Icom NXDN IC-F5400D SERIES Product Manual page 10

Model name
Sensitivity
Audio power output
Adjacent channel selectivity
Spurious response rejection
Intermodulation
Hum and noise (without CCITT filter)
Squelch sensitivity (Threshold)
A: Analog
D: Digital
Specifications: Measurements made in accordance with TIA-603.
NXDN™ IC-F5400D/IC-F6400D SERIES PRODUCT GUIDE
IC-F5400D
RECEIVER
• 0.22 μV typical
@ 12 dB SINAD
• ‒6.0 dBμV (EMF) typical
@ 1% BER (D: 6.25 kHz)
• ‒5.0 dBμV (EMF) typical
@ 1% BER (D: 12.5 kHz)
4.0 W typical @ 5% distortion into 4 Ω
A: 72 dB typical
D: 65 dB typical (6.25 kHz),
68 dB typical (12.5 kHz)
A: 78 dB typical
D: 70 dB typical
(6.25 kHz/12.5 kHz)
0.22 μV typical
10
IC-F6400D
• 0.25 μV typical
@ 12 dB SINAD
• ‒6.0 dBμV (EMF) typical
@ 1% BER (D: 6.25 kHz)
• ‒5.0 dBμV (EMF) typical
@ 1% BER (D: 12.5 kHz)
85 dB typical
A: 75 dB typical
D: 70 dB typical
(6.25 kHz/12.5 kHz)
48 dB typical
0.25 μV typical
