LARGE BATTERY BANK
SITUATION
One alternator feeding a Starter battery
and a large Service battery bank.
PROBLEM
The Starter battery will not be fully
charged and might not always be able
to start the engine.
INSTALLATION ShEET 3
18 • EN
20020400A D250S Dual SMARTPASS manual EU_US, print file, Print file 001.indd 18
SOLUTION
The D250S DUAL recharges the Starter
battery quickly to 100%, which guaran-
tees trouble-free engine starts.
+IN
12V
D250S DUAL
+IN +OUT
TIP 3
Mount the temperature sensor on the
Starter battery.
WARNING!
D250S DUAL is not reverse
polarity protected
WARNING!
Max 23 V input
