device Technology) plant asset management tool from Endress+Hauser. It can configure all smart field units in a system and helps you manage them. By using the status information, it is also a simple but effective way of checking their status and condition.
Page 68 Operation options Proline Promag H 300 HART Access is via: • HART protocol →  64 • CDI-RJ45 service interface →  65 • WLAN interface →  66 Typical functions: • Transmitter parameter configuration • Loading and saving of device data (upload/download) •...
Page 69: Devicecare
DeviceCare Function range Tool for connecting and configuring Endress+Hauser field devices. The fastest way to configure Endress+Hauser field devices is with the dedicated "DeviceCare" tool. Together with the device type managers (DTMs) it presents a convenient, comprehensive solution. Innovation brochure IN01047S Source for device description files →...
Page 70: Field Communicator 475
Operation options Proline Promag H 300 HART 8.5.6 Field Communicator 475 Function scope Industrial handheld terminal from Emerson Process Management for remote configuration and measured value display via HART protocol. Source for device description files See information →  71 8.5.7...
Page 71: System Integration
Proline Promag H 300 HART System integration System integration Overview of device description files 9.1.1 Current version data for the device Firmware version 01.06.zz • On the title page of the manual • On the transmitter nameplate • Firmware version Diagnostics →...
Page 72: Device Variables
System integration Proline Promag H 300 HART Dynamic variables Measured variables (HART device variables) Primary dynamic variable (PV) Volume flow Secondary dynamic variable (SV) Totalizer 1 Tertiary dynamic variable (TV) Totalizer 2 Quaternary dynamic variable (QV) Totalizer 3 The assignment of the measured variables to the dynamic variables can be modified and...
Page 73: Other Settings
Proline Promag H 300 HART System integration • 8 = totalizer 1 • 9 = totalizer 2 • 10 = totalizer 3 Other settings Burst mode functionality in accordance with HART 7 Specification: Navigation "Expert" menu → Communication → HART output → Burst configuration → Burst configuration 1 to n ‣...
Page 74: Parameter Overview With Brief Description
System integration Proline Promag H 300 HART Parameter overview with brief description Parameter Description Selection / User entry Factory setting Burst mode 1 to n Activate the HART burst mode for burst • Off message X. • On Burst command 1 to n Select the HART command that is sent to the •...
Page 75 Proline Promag H 300 HART System integration Parameter Description Selection / User entry Factory setting Min. update period Enter the minimum time span between two Positive integer 1 000 ms burst commands of burst message X. Max. update period Enter the maximum time span between two...
Page 76: Commissioning
Commissioning Proline Promag H 300 HART Commissioning 10.1 Post-mounting and post-connection check Before commissioning the device: ‣ Make sure that the post-installation and post-connection checks have been performed successfully. • Checklist for "Post-mounting" check→  28 • Checklist for "Post-connection check" →  42 10.2...
Page 77 Proline Promag H 300 HART Commissioning X X X X X X X 20.50 Main menu Display language English Display/operat. Setup Main menu Display/operat. Setup Diagnostic / ../Setup Medium selection XXXXXXXXX XXXXXXXXX A0032222-EN  28 Navigation to "Setup" menu using the example of the local display The number of submenus and parameters can vary depending on the device version.
Page 78: Defining The Tag Name
Commissioning Proline Promag H 300 HART ‣ Configure flow damping →  101 ‣ Advanced setup →  104 10.4.1 Defining the tag name To enable fast identification of the measuring point within the system, you can enter a unique designation using the Device tag parameter and thus change the factory setting.
Page 79 Proline Promag H 300 HART Commissioning Mass flow unit →  79 Mass unit →  79 →  79 Density unit Corrected volume flow unit →  80 Corrected volume unit →  80 Parameter overview with brief description...
Page 80: Displaying The I/O Configuration
Commissioning Proline Promag H 300 HART Parameter Prerequisite Description Selection Factory setting Corrected volume flow unit – Select corrected volume flow Unit choose list Country-specific: unit. • Nl/h • Sft³/h Result The selected unit applies to: Corrected volume flow parameter (→  123) Corrected volume unit –...
Page 81: Configuring The Status Input
Proline Promag H 300 HART Commissioning Parameter Description User interface / Selection / Factory setting User entry Apply I/O configuration Apply parameterization of the freely • No configurable I/O module. • Yes I/O alteration code Enter the code in order to change the I/O Positive integer configuration.
Page 82 Commissioning Proline Promag H 300 HART Navigation "Setup" menu → Current input ‣ Current input 1 to n Terminal number →  82 Signal mode →  82 →  82 0/4 mA value 20 mA value →  82 Current span →...
Page 83: Configuring The Current Output
Proline Promag H 300 HART Commissioning 10.4.6 Configuring the current output The Current output wizard guides you systematically through all the parameters that have to be set for configuring the current output. Navigation "Setup" menu → Current output ‣ Current output 1 to n Terminal number →...
Page 84 Commissioning Proline Promag H 300 HART Parameter Prerequisite Description User interface / Factory setting Selection / User entry Process variable current output – Select the process variable for • Off Volume flow the current output. • Volume flow • Mass flow • Corrected volume flow •...
Page 85 Proline Promag H 300 HART Commissioning Parameter Prerequisite Description User interface / Factory setting Selection / User entry Damping current output A process variable is selected Set reaction time for output 0.0 to 999.9 s 1.0 s in the Assign current output signal to fluctuations in the parameter (→...
Page 86: Configuring The Pulse/Frequency
Commissioning Proline Promag H 300 HART 10.4.7 Configuring the pulse/frequency/switch output The Pulse/frequency/switch output wizard guides you systematically through all the parameters that can be set for configuring the selected output type. Navigation "Setup" menu → Advanced setup → Pulse/frequency/switch output ‣...
Page 87 Proline Promag H 300 HART Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting interface / User entry Operating mode – Define the output as a pulse, • Pulse Pulse frequency or switch output. • Frequency • Switch Terminal number –...
Page 88 Commissioning Proline Promag H 300 HART Minimum frequency value →  89 Maximum frequency value →  89 →  89 Measuring value at minimum frequency Measuring value at maximum →  89 frequency Failure mode →  89 Failure frequency →...
Page 89 Proline Promag H 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting interface / User entry Minimum frequency value The Frequency option is Enter minimum frequency. 0.0 to 10 000.0 Hz 0.0 Hz selected in the Operating mode parameter (→  86)
Page 90 Commissioning Proline Promag H 300 HART Configuring the switch output Navigation "Setup" menu → Pulse/frequency/switch output ‣ Pulse/frequency/switch output 1 to n Operating mode →  90 Terminal number →  90 Signal mode →  90 Switch output function →...
Page 91 Proline Promag H 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting interface / User entry Switch output function The Switch option is selected Select function for switch • Off in the Operating mode output. • On parameter. • Diagnostic behavior • Limit •...
Page 92: Configuring The Local Display
Commissioning Proline Promag H 300 HART Parameter Prerequisite Description Selection / User Factory setting interface / User entry Switch-off delay • The Switch option is Define delay for the switch-off 0.0 to 100.0 s 0.0 s selected in the Operating of status output. mode parameter.
Page 93 Proline Promag H 300 HART Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Format display A local display is provided. Select how measured values • 1 value, max. size 1 value, max. size are shown on the display.
Page 94: Configuring The Low Flow Cut Off
Commissioning Proline Promag H 300 HART Parameter Prerequisite Description Selection / User Factory setting entry Value 6 display A local display is provided. Select the measured value that For the picklist, see None is shown on the local display. Value 1 display parameter (→...
Page 95: 10.4.10 Configuring Empty Pipe Detection
Proline Promag H 300 HART Commissioning 10.4.10 Configuring empty pipe detection The measuring instruments are calibrated with water (approx. 500 µS/cm) at the factory. For liquids with a lower conductivity, it is advisable to perform a new full pipe adjustment onsite.
Page 96 Commissioning Proline Promag H 300 HART Navigation "Expert" menu → Communication → HART input ‣ HART input ‣ Configuration →  96 ‣ Input →  97 "Configuration" submenu Navigation "Expert" menu → Communication → HART input → Configuration ‣...
Page 97 Proline Promag H 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Device type In the Capture mode Enter device type of external 2-digit hexadecimal 0x00 parameter, the Master device. number network option is selected. Manufacturer ID The Master network option is...
Page 98: 10.4.12 Configuring The Relay Output
Commissioning Proline Promag H 300 HART Parameter overview with brief description Parameter Description User interface Value Shows the value of the device variable recorded by the HART Signed floating-point number input. Status Shows the status of the device variable recorded by the HART •...
Page 99 Proline Promag H 300 HART Commissioning Parameter overview with brief description Parameter Prerequisite Description User interface / Factory setting Selection / User entry Terminal number – Shows the terminal numbers • Not used – used by the relay output • 24-25 (I/O 2) module.
Page 100: 10.4.13 Configuring The Double Pulse Output
Commissioning Proline Promag H 300 HART Parameter Prerequisite Description User interface / Factory setting Selection / User entry Switch state – Shows the current relay switch • Open – status. • Closed Powerless relay status – Select quietscent state for • Open Open relay.
Page 101: 10.4.14 Configuring Flow Damping
Proline Promag H 300 HART Commissioning Parameter Description Selection / User interface / Factory setting User entry Measuring mode Select measuring mode for pulse output. • Forward flow Forward flow • Forward/Reverse flow • Reverse flow • Reverse flow compensation Value per pulse...
Page 102 Commissioning Proline Promag H 300 HART Median filter depth →  102 Flow damping →  102 →  102 Support ID Save settings →  103 Parameter overview with brief description Parameter Description Selection / User interface Factory setting Scenario Select the applicable scenario.
Page 103 Proline Promag H 300 HART Commissioning Parameter Description Selection / User interface Factory setting Save settings Indicate whether to save the recommended • Cancel Cancel settings. • Save Filter Wizard result: • Completed Aborted • Aborted Visibility depends on order options or device settings...
Page 104: Advanced Settings
Commissioning Proline Promag H 300 HART 10.5 Advanced settings The Advanced setup submenu with its submenus contains parameters for specific settings. Navigation to the "Advanced setup" submenu X X X X X X X 20.50 0104-1 Main menu Display language English Display/operat.
Page 105: Using The Parameter To Enter The Access Code
Proline Promag H 300 HART Commissioning ‣ Totalizer 1 to n →  105 ‣ Display →  107 ‣ →  110 Electrode cleaning cycle ‣ WLAN settings →  111 ‣ Configuration backup →  113 ‣ Administration →...
Page 106 Commissioning Proline Promag H 300 HART Navigation "Setup" menu → Advanced setup → Totalizer 1 to n ‣ Totalizer 1 to n Assign process variable →  106 Unit totalizer 1 to n →  106 →  106 Totalizer operation mode Failure mode →...
Page 107: Carrying Out Additional Display Configurations
Proline Promag H 300 HART Commissioning 10.5.4 Carrying out additional display configurations In the Display submenu you can set all the parameters associated with the configuration of the local display. Navigation "Setup" menu → Advanced setup → Display ‣ Display Format display →...
Page 108 Commissioning Proline Promag H 300 HART Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Format display A local display is provided. Select how measured values • 1 value, max. size 1 value, max. size are shown on the display.
Page 109 Proline Promag H 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry 100% bargraph value 3 A selection was made in the Enter 100% value for bar Signed floating-point Value 3 display parameter. graph display. number Decimal places 3...
Page 110: Performing Electrode Cleaning
Commissioning Proline Promag H 300 HART Parameter Prerequisite Description Selection / User Factory setting entry Separator A local display is provided. Select decimal separator for • . (point) . (point) displaying numerical values. • , (comma) Backlight One of the following Switch the local display •...
Page 111: Wlan Configuration
Proline Promag H 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry / User interface ECC recovery time For the following order code: Specify the maximum 1 to 600 s 60 s "Application package", option timespan after the cleaning EC "ECC electrode cleaning"...
Page 112 Commissioning Proline Promag H 300 HART Connection state →  113 Received signal strength →  113 Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry / User interface WLAN – Switch WLAN on and off. • Disable Enable •...
Page 113: Configuration Management
Proline Promag H 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry / User interface Connection state – Displays the connection status. • Connected Not connected • Not connected Received signal strength – Shows the received signal • Low High strength.
Page 114: Function Scope Of The "Configuration Management" Parameter
Commissioning Proline Promag H 300 HART Parameter Description User interface / Selection Factory setting Backup state Shows the current status of data saving or • None None restoring. • Backup in progress • Restoring in progress • Delete in progress • Compare in progress •...
Page 115 Proline Promag H 300 HART Commissioning Using the parameter to define the access code Navigation "Setup" menu → Advanced setup → Administration → Define access code ‣ Define access code →  115 Define access code Confirm access code →  115...
Page 116: Simulation
Commissioning Proline Promag H 300 HART Parameter overview with brief description Parameter Description Selection Factory setting Device reset Reset the device configuration - either • Cancel Cancel entirely or in part - to a defined state. • To delivery settings •...
Page 117 Proline Promag H 300 HART Commissioning Switch state 1 to n →  118 Pulse output simulation →  118 →  118 Pulse value Device alarm simulation →  118 Diagnostic event category →  118 Diagnostic event simulation →...
Page 118: Protecting Settings From Unauthorized Access
Commissioning Proline Promag H 300 HART Parameter Prerequisite Description Selection / User Factory setting entry Switch state 1 to n – Select the status of the status • Open Open output for the simulation. • Closed Relay output 1 to n simulation –...
Page 119: Write Protection Via Access Code
Proline Promag H 300 HART Commissioning 10.7.1 Write protection via access code The effects of the user-specific access code are as follows: • Via local operation, the parameters for the measuring device configuration are write- protected and their values can no longer be changed.
Page 120: Write Protection Via Write Protection Switch
Via Web browser, FieldCare, DeviceCare (via CDI-RJ45 service interface), fieldbus You can only obtain a reset code from your local Endress+Hauser service organization. The code must be calculated explicitly for every device. 1. Note down the serial number of the device.
Page 121 Proline Promag H 300 HART Commissioning A0029630 Setting the write protection (WP) switch on the main electronics module to the ON position enables hardware write protection.  In the Locking status parameter, the Hardware locked option is displayed →  122. In addition, on the local display the  symbol appears in front of the parameters in the header of the operational display and in the navigation view.
Page 122: Operation
The DIP switch for custody transfer mode is activated on the PCB board. Locks the parameters that are relevant for custody transfer and also parameters that are predefined by Endress+Hauser and are not relevant for custody transfer (e.g. on local display or operating tool).
Page 123 Proline Promag H 300 HART Operation Navigation "Diagnostics" menu → Measured values → Process variables ‣ Process variables Volume flow →  123 Mass flow →  123 →  123 Corrected volume flow Flow velocity →  123 Conductivity →...
Page 124: Totalizer" Submenu
Operation Proline Promag H 300 HART Parameter Prerequisite Description User interface Temperature One of the following conditions is met: Displays the temperature that is Positive floating-point • Order code for "Sensor option", option currently calculated. number CI "Medium temperature Dependency measurement"...
Page 125: Output Values
Proline Promag H 300 HART Operation Input values of current input The Current input 1 to n submenu contains all the parameters needed to display the current measured values for every current input. Navigation "Diagnostics" menu → Measured values → Input values → Current input 1 to n ‣...
Page 126 Operation Proline Promag H 300 HART ‣ Pulse/frequency/switch output →  126 1 to n ‣ Relay output 1 to n →  127 ‣ →  127 Double pulse output Output values of current output The Value current output submenu contains all the parameters needed to display the current measured values for every current output.
Page 127 Proline Promag H 300 HART Operation Parameter overview with brief description Parameter Prerequisite Description User interface Output frequency 1 to n In the Operating mode parameter, the Displays the value currently measured 0.0 to 12 500.0 Hz Frequency option is selected.
Page 128: Adapting The Measuring Device To The Process Conditions
Operation Proline Promag H 300 HART Parameter overview with brief description Parameter Description User interface Pulse output Shows the currently output pulse frequency. Positive floating-point number 11.5 Adapting the measuring device to the process conditions The following are available for this purpose: •...
Page 129: Function Scope Of "Control Totalizer" Parameter
Proline Promag H 300 HART Operation Parameter Prerequisite Description Selection / User Factory setting entry / User interface Totalizer value A process variable is selected Displays the current totalizer Signed floating-point – in the Assign process variable counter value. number parameter (→  106) of the Totalizer 1 to n submenu.
Page 130 Operation Proline Promag H 300 HART • x-axis: depending on the number of channels selected displays 250 to 1000 measured values of a process variable. • y-axis: displays the approximate measured value span and constantly adapts this to the ongoing measurement.
Page 131 Proline Promag H 300 HART Operation Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry / User interface Assign channel 1 The Extended HistoROM Assign process variable to • Off application package is logging channel. • Volume flow available.
Page 132 Operation Proline Promag H 300 HART Parameter Prerequisite Description Selection / User Factory setting entry / User interface Data logging – Select the type of data logging. • Overwriting Overwriting • Not overwriting Logging delay In the Data logging Enter the time delay for...
Page 133: Diagnostics And Troubleshooting
Proline Promag H 300 HART Diagnostics and troubleshooting Diagnostics and troubleshooting 12.1 General troubleshooting For local display Error Possible causes Remedial action Local display is dark, but signal output is within The cable of the display module is not plugged in...
Page 134 Diagnostics and troubleshooting Proline Promag H 300 HART For access Error Possible causes Remedial action Write access to parameter not possible. Hardware write protection is enabled. Set the write protection switch on the main electronics module to the OFF position →...
Page 135 Proline Promag H 300 HART Diagnostics and troubleshooting Error Possible causes Remedial action Operation with FieldCare or DeviceCare not Firewall of the PC or network prevents Depending on the settings of the firewall used possible via CDI-RJ45 service interface (port communication.
Page 136: Diagnostic Information Via Light Emitting Diodes
Diagnostics and troubleshooting Proline Promag H 300 HART 12.2 Diagnostic information via light emitting diodes 12.2.1 Transmitter Different LEDs in the transmitter provide information on the device status. 1 2 3 4 5 A0029629 Supply voltage Device status Not used...
Page 137: Diagnostic Information On Local Display
Proline Promag H 300 HART Diagnostics and troubleshooting 12.3 Diagnostic information on local display 12.3.1 Diagnostic message Faults detected by the self-monitoring system of the measuring device are displayed as a diagnostic message in alternation with the operational display. Operational display in alarm condition...
Page 138: Diagnostic Information
Diagnostics and troubleshooting Proline Promag H 300 HART Diagnostic behavior Symbol Meaning Alarm • Measurement is interrupted. • Signal outputs and totalizers assume the defined alarm condition. • A diagnostic message is generated. Warning • Measurement is resumed. • The signal outputs and totalizers are not affected.
Page 139: Calling Up Remedial Measures
Proline Promag H 300 HART Diagnostics and troubleshooting 12.3.2 Calling up remedial measures X X X X X X X X X X X X X X 20.50 S801 Supply voltage Menu Diagnostic list Diagnostics 1 S801 Supply voltage Diagnostics 2...
Page 140: Diagnostic Information In The Web Browser
Diagnostics and troubleshooting Proline Promag H 300 HART 12.4 Diagnostic information in the web browser 12.4.1 Diagnostic options Any faults detected by the measuring device are displayed in the Web browser on the home page once the user has logged on.
Page 141: Calling Up Remedy Information
Proline Promag H 300 HART Diagnostics and troubleshooting 12.4.2 Calling up remedy information Remedy information is provided for every diagnostic event to ensure that problems can be rectified quickly. These measures are displayed in red along with the diagnostic event and the related diagnostic information.
Page 142: Diagnostic Options
Diagnostics and troubleshooting Proline Promag H 300 HART 12.5 Diagnostic information in FieldCare or DeviceCare 12.5.1 Diagnostic options Any faults detected by the measuring device are displayed on the home page of the operating tool once the connection has been established.
Page 143: Calling Up Remedy Information
Proline Promag H 300 HART Diagnostics and troubleshooting 12.5.2 Calling up remedy information Remedy information is provided for every diagnostic event to ensure that problems can be rectified quickly: • On the home page Remedy information is displayed in a separate field below the diagnostics information.
Page 144: Adapting The Diagnostic Information
Diagnostics and troubleshooting Proline Promag H 300 HART 12.6 Adapting the diagnostic information 12.6.1 Adapting the diagnostic behavior Each item of diagnostic information is assigned a specific diagnostic behavior at the factory. The user can change this assignment for specific diagnostic information in the Diagnostic behavior submenu.
Page 145 Proline Promag H 300 HART Diagnostics and troubleshooting Symbol Meaning Maintenance required Maintenance is required. The measured value remains valid. A0013957 Has no effect on the condensed status. A0023076 Endress+Hauser...
Page 146: Overview Of Diagnostic Information
Diagnostics and troubleshooting Proline Promag H 300 HART 12.7 Overview of diagnostic information The amount of diagnostic information and the number of measured variables affected increase if the measuring device has one or more application packages. In the case of some items of diagnostic information, the status signal and the diagnostic behavior can be changed.
Page 147 Proline Promag H 300 HART Diagnostics and troubleshooting Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] I/O module faulty 1. Restart device Alarm 2. Change I/O module Memory content Restart device Alarm inconsistent Device verification active Device verification active, please wait.
Page 148 Diagnostics and troubleshooting Proline Promag H 300 HART Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Trim 1 to n required Carry out trim Warning Configuration 1. Update firmware Alarm incompatible 2. Execute factory reset Dataset different 1.
Page 149 Proline Promag H 300 HART Diagnostics and troubleshooting Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Configuration 1. Check IP addresses in network Warning 2. Change IP address Custody transfer mode 1. Power off device and toggle DIP...
Page 150: Pending Diagnostic Events
Diagnostics and troubleshooting Proline Promag H 300 HART 12.8 Pending diagnostic events The Diagnostics menu allows the user to view the current diagnostic event and the previous diagnostic event separately. To call up the measures to rectify a diagnostic event: •...
Page 151 Proline Promag H 300 HART Diagnostics and troubleshooting / ../Diagnose list Diagnostics F273 Main electronic Diagnostics 2 Diagnostics 3 A0014006-EN  32 Using the example of the local display To call up the measures to rectify a diagnostic event: • Via local display →  139 •...
Page 152: 12.10 Event Logbook
Diagnostics and troubleshooting Proline Promag H 300 HART 12.10 Event logbook 12.10.1 Reading out the event logbook A chronological overview of the event messages that have occurred is provided in the Events list submenu. Navigation path Diagnostics menu → Event logbook submenu → Events list / ../Eventlist...
Page 153: 12.10.3 Overview Of Information Events
Proline Promag H 300 HART Diagnostics and troubleshooting 12.10.3 Overview of information events Unlike a diagnostic event, an information event is displayed in the event logbook only and not in the diagnostic list. Info number Info name I1000 --------(Device ok)
Page 154 Diagnostics and troubleshooting Proline Promag H 300 HART Info number Info name I1622 Calibration changed I1624 All totalizers reset I1625 Write protection activated I1626 Write protection deactivated I1627 Web server: login successful I1628 Display: login successful I1629 CDI: login successful...
Page 155: 12.11 Resetting The Measuring Device
Proline Promag H 300 HART Diagnostics and troubleshooting 12.11 Resetting the measuring device The entire device configuration or some of the configuration can be reset to a defined state with the Device reset parameter (→  116). 12.11.1 Function range of "Device reset" parameter...
Page 156: 12.12 Device Information
Diagnostics and troubleshooting Proline Promag H 300 HART 12.12 Device information The Device information submenu contains all parameters that display different information for device identification. Navigation "Diagnostics" menu → Device information ‣ Device information Device tag →  156 Serial number →...
Page 157 Proline Promag H 300 HART Diagnostics and troubleshooting Parameter Description User interface Factory setting Device name Shows the name of the transmitter. Promag 300/500 –  The name can be found on the nameplate of the transmitter. Manufacturer Displays the manufacturer.
Page 158: 12.13 Firmware History
"Manufacturer' s information" document. The manufacturer' s information is available: • In the Download Area of the Endress+Hauser web site: www.endress.com → Downloads • Specify the following details: •...
Page 159: Maintenance
Replacement seals (accessory part) →  195 13.2 Measuring and test equipment Endress+Hauser offers a variety of measuring and testing equipment, such as Netilion or device tests. Your Endress+Hauser Sales Center can provide detailed information on the services. List of some of the measuring and testing equipment: →  164 13.3...
Page 160: Repair
• The measuring devices have a modular design. • Spare parts are grouped into logical kits with the associated Installation Instructions. • Repairs are carried out by Endress+Hauser Service or by appropriately trained customers. • Certified devices can only be converted to other certified devices by Endress+Hauser Service or at the factory.
Page 161: Disposal
Proline Promag H 300 HART Repair 14.5 Disposal If required by the Directive 2012/19/EU on waste electrical and electronic equipment (WEEE), the product is marked with the depicted symbol in order to minimize the disposal of WEEE as unsorted municipal waste. Do not dispose of products bearing this marking as unsorted municipal waste.
Page 162: Accessories
Various accessories, which can be ordered with the device or subsequently from Endress +Hauser, are available for the device. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.
Page 163: For The Sensor
Proline Promag H 300 HART Accessories 15.1.2 For the sensor Accessories Description Adapter set Adapter connections for installing a Promag H instead of a Promag 30/33 A or Promag 30/33 H (DN 25). Consists of: • 2 process connections • Screws •...
Page 164: Service-Specific Accessories
• As a downloadable DVD for local PC installation. Netilion lloT ecosystem: Unlock knowledge Endress+Hauser ' s Netilion lloT ecosystem enables you to optimize your plant performance, digitize workflows, share knowledge and improve collaboration. Based on decades of experience in process automation, Endress+Hauser offers the process industry an lloT ecosystem that enables you to gain useful insights from data.
Page 165: System Components
Proline Promag H 300 HART Accessories 15.4 System components Accessories Description Memograph M graphic The Memograph M graphic data manager provides information on all the relevant data manager measured variables. Measured values are recorded correctly, limit values are monitored and measuring points analyzed. The data are stored in the 256 MB internal memory and also on a SD card or USB stick.
Page 166: Technical Data
Technical data Proline Promag H 300 HART Technical data 16.1 Application The measuring device is intended only for the flow measurement of liquids with a minimum conductivity of 5 µS/cm. Depending on the version ordered, the measuring device can also measure potentially explosive, flammable, poisonous and oxidizing media.
Page 167 Proline Promag H 300 HART Technical data Recommended Nominal diameter Factory settings flow min./max. full Full scale value Pulse value Low flow cut off scale value current output (~ 2 pulse/s) (v ~ 0.04 m/s) (v ~ 0.3/10 m/s) (v ~ 2.5 m/s)
Page 168 Technical data Proline Promag H 300 HART Recommended Nominal diameter Factory settings flow Low flow min./max. full Full scale value cut off Pulse value scale value current output (v ~ (~ 2 pulse/s) (v ~ 0.3/10 m/s) (v ~ 2.5 m/s) 0.04 m/s...
Page 169 Proline Promag H 300 HART Technical data Voltage drop Typically: 0.6 to 2 V for 3.6 to 22 mA (passive) Maximum input voltage ≤ 30 V (passive) Open-circuit voltage ≤ 28.8 V (active) Possible input variables • Temperature • Density...
Page 170: Output
Technical data Proline Promag H 300 HART 16.4 Output Output signal Current output 4 to 20 mA HART Order code "Output; input 1" (20): Option BA: current output 4 to 20 mA HART Signal mode Can be set to: • Active •...
Page 171 Proline Promag H 300 HART Technical data Current output 4 to 20 mA Order code "Output; input 2" (21), "Output; input 3" (022): Option B: current output 4 to 20 mA Signal mode Can be set to: • Active • Passive...
Page 172 Technical data Proline Promag H 300 HART Pulse/frequency/switch output Function Can be configured as pulse, frequency or switch output Version Open collector Can be set to: • Active • Passive • Passive NAMUR  Ex-i, passive Maximum input values DC 30 V, 250 mA (passive) Open-circuit voltage DC 28.8 V (active)
Page 173 Proline Promag H 300 HART Technical data Number of switching Unlimited cycles Assignable functions • Disable • On • Diagnostic behavior • Limit value: • Disable • Volume flow • Mass flow • Corrected volume flow • Flow velocity • Conductivity •...
Page 174 Technical data Proline Promag H 300 HART Maximum switching • DC 30 V, 0.1 A capacity (passive) • AC 30 V, 0.5 A Assignable functions • Disable • On • Diagnostic behavior • Limit value: • Disable • Volume flow •...
Page 175: Local Display
Proline Promag H 300 HART Technical data Frequency output Fault mode Choose from: • Actual value • 0 Hz • Definable value between: 2 to 12 500 Hz Switch output Fault mode Choose from: • Current status • Open • Closed...
Page 176: Power Supply
Technical data Proline Promag H 300 HART Galvanic isolation The outputs are galvanically isolated: • from the power supply • from one another • from the potential equalization (PE) terminal Protocol-specific data Manufacturer ID 0x11 Device type ID 0x3C HART protocol revision...
Page 177: Performance Characteristics
Proline Promag H 300 HART Technical data Potential equalization Terminals Spring-loaded terminals: Suitable for strands and strands with ferrules. Conductor cross-section 0.2 to 2.5 mm (24 to 12 AWG). Cable entries • Cable gland: M20 × 1.5 with cable ⌀ 6 to 12 mm (0.24 to 0.47 in) •...
Page 178: Electrical Conductivity
Technical data Proline Promag H 300 HART Temperature ±3 °C (±5.4 °F) Electrical conductivity The values apply for: • Devices with stainless steel process connections • Measurements at a reference temperature of 25 °C (77 °F). At different temperatures, attention must be paid to the temperature coefficient of the medium (typically 2.1 %/K)
Page 179: Mounting
Proline Promag H 300 HART Technical data Current output Accuracy ±5 µA Pulse/frequency output o.r. = of reading Accuracy Max. ±50 ppm o.r. (over the entire ambient temperature range) Repeatability o.r. = of reading Volume flow Max. ±0.1 % o.r. ± 0.5 mm/s (0.02 in/s) Temperature ±0.5 °C (±0.9 °F)
Page 180 The device is suitable for use outdoors and indoors with a relative humidity of 4 to 95 %. Operating height According to EN 61010-1 • ≤ 2 000 m (6 562 ft) • > 2 000 m (6 562 ft) with additional overvoltage protection (e.g. Endress+Hauser HAW Series) Degree of protection Transmitter •...
Page 181: Electromagnetic Compatibility (Emc)
Proline Promag H 300 HART Technical data Electromagnetic • As per IEC/EN 61326 and NAMUR Recommendation 21 (NE 21) compatibility (EMC) • As per IEC/EN 61000-6-2 and IEC/EN 61000-6-4 Details are provided in the Declaration of Conformity. This unit is not intended for use in residential environments and cannot guarantee adequate protection of the radio reception in such environments.
Page 182: 16.10 Mechanical Construction
Technical data Proline Promag H 300 HART Flow limit The diameter of the pipe and the flow rate determine the nominal diameter of the sensor. The optimum velocity of flow is between 2 to 3 m/s (6.56 to 9.84 ft/s). Also match the velocity of flow (v) to the physical properties of the medium: •...
Page 183: Specification
Proline Promag H 300 HART Technical data Nominal diameter Weight [mm] [in] [kg] [lbs] 15.4 34.0 17.8 39.3 Measuring tube Nominal diameter Pressure rating Process connection internal diameter specification EN (DIN) [mm] [in] [bar] [mm] [in] 1/12 PN 16/40 2.25 0.09...
Page 184: Sensor Housing
Technical data Proline Promag H 300 HART Cable entries/cable glands A0020640  37 Possible cable entries/cable glands Female thread M20 × 1.5 Cable gland M20 × 1.5 Adapter for cable entry with female thread G ½" or NPT ½" Order code for "Housing", option A "Aluminum, coated"...
Page 185: Wall Mounting Kit
Proline Promag H 300 HART Technical data Electrodes Standard: 1.4435 (316L) Seals • O-ring seal, DN 2 to 25 (1/12 to 1"): EPDM, FKM , Kalrez • Aseptic gasket seal, DN 2 to 150 (1/12 to 6"): EPDM, FKM , VMQ (silicone)
Page 186: 16.11 Operability
Technical data Proline Promag H 300 HART (All data refer to parts in contact with the medium) Liner with PFA: ≤ 0.4 µm (15.7 µin) (All data refer to parts in contact with the medium) Stainless steel process connections: • With O-ring seal: ≤ 1.6 µm (63 µin) •...
Page 187 Proline Promag H 300 HART Technical data Via remote display and operating module DKX001 The remote display and operating module DKX001 is available as an optional extra →  162.. • The remote display and operating module DKX001 is only available for the following housing version: order code for "Housing": option A "Aluminum, coated"...
Page 188 Technical data Proline Promag H 300 HART Supported operating tools Different operating tools can be used for local or remote access to the measuring device. Depending on the operating tool used, access is possible with different operating units and via a variety of interfaces.
Page 189: Historom Data Management
Proline Promag H 300 HART Technical data Supported functions Data exchange between the operating unit (such as a notebook, for example,) and measuring device: • Upload the configuration from the measuring device (XML format, configuration backup) • Save the configuration to the measuring device (XML format, restore configuration) •...
Page 190: 16.12 Certificates And Approvals
The device meets the legal requirements of the applicable EU Directives. These are listed in the corresponding EU Declaration of Conformity along with the standards applied. Endress+Hauser confirms successful testing of the device by affixing to it the CE mark. UKCA marking The device meets the legal requirements of the applicable UK regulations (Statutory Instruments).
Page 191: Pharmaceutical Compatibility
Proline Promag H 300 HART Technical data Contact address Endress+Hauser UK: Endress+Hauser Ltd. Floats Road Manchester M23 9NF United Kingdom www.uk.endress.com RCM marking The measuring system meets the EMC requirements of the "Australian Communications and Media Authority (ACMA)". Ex-approval The devices are certified for use in hazardous areas and the relevant safety instructions are provided in the separate "Safety Instructions"...
Page 192 Technical data Proline Promag H 300 HART Restrictions • Valid single gases: • Air • Methane (CH • Carbon dioxide CO • Nitrogen (N • Oxygen (O • Valid 4-component natural gas composition in mol%: • CH 80 to 99 % •...
Page 193 Directive a) PED/G1/x (x = category) or b) PESR/G1/x (x = category) on the sensor nameplate, Endress+Hauser confirms compliance with the "Essential Safety Requirements" a) specified in Annex I of the Pressure Equipment Directive 2014/68/EU or b) Schedule 2 of Statutory Instruments 2016 No. 1105.
Page 194: 16.13 Application Packages
The application packages can be ordered with the device or subsequently from Endress+Hauser. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.
Page 195: 16.14 Accessories
For an overview of the scope of the associated Technical Documentation, refer to the following: • Device Viewer (www.endress.com/deviceviewer): Enter the serial number from the nameplate • Endress+Hauser Operations app: Enter serial number from nameplate or scan matrix code on nameplate. Standard documentation Brief Operating Instructions...
Page 196: Safety Instructions
Technical data Proline Promag H 300 HART Supplementary device- Safety instructions dependent documentation Safety instructions for electrical equipment for hazardous areas. Contents Documentation code ATEX/IECEx Ex d/Ex de XA01414D ATEX/IECEx Ex ec XA01514D cCSAus XP XA01515D cCSAus Ex d/ Ex de...
Page 197: Installation Instructions
Proline Promag H 300 HART Technical data Contents Documentation code Heartbeat Technology SD01640D Web server SD01654D Installation instructions Contents Note Installation instructions for spare part sets and • Access the overview of all the available spare part accessories sets via Device Viewer →  160 •...
Page 198: Index
Index Proline Promag H 300 HART Index Connection see Electrical connection Access authorization to parameters Connection cable ......29 Read access .
Page 199 Proline Promag H 300 HART Index Display area Field of application For operational display ..... 46 Residual risks ......10 In the navigation view .
Page 200 Index Proline Promag H 300 HART Installation conditions Mounting ....... . . 20 Partially filled pipe .
Page 201 Proline Promag H 300 HART Index Configuration backup (Submenu) ... . 113 Flow limit ......182 Configure flow damping (Wizard) .
Page 202 Index Proline Promag H 300 HART Switch output ......90 Web server ......63 System units .
Page 203 Proline Promag H 300 HART Index Use of measuring device Borderline cases ......9 Incorrect use .
Page 204 *71661654* 71661654 www.addresses.endress.com...

Endress+Hauser Proline Promag H 300 Operating Instructions Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Endress+Hauser Proline Promag H 300

Summary of Contents for Endress+Hauser Proline Promag H 300
