Operation
Connect With Your Smartphone
The Wi-Fi Garage Door Opener is
®
compatible with up to 16 myQ enabled
accessories. Up to 10 devices can be
paired to the Wi-Fi garage door opener's
internal gateway. These devices can be
controlled with the myQ app. These devices
include any combination of myQ garage
door openers, Wi-Fi garage door openers,
myQ light controls. A Merlin myQ Gateway
(828AU) can be added if you need to
control more than 10 devices using the
myQ app. Up to 6 devices can be paired
to garage door opener itself (controlled
by garage door opener through 900MHz).
These devices include any combination
of myQ light controls or a garage door
opener.
You will need:
• Wi-Fi enabled smartphone, tablet or
laptop
• Broadband Internet Connection
• Wi-Fi signal in the garage (2.4 Ghz,
802.11b/g/n required), see page 5
• Password for your home network
(router's main account, not guest
network)
• myQ serial number located on the
®
garage door opener
SYNCHRONISE THE DOOR CONTROL
To synchronize the door control to the
garage door opener, press the push bar
until the garage door opener activates (it
may take up to 3 presses).The garage door
opener must run through a complete cycle
before it will activate Wi-Fi
®
CONNECT YOUR GARAGE DOOR
OPENER TO YOUR HOME WI-FI
Learn
Button
LED
An LED on the garage door
opener will indicate Wi-Fi
status. See table above.
NETWORK
1. Ensure your smartphone is connected to
the wi-fi internet connection.
2. Download the myQ app on your
smartphone from the App Store® or
Google Play™ store.
Sign up to create a myQ account or sign in
using an existing account.
3. Ensure you are in the "Devices" screen
within the app and then press the plus
symbol on the top right hand side to add
a device and move into the "Device Setup"
screen.
4. There shall be a list of different devices
to select from, select "Garage Door Opener
with Wi-Fi Wall Installed". There should
also be images of the different devices to
select from and the "Garage Door Opener
with Wi-Fi Wall Installed" should have the
image of the Commander Ultimate opener.
5. Once you have selected "Garage Door
Opener with Wi-Fi Wall Installed", it should
take you to the next screen highlighting
"What You Need" which lists access to
your Wi-Fi garage door opener, Strong
Wi-Fi signal inside your garage and Your
Wi-Fi password. If you have access to
all three listed, then proceed to the next
screen by selecting "Next" at the bottom of
the screen.
6. The following screen should highlight to
programming.
locate the wall control. Once you located
the wall control, proceed to the next step
by selecting "Next" at the bottom of the
screen.
7. Using the wall control follow the
instructions highlighted by pressing the
menu button, going to "Program" and then
in the "Program" screen select the first
option "myQ wi-fi opener".
8. You should then hear a beep from your
opener, if you do select "Yes".
9. The app should then begin to "Look for
devices", you should then find a device
with a myQ name. The exact name will
match the last few characters of the myQ
serial number which can be found under
the cover of the opener.
10. Once you have selected the opener,
follow the remaining few prompts within
the app to complete the myQ wi-fi setup.
NOTES:
The myQ
work if the garage door opener is operating
on battery power.
To erase the Wi-Fi settings, see page 28.
If you need help adding devices to your
myQ account or to learn more, visit
gomerlin.com.au or gomerlin.co.nz and
contact our customer service team.
Navigation
Buttons
24
LED Definition
Blue Off - Wi-Fi is not turned on.
Blinking - Garage door
opener is in Wi-Fi learn
mode.
Solid - Mobile device
connected to the garage
door opener.
Blue and Blinking - Attempting to
Green connect to router.
Green Blinking - Attempting to
connect to the Internet
server.
Solid - Wi-Fi has been set
up and garage door opener
is connected to the Internet.
Smartphone Control WILL NOT
®
