Operating Method; Boot Up - ETCR ETCR2000+ Manual

the critical value of alarm setting
---Low battery & voltage is displayed. At this time, it not
guarantee the accuracy of the measurements
---Measured current is 8.40A
---Lock the current value displayed
---Store the current value as the data
Unit No.37
⑻ --- Access to the stored data unit No.8
.
--- Measured resistance is 30Ω
--- This data is measured in a lot of signals interference

1.Boot up

Boot , DO NOT press the trigger, don't open jaws, nor
clamp any wire
Boot complete, show "OL Ω", then press the trigger,
open jaws, clamp the measured wire
Before booting up, the trigger should be pressed for
a couple of times to ensure the jaws are well closed.
Boot, must maintain clamp meter natural resting
state, don't flip Clamp, don't be imposed outside
force on the jaw, otherwise can not guarantee the
accuracy of measurement
Press POWER Key to Boot, first, automated testing LCD,
VI. Operating Method
-11-
