H-Burner Models
Natural Gas
LOF-30LHTMSI-N
LOF-36LHTMSI-N
LOF-30LTTMSI-N
LOF-36LTTMSI-N
Thermocouple Manual Safety Ignition (TMSI) Fire Pits
Installation and Operating Instructions
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE THIS APPLIANCE
This fi re pit requires a minimum 18-square inches (per side) of cross ventilation.
Failure to provide proper ventilation can void the warranty.
Warning:
Warning: For Outdoor Use Only
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
MODELS
30" x 10" Linear Fire Pit with "H" Burner
36" x 12" Linear Fire Pit with "H" Burner
30" x 6" Linear Fire Pit with "T" Burner
36" x 6" Linear Fire Pit with "T" Burner
INSTALLATION PRECAUTION:
T-Burner Models
Description
Advertisement
Table of Contents
Related Manuals for Firegear LOF-30LTTMSI-N
Summary of Contents for Firegear LOF-30LTTMSI-N
- Page 1 LOF-30LHTMSI-N 30” x 10” Linear Fire Pit with “H” Burner LOF-36LHTMSI-N 36” x 12” Linear Fire Pit with “H” Burner LOF-30LTTMSI-N 30” x 6” Linear Fire Pit with “T” Burner LOF-36LTTMSI-N 36” x 6” Linear Fire Pit with “T” Burner...
- Page 2 CARBON MONOXIDE HAZARD DANGER This appliance can produce carbon monoxide which has no odor. Using it in an enclosed area can kill you. Never use this appliance in an enclosed space such as a camper, tent, car or home. WARNING DANGER If you smell gas: Do not store or us gasoline or other...
-
Page 3: Table Of Contents
Fuels used in gas fired appliances, and the products of combustion such as fuels, contain chemicals known to cause cancer, birth defects and/or other reproductive harm. This warning is issued pursuant to the California Health & Safety Code Sec. 25249.1 NOTE: An exterior lid/cover is not required but highly recommended when the fire pit is not in use. -
Page 4: Specifications
36” x 12” 32” 14 ½” 38½” 2¼” 2½” ⅜” 1¼” (914 x 305mm) (813mm) (368mm) (978mm) (57mm) (64mm) (10mm) (32mm) LOF-30LTTMSI-N 30”x 6” 27” 8 ½” 32½” 2¼” 2½” ⅜” 1¼” (762 x 152mm) (686mm) (216mm) (826mm) (57mm) (64mm) (10mm) -
Page 5: Specifications
OFF. Media (not supplied) is required inside the burner pan for operation (See page 12). Firegear Outdoors fi re pits are constructed and tested to follow the rigid ANSI standards for gas appliances and manufactured safely providing dependable and certifi ed products. If these fi re pits are not installed according to the installation manual (i.e. -
Page 6: Preparation For Non-Combustible Structure
VENTILATION FOR NON-COMBUSTIBLE ENCLOSURE Examples of Cross Ventilation Fire pits are subjected to many outdoor elements such as rain, 2- Firegear 6 x12 vents snow, wind, heat or cold. A minimum of 18 square inches (Model # VENT-KIT-6X12) (two opposite sides) of cross ventilation is required to keep the components in good working order. -
Page 7: Gas Pipe Sizing Chart
REFERENCE GAS PIPE SIZING CHART GAS PIPE SIZING NATURAL GAS : PIPE SIZING CHART Length of Pipe in Feet 1/2” 3/4” 1” 1 - 1/4” 1 - 1/2” 2” 2 - 2 1/2” 3” 4” • Natural Gas (NG) flow is given in 1237 2259 3640... -
Page 8: Installation Into An Approved Enclosure
7. These products are designed for outdoor use only. Not approved for any indoor use. 8. This fire pit is designed to have Firegear Outdoors lava rock or glass media completely covering the burner tube, so that the burner is not visible. Do not cover more than 1” above the top of burner. Use lava rock a minimum of 1”... -
Page 9: Gas Supply
Non-Combustible Burner Tube Fire Pit Pan Fire Pit Enclousure Shut-O Vents Gas Supply NOTE: Gas shut-off is not supplied. Fig. 6 Typical installation. INSTALLING BATTERY INTO PIEZO IGNITOR 1. Unscrew (counterclockwise) red ignitor knob/button and remove. 2. Insert AA battery (-) negative end into the ignitor battery compartment. 3. -
Page 10: Operation
OPERATION CAUTION: Children and adults should be alerted to the hazards on high surface temperatures and should stay away to avoid burns or clothing ignition. Young children should be carefully supervised when they are in the area of the appliance. WARNING: Do not use this appliance if any part has been under water. -
Page 11: Replacement Parts
TMSI REPLACEMENT PARTS Drawings not to scale. REV. 1-8-18 Page 11 Line of Fire - TMSI Series Fire Pits... -
Page 12: Media Requirements
14 LP Conversion kit for (for all 30” & 36” models) LOF-BO-LP40 MEDIA REQUIREMENTS Firegear Outdoor glass media comes in 5 lb. bags, Lava Rock comes in 10 lb. bags or 50 lb. box and Lava Stones come in 50 lb. bags. Model... -
Page 13: Fire Pit Maintenance/Trouble Shooting
2. Ensure fire pit enclosure has proper drainage for water and proper ventilation to dry out. OPTIONAL ACCESSORIES The following accessories are available from your local Firegear dealer/distributor. Each accessory comes with a separate installation manual. Read each instruction thoroughly before installing. -
Page 14: Lp Conversion Instructions
LOF-BO-LP40 (Natural to LP Gas Conversion) This instruction will properly convert the fire pit from Natural gas to Propane (LP) gas. Follow the steps below to proceed. See Table 2 on page 5 for proper LP orifice. Step 6: After the main burner orifice and brass fitting is re- Step 1: Shut OFF gas supply. -
Page 15: Limited Warranty
Lava Rock and Lava Stones are not may not apply to you. covered by warranty For Commercial applications, the liability of Firegear Outdoors End User must provide a bill of sale, canceled check, or payment is limited to the express terms of this warranty. We expressly... - Page 16 NOTES Line of Fire - TMSI Series Fire Pits REV. 1-8-18 Page 16...
- Page 17 FOR TECHNICAL SERVICE, CALL: (855) 498-8324 Firegear Outdoors 9230 Conservation Way Fort Wayne, IN 46809 Sales Support: (888) 699-6167 www.firegearoutdoors.com WEB SITE: REV. 1-8-18 Page 17 Line of Fire - TMSI Series Fire Pits...
- Page 18 Having problems getting the fire pit to operate? Don’t leave the job site! We want to help! Call 855.498.8324 for Technical Support between the hours of 8:00AM to 5:00PM EST. Text photos to 260.255.5750 or e-mail photos to support@skytechpg.com. BEFORE YOU CALL WE WILL NEED THIS INFORMATION Model Number: ___________________________ Serial Number: ___________________________ How long is the gas line run? Nat Gas ____ LP Gas ____...
