Maintenance information and precautions
Removing dust from inside the viewfinder
– CCD-TRV75/TRV85/TRV715/TRV815 only
(1) Remove the screw with a screwdriver (not supplied). Then, while sliding the
RELEASE knob, turn the eyecup in the direction of the arrow and pull it out.
(2) Clean the surface with a commercially available blower.
1
To reattach the eyecup
(1) Align the groove on the eyecup with the • mark on the barrel.
(2) Turn the eyecup in the direction of the arrow. Then replace the screw.
1
Caution
Do not remove any other screws. You may remove only the screw to remove the
eyecup.
2
2
69
