Date: 2017-12-15
Version: 1.0
Alternator
Starter Motor
Fuse*
* Fuse recomended. Please verify directive for applicable installation regarding fuses
Title: 2 X D250SA 40A
Not connected = 14.4V charge voltage
Connected to minus = 14.7V charge voltage
Ignition
Smart alternator cable (red)
Not connected = Conventional alternator
Connected to ignition = Smart alternator
AGM cable (black)
Fuse*
Advertisement
Related Manuals for CTEK D250SA
Summary of Contents for CTEK D250SA
- Page 1 Date: 2017-12-15 Title: 2 X D250SA 40A Version: 1.0 Alternator Ignition Starter Motor Smart alternator cable (red) Not connected = Conventional alternator Connected to ignition = Smart alternator Fuse* Fuse* AGM cable (black) Not connected = 14.4V charge voltage Connected to minus = 14.7V charge voltage...
- Page 2 Charge voltage: Size 40Ah to 600Ah. (2xD250SA) You can choose between 14.4V and 14.7V (AGM) on When 20A with one D250SA gives to long recharge time D250SA. and alternator has a low voltage providing a low current If you not connect the Black AGM cable you get 14.4V...
