User Manual - TRANSLATION
Mobile Computer
MC 92N0
series
ex
Type 17-A1A.-..../.......
Type B7-A2A.-..../.......
ATEX/IECEx Zone 1
ATEX/IECEx Zone 2 / 22
UL Class I, II, Division 1 and Class III
UL Class I, II, Division 2 and Class III
Document No.: 11-A1A2-7D0001
Status: 20
March 2019 / Revision B
th
Reservation: Technical data subject to change without notice. Changes, errors and
misprints may not be used as a basis for any claim for damages.
Contents
Page
English
1 – 79
Appendix
Declaration of Conformity

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MC 92N0ex Series and is the answer not in the manual?

Questions and answers

Related Manuals for Bartec MC 92N0ex Series

Summary of Contents for Bartec MC 92N0ex Series

  • Page 1 User Manual - TRANSLATION Mobile Computer MC 92N0 series Type 17-A1A.-…./……. Type B7-A2A.-…./……. ATEX/IECEx Zone 1 ATEX/IECEx Zone 2 / 22 UL Class I, II, Division 1 and Class III UL Class I, II, Division 2 and Class III Document No.: 11-A1A2-7D0001 Status: 20 March 2019 / Revision B Reservation: Technical data subject to change without notice.

  • Page 3: Table Of Contents

    Mobile Computer MC 92N0 Table of Content Type 17-A1A.-………… and Type B7-A2A.-………… Basic Security Information........................1 Information on this User Manual ..................1 Languages ........................2 Changes in the document ....................2 Handling the product ......................2 Intended use ........................2 Exclusive purpose ......................
  • Page 4 Mobile Computer MC 92N0 Table of Content Type 17-A1A.-………… and Type B7-A2A.-………… Transport and Storage ........................34 Transport ........................34 Storage ........................... 34 Commissioning ........................... 35 Scope of delivery ......................35 Accessories optional....................... 35 Requirements in potentially explosive atmosphere ............36 First steps ........................
  • Page 5 Mobile Computer MC 92N0 Table of Content Type 17-A1A.-………… and Type B7-A2A.-………… Faults and Troubleshooting ....................... 68 Resetting the MC 92N0 ....................68 Windows Embedded Handheld and Windows Compact Devices ........68 On an Android device ..................... 71 USB connection does not work ..................72 Service, Inspection, Repair ........................

  • Page 7: Basic Security Information

    The BARTEC company reserves the right to carry out technical changes at any time. In no event will BARTEC company be responsible or liable for indirect or consequential damages resulting from the use or application of this user manual.

  • Page 8: Languages

    BARTEC or stated on placing an order. Changes in the document BARTEC reserves the right to change the content of this document without notification. No warranty is assumed for the correctness of the information. In cases of doubt, the German safety instructions apply because it is not possible to rule out errors of translation or printing.

  • Page 9: Unintended Use

    Mobile Computer MC 92N0 Basic Security Information Type 17-A1A.-………… and Type B7-A2A.-………… Unintended use Any other use is unintended and may lead to damage and accidents. The manufacturer shall not be liable for any use extending beyond the exclusive purpose. Duties of the operator The operator undertakes to only permit persons to work with the Mobile Computers who are acquainted with the basic regulations on safety and accident prevention, and who...

  • Page 10: Repairs

    Mobile Computer MC 92N0 Basic Security Information Type 17-A1A.-………… and Type B7-A2A.-………… Repairs Repairs to explosion-protected devices may only be performed by authorised personnel with original spare parts and according to the state of the art. The applicable provisions must be observed in this respect. Commissioning It must be checked that all components and documents are available before commissioning.
  • Page 11 Mobile Computer MC 92N0 Basic Security Information Type 17-A1A.-………… and Type B7-A2A.-………… Unintended use of the Mobile Computers. Incorrect assembly, commissioning, operation and servicing. − Failure to observe the information in the User Manual with respect to transport, storage, − assembly, installation, commissioning, operation and service.

  • Page 12: Co-Applicable Documents - Set Of Documents

    MC 92N0 Basic Security Information Type 17-A1A.-………… and Type B7-A2A.-………… Co-applicable documents – Set of documents BARTEC User Manual to the Mobile Computer series MC 92N0 – The use of the explosion- − protected version of the Mobile Computer series MC 92N0 is described in this User Manual.

  • Page 13: Configuration

    Mobile Computer MC 92N0 Basic Security Information Type 17-A1A.-………… and Type B7-A2A.-………… 1.11 Configuration This Manual refers to the following configurations: Configuration Version Wireless WLAN:  WIN CE/WEH: 802.11 a/b/g/n/d/h/i Android: 802.11 a/b/g/n/d/h/i/k/r WPAN:  WIN CE/WEH: Microsoft-Stack: Bluetooth 2.1 EDR Stonestreet-Stack: Bluetooth 4.0 plus BLE or WBA Android: Bluetooth 4.0 BLE...

  • Page 14: Product Description

    Definition MC 92N0 -IS Version The MC 92N0 -IS Mobile Computer is a robust mobile computer designed for industrial use and has been specially modified by BARTEC for use in hazardous (potentially explosive) areas in ATEX/IECEx Zone 1 − UL Class I, II Division 1 and Class III −...

  • Page 15: Definition Mc 92N0 Ex -Ni Version

    (EMDK) or the additional Mobility DNA solutions from ZEBRA. 1 GB RAM and 2 GB flash memory are integrated in the device for storing user-defined applications and data. For larger applications and volumes of data, BARTEC offers SD memory cards.
  • Page 16 (EMDK) or the additional Mobility DNA solutions from ZEBRA. 1 GB RAM and 2 GB flash memory are integrated in the device for storing user-defined applications and data. For larger applications and volumes of data, BARTEC offers SD memory cards.

  • Page 17: Technical Data

    Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Technical Data Explosion protection IS ATEX Zone 1 Type 17-A1A3-0…/S…… MC 92N0 17-A1A3-R..1/S……. MC 92N0 -IS RFID 17-A1A3-R..3/S……. 17-A1A3-R..A/S……. 17-A1A3-R..B/S……. Ex protection II 2G Ex q [ib] IIC T4 Gb Type 17-A1A3-R..C/S…….

  • Page 18: Explosion Protection Ni

    Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… UL Class I, II, III Division 1 Type 17-A1A2-0…/S……. MC 92N0 17-A1A2-R…/S……. MC 92N0 -IS RFID Ex protection Class I Division 1 Groups C and D Class II Division 1 Groups F and G Class III Certificate USA and Canada E226123...
  • Page 19 Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… IECEx Zone 2/22 Type B7-A2A.-0.A0/S……. MC 92N0 B7-A2A.-0.J0/S……. B7-A2A.-0.30/S……. B7-A2A.-0.50/S……. B7-A2A.-0.90/S……. Ex protection Ex ic IIC T6 Gc Ex ic IIIB T80°C Dc IP64 Type B7-A2A.-0.L0/S……. MC 92N0 B7-A2A.-0.M0/S……. B7-A2A.-R..1/S…….

  • Page 20: Other Applicable Standards

    Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… UL Class I, II, III Division 2 Type B7-A2A4-0…/S……. MC 92N0 B7-A2A4-R…/S……. MC 92N0 -NI RFID Ex protection Class I Division 2 Groups A, B, C and D Class II Division 2 Groups F and G Class III Certificate USA and Canada E321557...

  • Page 21: Features

    Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Features Performance features Dual-Core 1 GHz OMAP 4430-Processor Operating system Windows Embedded Handheld WEH 6.5.3 Windows Embedded Compact 7 (CE 7.0) Android 4.4.4 Memory 1 GB RAM; 2 GB Flash Extension slot SD card slot with SDHC support...
  • Page 22 Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Weight Depends on version and configuration ATEX/IECEx (including battery) MC 92N0 ca. 1060 g approx. 37 oz MC 92N0 -G with internal RFID: ca. 1060 g approx. 37 oz MC 92N0 -G with internal RFID + external antenna:...
  • Page 23 Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Display 3,7"-VGA- colour display VGA mode: 480 x 640 pixel (width x height) QVGA mode: 240 x 320 pixel (width x height) (Windows CE only) Touchscreen Analogue-resistive touchscreen Background lighting LED technology Network connections Ethernet (via charge station);...

  • Page 24: User Environment

    Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Alpha numeric Numeric keypad keypad Alpha numeric Numeric keypad with with printing keypad (F) function keys for VT emulation 28 keys 43 keys 53 keys 53 keys No emulation software is installed on the Mobile Computers with the emulation key version.

  • Page 25: Application Development

    Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Application development Software: No functional changes were made to the device because of the explosion protection. All tools and applications available from Zebra for the MC9200 are compatible with the MC92N0ex version.
  • Page 26 Type 17-A1A.-………… and Type B7-A2A.-………… As software for individual application development, RFID BARTEC offers a demo version in Open Source and an SDK file. The SDK file is available for the C# programming language and contains all necessary resources for specific application development under Windows®...

  • Page 27: Voice And Data Transmission Wireless Lan

    Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Voice and data transmission Wireless LAN WLAN radio module Radio standard Android: IEEE 802.11 a/b/g/n/d/h/i/k/r WinCE/WEH: IEEE 802.11 a/b/g/n/d/h/i Note: IEEE802.11 a is not available in Thailand Output power 100 mW (USA and International) Data rate IEEE802.11a: up to 54 Mbit/sec.

  • Page 28: Voice And Data Transmission Wireless Pan

    Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Voice and data transmission Wireless PAN Windows operating system: Microsoft stack: (preinstalled by default) Bluetooth Version 2.1 with Bluetooth Stonestreet stack (can be optionally activated) Bluetooth 4.0 Plus BLE or Android operating system: Bluetooth version 4.0 with low energy consumption Maximum Output Power...

  • Page 29: Barcode Capture Options

    Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Barcode capture options Available for the following Available approvals/ Barcode capture Form operating systems Ex versions Version IS Version NI Windows MC92N0 MC92N0 Android 1D-Barcodes 4.4.4 17-A1A.-… B7-A2A.-… CE/WEH Brick 1D Standard Range SE965-SR...

  • Page 30: Reading Distances

    Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Reading distances Barcode capture Reading distance 1D-Barcodes minimum maximum 2,5 cm 130 cm 1D Standard Range SE965-SR Scan Engine 0.98 inch 51.18 inch 5 cm 1370 cm 1D Extended Range SE1524-ER Scan Engine 1.97 inch...

  • Page 31: Decodable Barcode Types

    Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Decodable barcode types DPM Codes (only with All supported 2D-Barcodes SE4500-HD) All supported 1D-Barcodes (only supported with Imager versions) mounted on 1D-Symbol/Codes 2D-Symbol/Codes Code 11 Code 39 Aztec Micro PDF-417 Metal Code 93 Code 128...
  • Page 32 Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… The maximum read / write ranges of the different RFID readers are dependent on various environmental and ambient conditions and refer in the following to office environment. e.g. Transponder (Tag), size Mounting surface (metal, wood or different) Environment conditions Magnetic influence from outside...
  • Page 33 Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… LF Reader (internal module) For MC 92N0 -G (Gun) and MC 92N0 -K (Brick) Combination with Scan Engine is not possible! Nominal reading distance up to approx. 5 cm up to approx.
  • Page 34 902.0 to 928.0 MHz (FCC CFR 47 Part 15.247) Supported standards EPC Class 1 Gen 2 tag Further information on the RFID Reader and the available SDK software can be found separately BARTEC Support Download page. http://automation.bartec.de/indexE.htm Category - Mobile Computers...

  • Page 35: Battery

    Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Battery Battery (charge only outside of hazardous location) Type 17-A1Z0-0001 Lithium Ion battery 7.2 / 2800 mAh (20.16 Wh) for MC 92N0 type 17-A1A3-… Type 17-A1Z0-0023 Lithium Ion battery 7.4 / 2600 mAh (19.3 Wh) for MC 92N0 type 17-A1A2-….

  • Page 36: External Interfaces

    Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… External interfaces Restrictions: The 17-pole data interface should only be used outside the potentially explosive − atmosphere and exclusively with the devices stated by the manufacturer! Signal name Function Signal name Function USB_GND...

  • Page 37: Product Labelling

    Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Product labelling CAUTION - CLASS 3R LASER LIGHT WHEN OPEN. Laser warning AVOID DIRECT EYE EXPOSURE. ATTENTION - LUMIÈRE LASER DE CLASSE 3R, EN CAS D’OUVERTURE. EXPOSITION DANGEREUSE AU FAISCEAU. VORSICHT - LASERLICHT KLASSE 3R, WENN ABDECKUNG GEÖFFNET.
  • Page 38 Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Additional marking Zone 2 Type: B7-A2A4-…./…….. Laser warning Type label e.g. for ATEX/IRCEx Zone 1 CAUTION - CLASS 2 LED LIGHT. Laser warning WHEN OPEN. DO NOT STARE INTO THE BEAM. ATTENTION - LUMINERE LED DE CLASSE 2.

  • Page 39: Laser Labels

    Mobile Computer MC 92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Battery marking Type 17-A1Z0-0001 Type 17-A1Z0-0023 Type B7-A2Z0-0044 Laser labels In compliance with IEC 60825 and EN 60825, Clause 5 the following information is provided: DEUTSCH KLASSE 1 KLASSE 1 LASER PRODUKT KLASSE 2 LASERLICHT NICHT IN DEN LASERSTRAHL SEHEN...

  • Page 40: Transport And Storage

    Replace the battery if the operating time has shortened considerably. The standard warranty period for all BARTEC batteries is 6 months, whereby it is irrelevant whether the battery was acquired separately or was contained in the scope of delivery of the MC92N0 Technical data subject to change without notice..

  • Page 41: Commissioning

    Scope of delivery 1 x MC 92N0 1 x Lithium-ion battery 1 x Stylus 1 x Hand strap 1 x User Manual Accessories optional Authorised accessories from BARTEC: SD card − Replacement stylus − Battery − Docking station for communication and charging −...

  • Page 42: Requirements In Potentially Explosive Atmosphere

    Mobile Computer MC 92N0 Commissioning Type 17-A1A.-………… and Type B7-A2A.-………… Requirements in potentially explosive atmosphere Mobile Computer The Mobile Computer may not be opened. Do not use, swap or replace any non-specified components. Do not retrofit any components to the internal plugs or slots. Exception: SD-card Protect the Mobile Computer from impact! Do not expose the Mobile Computer to caustic/aggressive liquids, vapours, mists!

  • Page 43: First Steps

    Type 17-A1A.-………… and Type B7-A2A.-………… Accessories Only install or replace accessories outside the potentially explosive atmosphere. Use accessories exclusively which have been tested or certified by BARTEC for this purpose. The end user can replace the SD card, screen protector, keypad and leather holster himself.

  • Page 44: Handling Accessories

    Type 17-A1A.-………… and Type B7-A2A.-………… Handling accessories DANGER Non-certified accessories endanger explosion protection. There is a risk of fatal injury in an explosive atmosphere! Only use original accessories from BARTEC/ZEBRA.  Only permitted outside the potentially explosive atmosphere: Charge battery. ...
  • Page 45 The battery (type 17-A1Z0-0001 and 17-A1Z0-0023) may be inserted/changed in hazardous areas. 3. Use only batteries which have been tested or certified by BARTEC for this purpose. 4. Insert the battery with the battery contacts facing forwards into the battery compartment under the keypad.

  • Page 46: Change Keypad

    Mobile Computer MC 92N0 Commissioning Type 17-A1A.-………… and Type B7-A2A.-………… Change keypad The MC 92N0 has interchangeable modular keypads. DANGER Non-certified accessories endanger explosion protection. There is a risk of fatal injury in an explosive atmosphere! It must be ensured that only original keypads are used in safety-oriented operation. ...
  • Page 47 Mobile Computer MC 92N0 Commissioning Type 17-A1A.-………… and Type B7-A2A.-………… Pull the keypad downwards in the direction of the arrow and then forwards to take it out of the MC 92N0 Check that the contacts and seals are clean and in good condition. Insert both of the keyboard’s guide pins into the guide grooves (see illustration) on the mobile computer housing.
  • Page 48 Mobile Computer MC 92N0 Commissioning Type 17-A1A.-………… and Type B7-A2A.-………… Check that the keypad is mounted correctly. Tighten the screws (torque = 0.452 Nm / torque = 4.0 in-lbs); 0.5 Nm is advisable. Attention: Always use the correct torque. 10. After the exchange of the keyboard a cold boot (see chapter 7.1 "Resetting the MC 92N0 ") must be performed.

  • Page 49: Insert Sd Card

    Work steps: Only install or replace the SD card outside the potentially explosive atmosphere. Only use SD cards which have been tested and certified by BARTEC for this purpose. Press the red button "ON/OFF" to suspend the MC 92N0 Remove the battery (see chapter 5.5.1 "Insert/change battery") Remove the two keypad screws and slide the keypad down and lift off (see chapter 5.5.2 "Change keypad").

  • Page 50: Remove/Replace Screen Protector

    Attach the screen protector in accordance with the “Screen protector installation instructions”. You can order screen protector from your customer consultant or from BARTEC. Installation instructions for the screen protector are part of the delivery scope. Part number: 17-A1Z0-0004 screen protector, pack of 5.

  • Page 51: Leather Holster

    Mobile Computer MC 92N0 Commissioning Type 17-A1A.-………… and Type B7-A2A.-………… Leather holster BARTEC offers holsters to protect the MC 92N0 series. DANGER Non-certified accessories endanger explosion protection. There is a risk of fatal injury in an explosive atmosphere! Use only the original leather holsters.

  • Page 52: Connection To A Pc

    Mobile Computer MC 92N0 Commissioning Type 17-A1A.-………… and Type B7-A2A.-………… Connection to a PC The MC 92N0 -IS series is supplied with the Operating system Microsoft Windows Embedded Handheld 6.5.3 (WEH 6.5.3), Windows Embedded Compact 7 (CE 7.0) or Android 4.4.4. For WEH6.5.3 and CE7.0: Microsoft provides software free of charge for connection to a PC for synchronisation, installation and data exchange.

  • Page 53: Android

    Mobile Computer MC 92N0 Commissioning Type 17-A1A.-………… and Type B7-A2A.-………… Android There are several ways to exchange or synchronize data from Android devices with a Windows PC. 1. Manually via USB. When an Android device is connected to a Windows PC via USB, it appears as a drive on the PC that can be selected.

  • Page 54: Operation

    Mobile Computer MC 92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… Operation The operator using an electric system in an potentially explosive environment must keep the accompanying operation equipment in a good condition, operate and monitor it correctly and conduct the requisite services and repairs. Before commissioning the devices, it must be checked that all components and documents are available.

  • Page 55: Care And Cleaning

    Mobile Computer MC 92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… Care and cleaning We recommend that the devices be cleaned regularly depending on use and also treated with care to ensure smooth and trouble-free operation. Care Display Only use with supplied stylus for the touchscreen −...

  • Page 56: Suitable Materials

    Mobile Computer MC 92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… The following precautionary measures should be taken for your own safety and to ensure the operational safety of the device: ATTENTION Devices and accessories can be destroyed if handled incorrectly. Generally separate the charger from the power supply.

  • Page 57: Operation Recommendations And Requirements

    Mobile Computer MC 92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… Separate the charging station or the docking-station from the power Contacts in charging station or supply to clean the charger contacts. docking-station Soak the cotton swabs in an alcohol solution to remove all grease −...
  • Page 58 Mobile Computer MC 92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… Vehicle installation RF signals may impair incorrectly installed or inadequately shielded electronic systems in vehicles (including safety systems). If you have any questions on your vehicle, get in touch with the manufacturer or a sales person. You can also learn from the manufacturer whether additional equipment has been fitted to the vehicle.

  • Page 59: Instructions On The Use Of Wireless Devices

    Mobile Computer MC 92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… Call for help using your mobile device if necessary. Dial the emergency services (9-1- 1 in the USA and 1-1-2 in Europe) or other local emergency service numbers in the event of fire, accidents or medical emergences.

  • Page 60: Equipment Of The Laser Devices

    Equipment of the laser devices Devices from BARTEC/ZEBRA equipped with lasers comply with the Guidelines 21CFR1040.10 and 1040.11. (with the exception of the deviations set out in the Laser Notice No. 50 dated 24 June 2007) and EN 60825-1:2001,2007 und EN 62471:2006. The classification of the laser device is stated on a plate attached to the device.

  • Page 61: Led Devices

    Radio Modules The device contain approved radio module(s). These module(s) are identified below. BARTEC/ZEBRA radio module supporting WLAN 802.11 a/b/g/n and Bluetooth. Type(s): 21-148603-0B Bluetooth® Wireless Technology This is an approved Bluetooth® product. For more information or to view End Product Listing, please visit https://www.bluetooth.org/tpg/listings,cfm...

  • Page 62: Frequency Of Operation - Fcc And Ic

    Mobile Computer MC 92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… Frequency of Operation – FCC and IC 5 GHz Only The use in the UNII (Unlicensed National Information Infrastructure) band 1 5150 -5250 MHz band is restricted to Indoor Use Only; any other use will make the operation of this device illegal.
  • Page 63 Mobile Computer MC 92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… Radio Transmitters (Part 15) This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 64: Electromagnetic Fields

    Conformity (DoC) at https://www.zebra.com/us/en/about-zebra/company-information/compliance.html Europe Handheld Devices This device was tested for typical body-worn operation. Use only BARTEC tested and approved belt-clips, holsters, and similar accessories to ensure EU Compliance. Technical data subject to change without notice.. 58/78 Revision B / 03/2019...

  • Page 65: Handheld Devices

    Handheld Devices This device was tested for typical body-worn operation. Use only BARTEC tested and approved belt-clips, holsters, and similar accessories to ensure FCC Compliance. The use of third-party belt-clips, holsters, and similar accessories may not comply with FCC RF exposure compliance requirements, and should be avoided.

  • Page 66: Optimise Operating Times/Change Energy Settings

    Mobile Computer MC 92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… Optimise operating times/change energy settings Factory settings of the MC 92N0 -IS for the WWAN and WLAN radio devices: ON. Instructions and notes for optimizing or changing settings for operating systems Windows Embedded Handheld 6.5.3 (WEH6.5.3) •...

  • Page 67: Change Display Backlight (Increases The Operating Time Of The Battery)

    Mobile Computer MC 92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… Change display backlight (increases the operating time of the battery) For Windows Embedded Handheld 6.5.3 (WEH6.5.3) Symbols In the start menu under: > Settings symbol > System symbol > Backlight symbol >...

  • Page 68: Change Keypad Background Lighting (Increases The Operating Time Of The Battery)

    Mobile Computer MC 92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… Change keypad background lighting (increases the operating time of the battery) For Windows Embedded Handheld 6.5.3 (WEH6.5.3) Symbols In the start menu under: > Settings symbol > System symbol > Keylight symbol >...

  • Page 69: Switch Off Radio Connections

    Mobile Computer MC 92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… Switch off radio connections Products with Bluetooth® Wireless technology: This device is an approved Bluetooth® product. Further information is available at http://www.bluetooth.org/tpg/listings.cfm Manufacturer: ZEBRA For Windows Embedded Handheld 6.5.3 (WEH6.5.3) Symbols Windows Embedded Handheld 6.5.3 devices have a simple and central possibility in the...

  • Page 70: Software Versions

    Mobile Computer MC 92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… Software versions Existing software versions and operating systems in the MC92N0 –IS: The software is not relevant to the explosion protection of the device. See the ZEBRA documentation for further information. For Windows Embedded Handheld 6.5.3 (WEH6.5.3) In the start menu under: Symbols...

  • Page 71: Aku

    Mobile Computer MC 92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… For Windows Embedded Handheld 6.5.3 (WEH6.5.3) Symbols In the start menu under: > Settings symbol > System symbol > About symbol > Version tab The last part of the build number contains storage battery number.

  • Page 72: Bluetooth

    Mobile Computer MC 92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… Bluetooth The “BTExplorer” application is only available if the “StoneStreet One Bluetooth Stack” function is activated. Further information is provided in the ZEBRA “User Manual on Integration”. For Windows Embedded Handheld 6.5.3 (WEH6.5.3) Symbols In the start menu under: >...

  • Page 73: Fusion"Software

    Mobile Computer MC 92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… “Fusion”software For Windows Embedded Handheld 6.5.3 (WEH6.5.3) Symbols In the start menu under: > Wireless Companion symbol > Wireless Status symbol > Point 7 “Versions” For Windows Embedded Compact 7 (CE7.0) Path specification: 1.

  • Page 74: Faults And Troubleshooting

    Faults and Mobile Computer MC 92N0 Troubleshooting Type 17-A1A.-………… and Type B7-A2A.-………… Faults and Troubleshooting DANGER There is a risk of fatal injury in an explosive atmosphere! Examine defective devices and any accessories only outside the potentially  explosive atmosphere. Information on fault rectification is provided in the User Manual or the Integration Manual on the ZEBRA website.
  • Page 75 Mobile Computer MC 92N0 Faults and Type 17-A1A.-………… and Type B7-A2A.-………… Troubleshooting ATTENTION Incorrect handling may cause damage to property! Data stored in the flash memory or on a memory card is not lost. First perform a  warm boot. The MC 92N0 is re-started and all stored data records and entries are preserved.
  • Page 76 Faults and Mobile Computer MC 92N0 Troubleshooting Type 17-A1A.-………… and Type B7-A2A.-………… On a Windows Embedded Handheld (WEH) 6.5.3 device A warm boot starts the MC92N0 again and shuts down all running programs. − A cold boot also restarts the MC92N0ex, but erases all stored records and entries in −...

  • Page 77: On An Android Device

    Mobile Computer MC 92N0 Faults and Type 17-A1A.-………… and Type B7-A2A.-………… Troubleshooting Clean Boot ATTENTION Incorrect handling may cause damage to property! Performing a clean boot restores formats, preferences and other settings to the  factory settings. Perform Clean Boot: Download the File: “Clean Boot Package”...

  • Page 78: Usb Connection Does Not Work

    Faults and Mobile Computer MC 92N0 Troubleshooting Type 17-A1A.-………… and Type B7-A2A.-………… Cold boot ATTENTION Incorrect handling may cause damage to property! Performing a hard reset with an SD card installed in the MC9200 may cause  damage or data corruption to the data on SD card or the SD card itself. To perform a hard reset (if the device is completely non-responsive, skip steps 1 and 2): 1.
  • Page 79 Mobile Computer MC 92N0 Faults and Type 17-A1A.-………… and Type B7-A2A.-………… Troubleshooting Solution: Use of an external USB hub with external power supply. Important note: The USB interface used must be a maximum of USB 2.0 • USB 3.0 is not supported •...

  • Page 80: Service, Inspection, Repair

    Disposal, Dispatch and Mobile Computer MC 92N0 Packaging Type 17-A1A.-………… and Type B7-A2A.-………… Service, Inspection, Repair Commissioning and service of Mobile Computers may be conducted exclusively by trained and qualified staff! The staff is familiar with the installation, assembly, commissioning and operation of the Mobile Computers, has been informed about the risks and has the qualifications necessary for this work.

  • Page 81: Information On Sending In For Repairs

    Then complete the RMA form (Return Merchandise Authorization), sign it and send it to our “Returns Centre”. E-Mail: services@bartec.de Fax: +49 7931 597-119 We cannot guarantee the processing within the contractually agreed period for any returns received by us without RMA number.

  • Page 82: Disposal

    Disposal, Dispatch and Mobile Computer MC 92N0 Packaging Type 17-A1A.-………… and Type B7-A2A.-………… Disposal The Mobile Computers contain metallic and plastic parts and electronic components. Our devices are intended as professional electric devices for business use only, referred to as B2B devices under the WEEE-Directive. The WEEE directive sets the framework for waste electric and electronic equipment handling procedures which are to apply throughout the EU.

  • Page 83: Accessories, Spare Parts

    Mobile Computer MC 92N0 Accessories, Spare Parts Type 17-A1A.-………… and Type B7-A2A.-………… Accessories, Spare Parts Mobile Computer MC 92N0 Description Order number Spare battery 7.2 V/2800 mAh, Li-Ion Battery ATEX/IECEx 17-A1Z0-0001 7.4 V/2600 mAh, Li-Ion Battery 17-A1Z0-0023 Spare keypad with blue overlay for ATEX / IECEx / UL - ATEX and Division 1 with 28 keys 05-0080-0438 with 43 keys...
  • Page 84 Mobile Computer MC 92N0 Accessories, Spare Parts Type 17-A1A.-………… and Type B7-A2A.-………… General Description Order number SD cards with 2 GB 17-28BE-F006/0003 with 4 GB 17-28BE-F006/0004 with 8 GB 17-28BE-F006/0005 with 16 GB 17-28BE-F006/0006 with 32 GB 17-28BE-F006/0007 Screen protector 5 pieces per package 17-A1Z0-0004 Leather Holster...

  • Page 85: Additional Information

    Type 17-A1A.-………… and Type B7-A2A.-………… Additional Information 12.1 Links https://www.bartec.de/en/ BARTEC website http://www.bartec.de/automation-download/ BARTEC Downoad website https://www.zebra.com/de/de.htmlS ZEBRA website The ZEBRA page for the MC9200 User Manuals and software of the non-explosion protected version Support and Downloads − Mobile Computers −...
  • Page 86 Mobile Computer MC 92N0 Declaration of Conformity Type 17-A1A.-………… and Type B7-A2A.-………… Declaration of Conformity Mobile Computer MC92N0 -IS – Zone 1 Technical data subject to change without notice.. Revision B / 03/2019...
  • Page 87 Declaration of Conformity Type 17-A1A.-………… and Type B7-A2A.-………… Mobile Computer MC 92N0 -NI – Zone 2/22 Mobile Computer MC 92N0 -NI – Zone 2/22 All certification see https://www.bartec.de/en/  Technical data subject to change without notice. Revision B / 03/2019...
