Summary of Contents for CTEK 1027
- Page 1 ® DC/DC Battery Charger For lead-acid batteries D250S User Manual and Guide to professional charging of starter and deep cycle batteries. Мodel 1027...
- Page 2 Congratulations on purchasing your new CTEK professional switch mode battery charger. This charger is part of a range of professional battery chargers from CTEK SWEDEN AB. It represents the latest technology in battery charging with charging and analysis in five steps with temperature compensation.
- Page 3 INSTAllINg ThE ChARgER IN ThE VEhIClE Install the charger on a surface where it can be properly fixed and where the charger is not exposed to fuels, oils or splashes of dirt. Mount the charger with screws intended for the surface and attach it with one screw in each of the four holes in the corners of the charger.
-
Page 4: Connecting The Charger
CONNECTINg ThE ChARgER 1. Identify the supply cords and connect the positive power cord to screw terminal marked with IN + 2. Identify the target battery cords and connect the positive power cord to screw terminal marked with OUT + 3. -
Page 5: Specification
*) The quality of the charging voltage and charging current are very important. High current ripple heats the battery and ages the positive electrode. High voltage ripple can damage other equipment connected to batteries. The battery chargers from CTEK produces very high quality voltage and current with low ripple. -
Page 6: Program Description
PROgRAM DESCRIPTION Desulphation Soft Start Bulk Revives a Soft Start Bulk charge sulphated battery PARAMETERS The charger starts charging the target battery when the voltage of the supply source exceeds 13.4V for 5 sec. The charger stops charging the target battery when the voltage of the supply drops below 12.8V for 10 sec. - Page 7 Absorption Float Pulse Peak charge with Maintenance for Maintenance for minimal fluid loss maximum performance maximum service life Absorption Float Pulse 14.4V until the current has Charging with constant The state of charge varies dropped to 0.4A or max 12h. voltage between 95% and 100%.
- Page 8 CTEK SWEDEN AB Rostugnsvägen 3, SE-776 70 VIKMANShYTTAN, Sweden Tel: +46 225 351 80 www.ctek.com...
