Summary of Contents for Bartec MC92N0EX

Page 1 Reservation: Technical data subject to change without notice. Changes, errors and misprints may not be used as a basis for any claim for damages. Contents Page English 1 – 73 Appendix Declaration of Conformity BARTEC GmbH Contact: Max-Eyth-Straße 16 Phone: +49 7931 597-0 Service-mobilecomputing@bartec.de Download: 97980 Bad Mergentheim...
Page 3 Mobile Computer MC92N0 Table of Content Type 17-A1A.-………… and Type B7-A2A.-………… Technical data subject to change without notice. Revision D / Status 10/2016...
Page 4 Mobile Computer MC92N0 Table of Content Type 17-A1A.-………… and Type B7-A2A.-………… Technical data subject to change without notice. Revision D / Status 10/2016...
Page 5: Table Of Contents
Mobile Computer MC92N0 Table of Content Type 17-A1A.-………… and Type B7-A2A.-………… Basic Security Information........................1 Information on this User Manual ..................1 1.1.1 Languages ........................2 1.1.2 Changes in the document ....................2 Handling the product ......................2 Intended use ........................2 1.3.1 Exclusive purpose ......................
Page 6 Mobile Computer MC92N0 Table of Content Type 17-A1A.-………… and Type B7-A2A.-………… Transport and Storage ........................34 Transport ........................34 Storage ........................... 34 Commissioning ........................... 35 Scope of delivery ......................35 5.1.1 Accessories optional....................... 35 Requirements in potentially explosive atmosphere ............36 First steps ........................
Page 7 Mobile Computer MC92N0 Table of Content Type 17-A1A.-………… and Type B7-A2A.-………… 6.8.2 AKU ..........................63 6.8.3 Bluetooth ........................63 6.8.4 “Fusion”software ......................64 Faults and Troubleshooting ....................... 65 Resetting the MC92N0 ....................65 7.1.1 Windows Embedded Handheld and Windows CE Devices ..........65 7.1.2 On a Windows CE 7.0 device ..................
Page 9 - blank -...
Page 11: Basic Security Information
Mobile Computer MC92N0 Basic Security Information Type 17-A1A.-………… and Type B7-A2A.-………… Basic Security Information Information on this User Manual Read carefully before putting the devices into operation. The User Manual is a fixed part of the product. It must be kept in the direct vicinity of the device and the installation, operating and service staff must have access to it at all times.
Page 12: Languages
1.1.2 Changes in the document BARTEC reserves the right to change the content of this document without notification. No warranty is assumed for the correctness of the information. In cases of doubt, the German safety instructions apply because it is not possible to rule out errors of translation or printing.
Page 13: Duties Of The Operator
Mobile Computer MC92N0 Basic Security Information Type 17-A1A.-………… and Type B7-A2A.-………… Duties of the operator The operator undertakes to only permit persons to work with the Mobile Computers who are acquainted with the basic regulations on safety and accident prevention, and who ...
Page 14: Repairs
Mobile Computer MC92N0 Basic Security Information Type 17-A1A.-………… and Type B7-A2A.-………… 1.6.3 Repairs Repairs to explosion-protected devices may only be performed by authorised personnel with original spare parts and according to the state of the art. The applicable provisions must be observed in this respect. 1.6.4 Commissioning It must be checked that all components and documents are available before...
Page 15 Mobile Computer MC92N0 Basic Security Information Type 17-A1A.-………… and Type B7-A2A.-………… Unintended use of the Mobile Computers. Incorrect assembly, commissioning, operation and servicing. − Failure to observe the information in the User Manual with respect to transport, − storage, assembly, installation, commissioning, operation and service. Independent structural changes.
Page 16: Co-Applicable Documents - Set Of Documents
Mobile Computer MC92N0 Basic Security Information Type 17-A1A.-………… and Type B7-A2A.-………… Co-applicable documents – Set of documents BARTEC User Manual to the Mobile Computer series MC92N0 – The use of the explosion- − protected version of the Mobile Computer series MC92N0 is described in this User Manual.
Page 17: Configuration
Mobile Computer MC92N0 Basic Security Information Type 17-A1A.-………… and Type B7-A2A.-………… 1.11 Configuration This Manual refers to the following configurations: Configuration Version Wireless WLAN: 802.11 a/b/g/n  WPAN: Bluetooth 2.1 EDR  Reader options RFID-LF 125 kHz / 134 kHz ...
Page 18: Product Description
Definition MC92N0 -IS Version The MC92N0 -IS Mobile Computer is a robust mobile computer designed for industrial use and has been specially modified by BARTEC for use in hazardous (potentially explosive) areas in ATEX and IECEx Zone 1 − UL Class I, II Division 1 −...
Page 19: Definition Mc92N0 Ex -Ni Version
Developer Kits (EMDK) or RohMobile Suite from Zebra. 1 GB RAM and 2 GB flash memory are integrated in the device for storing user-defined applications and data. For larger applications and volumes of data, BARTEC offers SD memory cards. Definition MC92N0...
Page 20: Operation
Developer Kits (EMDK) or RohMobile Suite from Zebra. 1 GB RAM and 2 GB flash memory are integrated in the device for storing user-defined applications and data. For larger applications and volumes of data, BARTEC offers SD memory cards. Operation The Mobile Computer MC92N0 -IS is a handheld electrical device.
Page 21: Rfid / Rubee
Mobile Computer MC92N0 Product Description Type 17-A1A.-………… and Type B7-A2A.-………… The Mobile Computer MC92N0 -IS, Type 17-A1A.-…./…….. have been modified for use in the following potentially explosive atmospheres ATEX/IECEx Zone 1 − UL Class I Division 1 Groups C and D −...
Page 22: Technical Data
Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Technical Data Explosion protection IS ATEX Zone 1 Type 17-A1A3-0…/S……. MC92N0 17-A1A3-R…/S…… MC92N0 -IS RFID Ex protection II 2G Ex q [ib] IIC T4 Gb Type 17-A1A3-R..C/S……. MC92N0 -IS RFID 17-A1A3-R..D/S…….
Page 23: Explosion Protection Ni
Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Explosion protection NI ATEX Zone 2/22 Type B7-A2A4-0…/S……. MC92N0 B7-A2A4-R…/S……. MC92N0 -NI RFID/RuBee Ex protection II 3G Ex nA IIC T6 Gc II 3D Ex tc IIIC T80 °C Dc -20 °C ≤...
Page 24: Other Applicable Standards
Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Other applicable standards Electrical safety Information technology equipment - Safety - EN 60950-1:2006 +A12:2011 Part 1: General requirements Radio Specification - WLAN / Bluetooth Electromagnetic compatibility and Radio spectrum Matters (ERM) - Wideband EN 300 328 V1.8.1 transmission systems - Data transmission equipment operating in the 2,4 GHz ISM band...
Page 25 Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Electro Magnetic Compatibility (EMC) Specifications EMC Tests on Radio and Telecommunications EN 301 489-1 V1.9.2 Terminal Equipment Part 1: Common EMC Requirements Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic EN 301 489-3 V1.6.1 Compatibility (EMC) standard for radio equipment and services...
Page 26: Features
Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Features 3.4.1 Performance features Dual-Core 1 GHz OMAP 4430-Processor Operating system Windows Embedded Handheld WEH 6.5.3 or Windows CE 7.0 Memory 1 GB RAM; 2 GB Flash Extension slot SD card slot with SDHC support (up to 32 GB) Optionally extendable with SD card: 1 GB Order number 17-28BE-F006/0002...
Page 27 Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Display 3,7"-VGA- colour display VGA mode: 480 (width) x 640 pixel (height) QVGA mode: 240 (width) x 320 pixel (height) (Windows CE only) Touchscreen Analogue-resistive touchscreen Background lighting LED technology Network connections Ethernet (via charge station);...
Page 28: User Environment
Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Alpha numeric keypad Alpha numeric keypad Alpha numeric keypad with printing for VT with printing for 3270 with printing for 5250 emulation emulation emulation 53 keys 53 keys 53 keys No emulation software is installed on the Mobile Computers with the emulation key version.
Page 29: Application Development
Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… 3.4.4 Application development PSDK (Platform Software Development Kit) and EMDK (Enterprise Mobility Developer Kit) is available via the ZEBRA Solutions Website. Available for − .Net − Browser support: Pocket Browser or “RhoMobile Suite” from ZEBRA Solutions for application development. RhoMobile Suite Toolkit Technology-independent applications are prepared consists of:...
Page 30: Voice And Data Transmission Wireless Lan
Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… 3.4.5 Voice and data transmission Wireless LAN WLAN radio module Radio standard Tri Mode IEEE 802.11a/b/g/n Data rate IEEE802.11a: up to 54 Mbit/sec. IEEE802.11b: up to 11 Mbit/sec. IEEE802.11g: up to 54 Mbit/sec. IEEE802.11n: up to 65 Mbit/sec.
Page 31: Data Capture Options
Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… 3.4.8 Data Capture Options Five available configuration – 1D-Standard-Range Laser Scanner possibilities (SE965) – 1D-Long-Range Laser Scanner Lorax SE1524) – 1D-/2D-Imager (Blockbuster SE4500-SR) – 1D-/2D-Imager DPM (Direct Part Marking) (Blockbuster SE4500-HD) Only for NI Version –...
Page 32 Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… 3.4.8.2 1D-Long-Range Laser Scanner (Lorax SE1524) Lorax SE1524 1D scan engine decodes/reads 1D barcodes/symbols For MC92N0 -G (Gun) versions: Further detailed information on the Lorax SE1524 can be found in the “User Manual“ or “Integrator Guide”...
Page 33 Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… 3.4.8.4 1D-/2D-Imager DPM (Blockbuster SE4500-HD) SE4500-HD 1D/2D Imager Engine with DPM decodes/reads a wide range of DPM markings on metal, plastic and glass surfaces, including dot peening, laser etching, casting, stamping or moulding. For MC92N0 -G (Gun) and MC92N0 -K (Brick) versions:...
Page 34 Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Laser class CDRH Class II / IEC 825 Class 2 Decode range, near up to approx. 5.8 cm with 5 mil Code 128 up to approx. 2.3 inches Decode range, far up to approx.
Page 35 Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… 3.4.8.7 1D-/2D-Long Range Imager (SE4600-LR) SE4500-SR 1D/2D Imager Engine (omni-directional) decodes/reads 1D and 2D barcodes/symbols For MC92N0 -G (Gun), type B7-A2A4-.G.. versions: Further detailed information on the SE4600-LR can be found in the “User Manual“ or “Integrator Guide”...
Page 36: Decodable Barcode Types
Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… 3.4.9 Decodable barcode types All supported 2D-Barcodes All supported 1D-Barcodes (only supported with Imager versions) 1D-Symbol/Codes 2D-Symbol/Codes Code 11 Code 39 Aztec Micro PDF-417 Code 93 Code 128 Australian 4-state Maxi Code Codabar Coupon code...
Page 37 Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… 3.4.10.1 LF Reader (internal module) For MC92N0 -G (Gun) and MC92N0 -K (Brick) Combination with Scan Engine is not possible! Nominal reading / writing up to approx. 5 cm distance up to approx.
Page 38 Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… 3.4.10.3 HF Reader (internal module) For MC92N0 -G (Gun) and MC92N0 -K (Brick) Combination with Scan Engine is not possible! Supported standards HF ISO 15693 I-Code SLI, Tag-IT HFI, my-d vicinity, STM LRI512 HF ISO 14443 mifare, mifare Ultra Light, my-d proximity,...
Page 39 Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… 3.4.10.5 UHF Reader (internal module) For MC92N0 -G (Gun) and MC92N0 -K (Brick) Combination with Scan Engine is not possible! Supported standards EPC Class 1 Gen 2 tag Nominal reading range up to approx.
Page 40 Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… 3.4.10.8 UHF Reader (extended module + mounted antenna) For MC92N0 -G (Gun) and MC92N0 -K (Brick) ATEX/IECEx protection type: II 2G Ex q [ib] IIB T4 Gb Supported standards EPC Class 1 Gen 2 tag Nominal reading range up to approx.
Page 41: Battery
Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Battery Battery (charge only outside of hazardous location) Type 17-A1Z0-0001 for type 17-A1A3-… Type 17-A1Z0-0002 for type 17-A1A2-…. Type B7-A2Z0-0006 for type B7-A2A4-... Lithium Ions 7.4 V / 2400 mAh Operating temperature 0 °C to +40 °C +32 °F to 104 °F...
Page 42: Product Labelling
Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Product labelling CAUTION - CLASS 3R LASER LIGHT WHEN OPEN. AVOID DIRECT EYE EXPOSURE. Laser warning ATTENTION - LUMIÈRE LASER DE CLASSE 3R, EN CAS D’OUVERTURE. EXPOSITION DANGEREUSE AU FAISCEAU. VORSICHT - LASERLICHT KLASSE 3R, WENN ABDECKUNG GEÖFFNET.
Page 43: Laser Labels
Mobile Computer MC92N0 Technical Data Type 17-A1A.-………… and Type B7-A2A.-………… Battery Type 17-A1Z0-0001 Type 17-A1Z0-0002 Type B7-A2Z0-0006 Laser labels In compliance with IEC 60825 and EN 60825, Clause 5 the following information is provided: DEUTSCH KLASSE 1 KLASSE 1 LASER PRODUKT KLASSE 2 LASERLICHT NICHT IN DEN LASERSTRAHL SEHEN...
Page 44: Transport And Storage
Replace the battery if the operating time has shortened considerably. The standard warranty period for all BARTEC batteries is 6 months, whereby it is irrelevant whether the battery was acquired separately or was contained in the scope of delivery of the MC92N0 Technical data subject to change without notice..
Page 45: Commissioning
Scope of delivery 1 x MC92N0 1 x Lithium-ion battery 7.4 V / 2400 mAh 1 x Stylus 1 x User Manual 5.1.1 Accessories optional Authorised accessories from BARTEC: SD card − Replacement stylus − Battery 7.4 V / 2400 mAh −...
Page 46: Requirements In Potentially Explosive Atmosphere
Mobile Computer MC92N0 Commissioning Type 17-A1A.-………… and Type B7-A2A.-………… Requirements in potentially explosive atmosphere Mobile Computer The Mobile Computer may not be opened. Do not use, swap or replace any non-specified components. Do not retrofit any components to the internal plugs or slots. Protect the Mobile Computer from impact! Do not expose the Mobile Computer to caustic/aggressive liquids, vapours, mists! Avoid the impact of moisture outside the specifications.
Page 47: First Steps
Type 17-A1A.-………… and Type B7-A2A.-………… Accessories Only install or replace accessories outside the potentially explosive atmosphere. Use accessories exclusively which have been tested or certified by BARTEC for this purpose. The end user can replace the SD card, screen protector, keypad and leather holster himself.
Page 48: Handling Accessories
Lithium-ion battery 7.4 V / 2400 mAh Work steps: 1. Charge the battery only outside hazardous areas. 2. Use only batteries which have been tested or certified by BARTEC for this purpose. 3. Insert the battery with the battery contacts facing forwards into the battery compartment under the keypad.
Page 49: Change Keypad
Mobile Computer MC92N0 Commissioning Type 17-A1A.-………… and Type B7-A2A.-………… 5.5.2 Change keypad The MC92N0 has interchangeable modular keypads. DANGER Non-certified accessories endanger explosion protection. There is a risk of fatal injury in an explosive atmosphere! It must be ensured that only original keypads are used in safety-oriented operation. ...
Page 50 Mobile Computer MC92N0 Commissioning Type 17-A1A.-………… and Type B7-A2A.-………… Pull the keypad downwards in the direction of the arrow and then forwards to take it out of the MC92N0 Check that the contacts and seals are clean and in good condition. Insert both of the keyboard’s guide pins into the guide grooves (see illustration) on the mobile computer housing.
Page 51 Mobile Computer MC92N0 Commissioning Type 17-A1A.-………… and Type B7-A2A.-………… Check that the keypad is mounted correctly. Tighten the screws (torque = 0.452 Nm / torque = 4.0 in-lbs); 0.5 Nm is advisable. Attention: Always use the correct torque. 10. After the exchange of the keyboard a cold boot (see chapter 7.1 "Resetting the MC92N0 ") must be performed.
Page 52: Insert Sd Card
Order number 17-28BE-F006/0007 Work steps: Only install or replace the SD card outside the potentially explosive atmosphere. Only use SD cards which have been tested and certified by BARTEC for this purpose. Press the red button "ON/OFF" to suspend the MC92N0 Remove the battery (see chapter 5.5.1 "Insert battery")
Page 53: Remove/Replace Screen Protector
Attach the screen protector in accordance with the “Screen protector installation instructions”. You can order screen protector from your customer consultant or from BARTEC. Installation instructions for the screen protector are part of the delivery scope. Part number: 17-A1Z0-0003 screen protector, pack of 5.
Page 54: Leather Holster
MC92N0 Commissioning Type 17-A1A.-………… and Type B7-A2A.-………… 5.5.5 Leather holster BARTEC offers holsters to protect the MC92N0 series. The holsters are available in different versions. DANGER Non-certified accessories endanger explosion protection. There is a risk of fatal injury in an explosive atmosphere! Use only the original leather holsters.
Page 55: Rfid/Rubee
Mobile Computer MC92N0 Commissioning Type 17-A1A.-………… and Type B7-A2A.-………… RFID/RuBee The MC92N0 can be optionally equipped with RFID/RuBee This unique idea makes it possible to combine state-of-the-art technologies so that one device can capture barcode data or RFID/RuBee technology. Thanks to modular keyboards and a colour display, the data can be edited directly on the device.
Page 56: Reading Range/Direction
Mobile Computer MC92N0 Commissioning Type 17-A1A.-………… and Type B7-A2A.-………… 5.6.2 Reading range/direction The following specifications relating to ranges refer to an office environment and depend on the standard used, the tags and the environmental influences. Internal LF Reader up to 5 cm Internal HF Reader up to 5 cm Internal UHF Reader...
Page 57: Software
− Android KitKat 4.4 − The SDK, the demo and the relevant descriptions are available free of charge on the BARTEC Download page. http://www.bartec.de/automation-download/ Connection to a PC The MC92N0 -IS series is supplied with the Microsoft WEH 6.5.3 or higher operating system.
Page 58: Operation
Mobile Computer MC92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… Operation The operator using an electric system in an potentially explosive environment must keep the accompanying operation equipment in a good condition, operate and monitor it correctly and conduct the requisite services and repairs. Before commissioning the devices, it must be checked that all components and documents are available.
Page 59: Care And Cleaning
Mobile Computer MC92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… Care and cleaning We recommend that the devices be cleaned regularly depending on use and also treated with care to ensure smooth and trouble-free operation. 6.3.1 Care Display Only use with supplied stylus for the touchscreen −...
Page 60: Suitable Materials
Mobile Computer MC92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… The following precautionary measures should be taken for your own safety and to ensure the operational safety of the device: ATTENTION Devices and accessories can be destroyed if handled incorrectly. Generally separate the charger from the power supply. ...
Page 61: Operation Recommendations And Requirements
Mobile Computer MC92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… Separate the charger from the power supply to clean the charger Charger plug-in connector contacts. Soak the cotton swabs in an alcohol solution to remove all grease − and dirt deposits on the contacts. Repeat cleaning several times −...
Page 62 Mobile Computer MC92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… 6.4.1.2 Vehicle installation RF signals may impair incorrectly installed or inadequately shielded electronic systems in vehicles (including safety systems). If you have any questions on your vehicle, get in touch with the manufacturer or a sales person. You can also learn from the manufacturer whether additional equipment has been fitted to the vehicle.
Page 63: Instructions On The Use Of Wireless Devices
Mobile Computer MC92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… Call for help using your mobile device if necessary. Dial the emergency services (9- 1-1 in the USA and 1-1-2 in Europe) or other local emergency service numbers in the event of fire, accidents or medical emergences. Remember that these calls are free of charge on the wireless device! The call can be made independently of security code or networks with or without the SIM card.
Page 64: Equipment Of The Laser Devices
Mobile Computer MC92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… 6.4.2.3 Heart pacemakers Manufacturers recommend that a minimum distance of 15 cm be observed between a wireless handheld device and a pacemaker to avoid potential interference. This guideline is in line with independent research results and recommendations of Wireless Technology Research.
Page 65: Led Devices
Radio Modules The device contain approved radio module(s). These module(s) are identified below. BARTEC/Zebra radio module supporting WLAN 802.11 a/b/g/n and Bluetooth. Type(s): 21-148603-0B Bluetooth® Wireless Technology This is an approved Bluetooth® product. For more information or to view End Product Listing, please visit https://www.bluetooth.org/tpg/listings,cfm...
Page 66: Frequency Of Operation - Fcc And Ic
Mobile Computer MC92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… Frequency of Operation – FCC and IC 5 GHz Only The use in the UNII (Unlicensed National Information Infrastructure) band 1 5150 -5250 MHz band is restricted to Indoor Use Only; any other use will make the operation of this device illegal.
Page 67 Mobile Computer MC92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… Radio Transmitters (Part 15) This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 68: Electromagnetic Fields
Wireless Communications and Health. Europe Handheld Devices This device was tested for typical body-worn operation. Use only BARTEC Zebra tested and approved belt-clips, holsters, and similar accessories to ensure EU Compliance. Technical data subject to change without notice..
Page 69: Handheld Devices
Handheld Devices This device was tested for typical body-worn operation. Use only BARTEC tested and approved belt-clips, holsters, and similar accessories to ensure FCC Compliance. The use of third-party belt-clips, holsters, and similar accessories may not comply with FCC RF exposure compliance requirements, and should be avoided.
Page 70: Optimise Operating Times/Change Energy Settings (Weh 6.5.3 Only)
Mobile Computer MC92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… Optimise operating times/change energy settings (WEH 6.5.3 only) Factory settings of the MC92N0 -IS for the WWAN and WLAN radio devices: ON. 6.7.1 Automatic shutdown in the case of lengthy standby periods In the start menu under: Symbols >...
Page 71: Change Keypad Background Lighting (Increases The Operating Time Of The Battery)
Mobile Computer MC92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… 6.7.3 Change keypad background lighting (increases the operating time of the battery) Symbols In the start menu under: > Settings symbol > System symbol > Keylight symbol > Battery Power tab Activate “Disable keylight if device if not used for”...
Page 72: Switch Off Radio Connections
Mobile Computer MC92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… 6.7.4 Switch off radio connections Products with Bluetooth® Wireless technology: This device is an approved Bluetooth® product. Further information is available at http://www.bluetooth.org/tpg/listings.cfm Manufacturer: ZEBRA Symbols Windows Embedded Handheld 6.5.3 devices have a simple and central possibility in the form of the Wireless Manager to deactivate and configure all wireless functions of the device.
Page 73: Aku
Mobile Computer MC92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… 6.8.2 Symbols In the start menu under: > Settings symbol > System symbol > About symbol > Version tab The last part of the build number contains storage battery number. 6.8.3 Bluetooth The “BTExplorer”...
Page 74: Fusion"Software
Mobile Computer MC92N0 Operation Type 17-A1A.-………… and Type B7-A2A.-………… 6.8.4 “Fusion”software Symbols In the start menu under: > Wireless Companion symbol > Wireless Status symbol > Point 7 “Versions” Technical data subject to change without notice.. 64/73 Revision D / Status: 10/2016...
Page 75: Faults And Troubleshooting
Mobile Computer MC92N0 Faults and Type 17-A1A.-………… and Type B7-A2A.-………… Troubleshooting Faults and Troubleshooting DANGER There is a risk of fatal injury in an explosive atmosphere! Examine defective devices and any accessories only outside the potentially  explosive atmosphere. Information on fault rectification is provided in the User Manual or the Integration Manual from ZEBRA.
Page 76 Faults and Mobile Computer MC92N0 Troubleshooting Type 17-A1A.-………… and Type B7-A2A.-………… ATTENTION Incorrect handling may cause damage to property! Data stored in the flash memory or on a memory card is not lost. First perform a  warm boot. The MC92N0 is re-started and all stored data records and entries are preserved.
Page 77: On A Windows Embedded Handheld 6.5.3 Device
On a Windows Embedded Handheld 6.5.3 device A warm boot starts the MC92N0 again and shuts down all running programs. − A cold boot also restarts the MC92N0ex, but erases all stored records and entries in − RAM. In addition, some new drivers are installed ATTENTION Incorrect handling may cause damage to property! Data stored in the flash memory or on a memory card is not lost.
Page 78 Faults and Mobile Computer MC92N0 Troubleshooting Type 17-A1A.-………… and Type B7-A2A.-………… 7.1.3.3 Clean Boot ATTENTION Incorrect handling may cause damage to property! Performing a clean boot restores formats, preferences and other settings to the  factory settings. Download the Clean Boot Package from the Zebra Support Central. Follow the instructions included in the package for installing the package onto the MC92N0 Technical data subject to change without notice..
Page 79: Service, Inspection, Repair
Mobile Computer MC92N0 Service, Inspection, Repair Type 17-A1A.-………… and Type B7-A2A.-………… Service, Inspection, Repair Commissioning and service of Mobile Computers may be conducted exclusively by trained and qualified staff! The staff is familiar with the installation, assembly, commissioning and operation of the Mobile Computers, has been informed about the risks and has the qualifications necessary for this work.
Page 80: Information On Sending In For Repairs
Please read through the handling guidelines for the RMA process before you send in a defective device for repair. Then complete the RMA form (Return Merchandise Authorization), sign it and send it to our “Returns Centre”. E-Mail: services@bartec.de Fax: +49 7931 597-119 We cannot guarantee the processing within the contractually agreed period for any returns received by us without RMA number.
Page 81: Disposal
Mobile Computer MC92N0 Service, Inspection, Repair Type 17-A1A.-………… and Type B7-A2A.-………… Disposal The Mobile Computers contain metallic and plastic parts and electronic components. Our devices are intended as professional electric devices for business use only, referred to as B2B devices under the WEEE-Directive. The WEEE directive sets the framework for waste electric and electronic equipment handling procedures which are to apply throughout the EU.
Page 82: Accessories, Spare Parts
Mobile Computer MC92N0 Accessories, Spare Parts Type 17-A1A.-………… and Type B7-A2A.-………… Accessories, Spare Parts Mobile Computer MC92N0 Description Order number Spare battery 7.4 V/2400 mAh, Li-Ion Battery ATEX/IECEx 17-A1Z0-0001 7.4 V/2400 mAh, Li-Ion Battery 17-A1Z0-0002 Spare keypad with blue overlay for ATEX / IECEx / UL - ATEX and Division 1 with 28 keys 05-0080-0438 with 43 keys...
Page 83 Mobile Computer MC92N0 Accessories, Spare Parts Type 17-A1A.-………… and Type B7-A2A.-………… General Description Order number SD cards with 1 GB 17-28BE-F006/0002 with 2 GB 17-28BE-F006/0003 with 4 GB 17-28BE-F006/0004 with 8 GB 17-28BE-F006/0005 with 16 GB 17-28BE-F006/0006 with 32 GB 17-28BE-F006/0007 Protective Display Foil for gas group IIA and IIB...
Page 84: Additional Information
Type 17-A1A.-………… and Type B7-A2A.-………… Additional Information 12.1 Links http://www.bartec-group.com BARTEC website http://www.bartec.de/automation-download/ BARTEC Downoad website http://www.motorolasolutions.com/US-EN/Enterprise+Mobility ZEBRA website The ZEBRA page for the MC9200 User Manuals and software of the non-explosion protected version Support − Mobile Computers, Barcode Scanners => Selelect a Produkt −...
Page 85: Declaration Of Conformity
Mobile Computer MC92N0 Appendix Type 17-A1A.-………… and Type B7-A2A.-………… Declaration of Conformity Mobile Computer MC92N0 -IS – Zone 1 Technical data subject to change without notice. Revision C / Status 09/2015...
Page 86 Mobile Computer MC92N0 Appendix Type 17-A1A.-………… and Type B7-A2A.-………… Mobile Computer MC92N0 -NI – Zone 2/22 Mobile Computer MC92N0 -NI – Zone 2/22 All certification see www.bartec-group.com  Technical data subject to change without notice. Revision C / Status 09/2015...
