Using alternative power sources

Using alkaline batteries

– CCD-TRV75/TRV85/TRV93 only
Use the battery case (supplied) and six size AA (LR6) Sony Alkaline batteries (not
supplied).
(1) Remove the battery holder from the battery case.
(2) Insert six new alkaline batteries into the battery holder, following the marking
on the holder to be sure the batteries are installed in the correct direction.
(3) Insert the battery holder with the alkaline batteries.
(4) Insert the battery case with the alkaline batteries to the battery mounting
surface of the camcorder in the same way as the battery pack.
1

Battery life

Using alkaline batteries at 77°F (25°C).
Upper numbers are the time when recording with the viewfinder. Lower numbers are
the time when recording with the LCD screen.
CCD-
Continuous
Typical recording time
PRECAUTION
When the battery case is installed with the camcorder, do not connect the AC power
adaptor to the camcorder.
Notes
•You may not use the battery case in cold environment.
•The battery life may be shorter depending on the using environment.
•The above battery lives are estimates. The battery life may be shorter depending on
the storage condition of the battery before being purchased and temperature.
To remove the battery case
The battery case is removed in the same way as the battery pack.
When you replace the batteries, be sure to remove the battery case from the camcorder
to prevent malfunction.
Remove the battery case after using it.
26
2
recording time
3
TRV75 TRV85
265 min. 265 min.
180 min. 170 min.
140 min. 140 min.
95 min. 90 min.
TRV93
285 min.
180 min.
150 min.
95 min.
