MANUAL
CONGRATULATIONS
on the purchase of your new CTEK professional battery man-
agement unit. This unit is part of a range of professional bat-
tery chargers from CTEK SWEDEN AB. It represents the latest
technology in battery charging.
Using the CTEK D250S DUAL and SMARTPASS products, you
can maximize the performance of your 12 V DC source.
IMPORTANT SAFETY
INSTRUCTIONS
CALIFORNIA PROPOSITION 65
WARNING: This product contains chemical known to the state
of California to cause cancer or reproductive toxicity.
SAVE THESE INSTRUCTIONS
1.
– This manual contains important safety and operating
instructions for battery charger Models D250S DUAL
(1044) and SMARTPASS (1058).
2. Use of an attachement not recommended or sold by the
CTEK may result in a risk of fire, electric shock, or injury to
persons.
20020400A D250S Dual SMARTPASS manual EU_US, print file, Print file 001.indd 3
3. When charging, batteries can emit explosive gases,
therefore it is essential to prevent flames and sparks. The
charger is designed for charging 12 V lead-acid batteries.
Do not use for any other purpose.
4. Always provide good ventilation when charging.
5. Make sure that cables used have sufficient cable area,
see CABLE DIMENSIONS.
6. Do not operate charger with damaged cord - replace the
cord immediately.
7.
Never operate the charger if it has received a sharp blow,
been dropped or otherwise damaged in any way; take it
to a CTEK representative.
8. Do not disassemble charger; take it to the retailer when
service or repair is required. Incorrect reassembly may
result in a risk of electrical shock or fire.
9.
Disconnect the products before attempting any mainte-
nance or cleaning
WARNING - RISK OF
10.
EXPLOSIVE GASES
WORKING IN VICINITY OF
a)
A LEAD-ACID BATTERY IS
DANGEROUS. BATTERIES
 EN • 3
2013-12-02 13:47:01
