3.1 LED Self-Test Sequence and Functions

3.1.1 LED Self-Test Sequence

3.1.2 EtherCAT Link/Activity LED

3.1.3 Run LED

8
02.00 | FT-AXIA 80 EtherCat | Assembly and operating manual | en | 1009369
The EtherCAT F/T provides (3) LEDs for EtherCAT Link, Run, and
Sensor Status. When the user applies power, the sensor completes
a self-test, during which the LEDs under firmware control individu-
ally turn on.
When the user applies power to the sensor, the sensor completes
a self-test, during which the LEDs under firmware control individu-
ally turn on in the following sequence:
Sequence LED
Order
1 Sensor Status
2 Run
3 EtherCAT Link/Activity Red
4 Sensor Status
5 EtherCAT Link/Activity Green
The Green Run LED is not tested in the self-test sequence.
One LED signals link/activity on the EtherCAT port as follows:
LED State Link
Off No
Green Yes
1
This LED behavior is different from the standard EtherCAT device
Link/Activity LED behavior, which is a flashing green LED.
One LED signals the communication status of the EtherCAT sensor
interface as follows:
LED State Description
Off EtherCAT interface is in the state "INIT".
Flashing green EtherCAT interface is in the state "Preoperational".
Green EtherCAT interface is in the state "Operational".
State Duration
Red Approximately one
second for each
Red
LED.
Green
Activity Condition
No No Ethernet connection
No Ethernet link/activity is
detected.
1
Yes
