Linear Outdoor Fire Pit (LOF)
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS DO
NOT ATTEMPT TO INSTALL OR OPERATE THIS APPLIANCE
This Linear Outdoor Fire pit requires a minimum 18-square inches (per side) of cross
ventilation. Failure to provide proper ventilation can void the warranty.
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
Natural Gas
LOF-30MT-N
30-inch stainless tube burner & pan
LOF-36MT-N
36-inch stainless tube burner & pan
Installation and Operating Instructions
INSTALLATION PRECAUTION:
Warning: For Outdoor Use Only
MODELS
Description
Advertisement
Table of Contents
Related Manuals for Firegear LOF-36MT-N
Summary of Contents for Firegear LOF-36MT-N
- Page 1 MODELS Natural Gas Description LOF-30MT-N 30-inch stainless tube burner & pan LOF-36MT-N 36-inch stainless tube burner & pan Linear Outdoor Fire Pit (LOF) Installation and Operating Instructions IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS DO NOT ATTEMPT TO INSTALL OR OPERATE THIS APPLIANCE...
- Page 2 CARBON MONOXIDE HAZZARD DANGER This appliance can produce carbon monoxide which has no odor. Using it in an enclosed area can kill you. Never use this appliance in an enclosed space such as a camper, tent, car or home. DANGER WARNING Do not store our use gasoline or other If you smell gas:...
-
Page 3: Table Of Contents
CALIFORNIA PROPOSITION 65 WARNING This product is designed to operate with one of the following fuel sources: Liquid Propane or Natural Gas. The fuel used to operate this product, and the products of combustion of such fuel, can expose you to chemicals including Benzene which is known to the State of California to cause cancer, birth defects and other reproductive harm and Carbon Monoxide which is known to the State of California to cause birth defects or other reproductive harm. -
Page 4: Specifications
6 ¼”- 7 ½” W x 30 ¼”- 31 ¾” L 2 ¾” 32” x 8” 30” x 6” 6” 18” LOF-36MT-N 6 ¼”- 7½” W x 36 ¼”- 37 ¾” L 2 ¾” 38” x 8” 36” x 6” 6”... -
Page 5: Gas Pipe Sizing
GAS PIPE SIZING CHART REFERENCE GAS PIPE SIZING NATURAL GAS : PIPE SIZING CHART Length of Pipe in Feet 1/2” 3/4” 1” 1 - 1/4” 1 - 1/2” 2” 2 - 2 1/2” 3” 4” • Natural Gas (NG) flow is given in 1237 2259 3640... -
Page 6: Preparation For Non-Conbustible Structure
2 - 1” x 9” Slots Per Side or Linear Outdoor Fire’s are subjected to many outdoor 2- Firegear 6 x12 vents elements such as rain, snow, wind, heat or cold. A minimum of 18 square inches of cross ventilation (2 sides) is Fire Pit required to keep the components in good working order. -
Page 7: Installation Into An Approved Enclosure
INSTALLATION OF INTO AN APPROVED ENCLOSURE REQUIREMENTS 1. Only non-combustible materials should come in direct contact with any part of the Linear Outdoor Fire. Under neath area should be non-combustible as well. 2. Only a minimum ¾” gas supply line to the Linear Outdoor Fire. Based on the selection of the Linear Outdoor Fire size, the proper brass fittings should be used to ensure a proper installation. -
Page 8: Installing Orifice & Key Valve
INSTALLING BURNER ORIFICE (OAS) Locate the burner nipple underneath the burner pan. Ensure the nipple from on the spur burner has gas rated Teflon tape Burner Pan Lock Nut wrapped around the threads. Thread the OAS (orifice air shutter) on to the nipple of the burning spur clockwise manner. -
Page 9: Typical Installation Drawings
Non-Combustible Fire Pit Pan Fire Pit Enclousure PUSH TO STOP TURN TO START HOURS E-Stop Valve Gas Valve Supply NOTE: E-Stop valve and flex line to the key valve are not supplied. Note: A 1¼” x 2” black iron or galvanized coupler/nipple (not supplied) can be used as a spacer between the manual valve and the valve flange to add additional... -
Page 10: Expanded View Drawing
Expanded View of Match Throw (LOF) Fire Pits / ” Washer Brass Nut OASNG# (Burner Ori ce) U3-8D-S (Fitting) Note: Use joint compound or Te on tape resistant to all T200-9898-46 gasses on all male NPT (Flex Connector) threads; not ared ttings. Ensure all connections are tight and check for gas leaks before and after assembly is... -
Page 11: Operation
OPERATION CAUTION: Children and adults should be alerted to the hazards on high surface temperatures and should stay away to avoid burns or clothing ignition. Young children should be carefully supervised when they are in the area of the appliance. WARNING: Do not use this appliance if any part has been under water. -
Page 12: Replacement Parts
REPLACEMENT PARTS DRAWINGS NOT TO SCALE REPLACEMENT PARTS Qty. Item Part Number Description LOF-30 30” Pan and Burner Tube only LOF-36 36” Pan and Burner Tube only Cover Plate ST3-100-1043 ORING Silicone Rubber Washer 7/8” Flat Washer/Spacer WASHER10SS 1/2” Flex Gas Line (46-inch Length) T-200-9898-46 Orifice Air Shutter (LOF-30 NG) OAS-NG36... -
Page 13: Maintenance/ Trouble Shooting
MAINTENANCE 1. The Linear Outdoor Fire should be inspected and cleaned before initial use annually by a qualified field service per- son. 2. Any component that is found faulty must be replaced with an approved component. 3. Any tampering or modifying with the Linear Outdoor Fire is dangerous and voids all warranties. 4. -
Page 14: Optional Accessories
ACCESSORIES The following accessories are available from your local Firegear dealer/distributor. Each accessory comes with a separate installation manual. Read each instruction thoroughly before installing. Lava Stones Lava Boulders Lava Rock Lava Rock: 1” to 2" size (10lbs) Lava Stones: 1” to 2” size (15lbs) Model: FG-LAVA-10 Lava Boulders: 6”... - Page 15 Lava Rock and Lava Stones are not covered by warranty For Commercial applications, the liability of Firegear Outdoors End User must provide a bill of sale, canceled check, or payment is limited to the express terms of this warranty. We expressly...
- Page 16 Having problems getting the fire pit to operate? Don’t leave the job site! We want to help! Call 855.498.8324 for Technical Support between the hours of 8:00AM to 5:00PM EST. Text photos to 260.255.5750 or e-mail photos to support@skytechpg.com. BEFORE YOU CALL WE WILL NEED THIS INFORMATION Model Number: ___________________________ Serial Number: ___________________________ How long is the gas line run? Nat Gas ____ LP Gas ____...
