GmbH
Max-Eyth-Straße 16
97980 Bad Mergentheim
Germany
User Manual
Mobile Computer MC 9090
Type 17-A129-0G.0/H.....
Mobile Computer MC 9090
Type 17-A129-0K.0/H.....
UL Version
Phone: +49 7931 597-0
Fax:
+49 7931 597-183
-G
ex
-K
ex
Status: June, 19
Technical data subject to change!
Contact:
support-polaris@bartec.de
Version 3.00
2007
th
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bartec MC 9090ex-G
Summary of Contents for Bartec MC 9090ex-G
- Page 1 Mobile Computer MC 9090 Type 17-A129-0G.0/H….. Mobile Computer MC 9090 Type 17-A129-0K.0/H….. UL Version Version 3.00 Status: June, 19 2007 Technical data subject to change! GmbH Max-Eyth-Straße 16 Phone: +49 7931 597-0 Contact: 97980 Bad Mergentheim Fax: +49 7931 597-183 support-polaris@bartec.de Germany...
- Page 3 Natural wear is also excluded from warranty. BARTEC reserves the right to alter the contents of the document without notice. No guarantee is given for the correctness of the information. In case of doubt the original German version of the safety information will apply because it is not possible to rule out errors in translation or in printing.
-
Page 5: Table Of Contents
Contents Mobile Computer MC 9090 Product description ..........................10 General ............................10 Use.............................11 Advantages ..........................11 Safety instructions............................12 Warnings about the Mobile Computers ..................12 Warnings for battery........................15 Warnings about Laser Devices ....................16 Notes on installation........................16 Electromagnetic Fields.......................18 2.5.1 International ..........................18 2.5.2 Portable Devices ........................18 2.5.3 Handheld Devices ........................18 Health and Safety Recommendations..................19... - Page 6 Inhaltsverzeichnis Commissioning ............................33 Mobile Computer........................33 Display ............................33 Battery............................34 4.3.1 Cradles............................34 4.3.2 Charging station .........................34 4.3.3 Power supply..........................35 4.3.4 Charging the Battery ........................35 Installing Battery.........................36 Handling..............................37 Mobile Computer MC 9090 -K ....................37 Mobile Computer MC 9090 -G ....................38 Battery............................39 5.3.1 Battery Informationen.........................39 5.3.2 Charging Processes........................39 5.3.3...
- Page 7 Contents Mobile Computer MC 9090 Maintenance ..............................51 Care of the Battery ........................51 Cleaning the Battery Contacts....................51 Information about Repairs......................51 Additional information..........................52 Links............................52 Accessories..........................53 Order numbers ...........................55 Transport and shipment ...........................57 Certificates ..............................58 Page 9...
-
Page 8: Product Description
User Manual Mobile Computer MC 9090 Product description General The MC 9090 -G and MC 9090 -K Mobile Computers each form a compact unit for high-standard barcode scanning in hazardous (potentially explosive) areas. The comfortably positioned scan trigger and the ergonomic design of the MC 9090 device series allow the acquisition of data with one-hand operation. -
Page 9: Use
Mobile Computer MC 9090 The Mobile Computer is a hand-guided electrical device used for the mobile acquisition, processing and radio transmission of data in hazardous areas. The Mobile Computer is used in areas of Class I Div 1. The MC 9090 series is specially intended for use in Class I Div 1, Group C, D. -
Page 10: Safety Instructions
User Manual Mobile Computer MC 9090 Safety instructions Warnings about the Mobile Computers W A R N I N G S ■ The device may not be opened by the user outside the hazardous area either! The user may not make any alterations to the device. - Page 11 Mobile Computer MC 9090 C A U T I O N ■ Do not open or charge the device and do not exchange any data through the "cradle contacts" on the battery in the hazardous area! Operating the 17-pin data interface (see Chapter 3.5 "Technical data Battery, Article "External battery contacts") is only permissible outside the hazardous area and only with devices specified by the manufacturer! ■...
- Page 12 User Manual Mobile Computer MC 9090 A T T E N T I O N Equipment that is damaged in any way or that does not function proberly must instantly be removed from the hazardous area and sent in for inspection/repair! ■...
-
Page 13: Warnings For Battery
Mobile Computer MC 9090 Warnings for battery W A R N I N G ■ The battery may only be charged outside the hazardous area! ■ It must be ensured that only original batteries of the type 17-A1Z0-0002 with 7.4 V/2200 mAh are used in safety-oriented operation. -
Page 14: Warnings About Laser Devices
User Manual Mobile Computer MC 9090 Warnings about Laser Devices Devices equipped with Symbol lasers conform to the US 21CFR1040.10 and IEC 825-1:1993, EN 60825-1:1994+A11:1996 standards. The laser classification is marked on one of the labels on the device. Class 1 laser devices are rated not hazardous when used in the manner intended. - Page 15 Repairs on explosion-protected operating equipment may only be done by authorised persons using original spare parts and working in accordance with the latest developments of technology. The relevant applicable regulations must be observed. Please direct any questions you may have to BARTEC GmbH. ■ Installation Directives The safety and accident prevention regulations applicable to the respective application must be adhered to.
-
Page 16: Electromagnetic Fields
2.5.2 Portable Devices This device was tested for typical body-worn operation. Use only BARTEC tested and approved beltclips, holsters, and similar accessories to ensure FCC Compliance. The use of third-party belt-clips, holsters, and similar accessories may not comply with FCC RF exposure compliance requirements, and should be avoided. -
Page 17: Health And Safety Recommendations
Mobile Computer MC 9090 Health and Safety Recommendations Use only the accessories, batteries and battery chargers approved by BARTEC. Do not attempt to charge damp/wet Mobile Computers or batteries. All components must be dry before being connected to an external power supply point. -
Page 18: Warnings For Use Of Wireless Devices
User Manual Mobile Computer MC 9090 Warnings for Use of Wireless Devices Please observe all warning notices with regard to the usage of wireless devices. 2.7.1 Safety in Aircraft Switch off your wireless device whenever you are instructed to do so by airport or airline staff. If your device offers a 'flight mode' or similar feature, consult airline staff as to its use in flight. -
Page 19: Radio Frequency Interference Requirements-Fcc
Mobile Computer MC 9090 2.7.5 Radio Frequency Interference Requirements-FCC Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 20: Technical Data
User Manual Mobile Computer MC 9090 Technical data Explosion Protection Type 17-A129-0G.0/H..and 17-A119-0K.0/H...…. Ι Class Div 1 Groups C and D, T4 Ex ia Ex protection type Certification File No. E226123 General data Dimensions (height x width x depth) Type 17-A119-0G.0/H.. - Page 21 Mobile Computer MC 9090 Interfaces RS232, max. 115.2 kbps, min. 1200 bps USB Vers. 1.1 (client) Keypad versions "Gun" version and "Brick" version As an alternative, the 53-key version is also available with emulation key printing 28 keys 43 keys 53 keys No emulation software is installed on the Mobile Computers with the emulation key version.
-
Page 22: Technical Data Scan Engine And Decode Zone
User Manual Mobile Computer MC 9090 Technical data Scan Engine and decode zone 3.3.1 Scan Engine for type 17-A129-0GJ0/H..(Long Range Scan Engine) Laser diode visible red light 650 nm Scan rate 35 scans / sec. ± 5 (bi-directional) Scan angle 13.5°... -
Page 23: Scan Engine Für Typ 17-A129-0Ka0/H
Mobile Computer MC 9090 3.3.2 Scan Engine für Typ 17-A129-0KA0/H..(Standard Range Scan Engine) Laser diode visible red light 650 nm Scan rate 104 scans / sec. ± 12 (bi-directional) Scan angle 47° ± 3° standard 35° ± 3° reduced Laser safety Devices in CDRH Class II / IEC 825 Class 2 Decode zone for MC 9090... -
Page 24: Scan Engine For Type 17-A12.-0Kk0/H
User Manual Mobile Computer MC 9090 3.3.3 Scan Engine for type 17-A12.-0KK0/H..(Imager) Illumination element (LED) Visible red light 635 nm +/- 20 nm Target element (VLD) Visible red light 635 nm +/- 20 nm Field of vision Horizontal 32,2 ° Vertical 24,5 °... -
Page 25: Technical Data Wlan / Wpan
Mobile Computer MC 9090 Technical data WLAN / WPAN WLAN (integrated radio module) Radio standard IEEE 802.11a/b/g (direct sequence topologie) Data rate IEEE802.11a: up to 54 Mbit/Sek. IEEE802.11b: up to 11 Mbit/Sek. IEEE802.11g: up to 54 Mbit/Sek. Frequency range IEEE802.11a: 5 GHz IEEE802.11b: 2.4 GHz... -
Page 26: Technical Data Battery
User Manual Mobile Computer MC 9090 Technical data Battery Battery Type 17-A1Z0-0002 (only rechargeable in the safe range) Lithium Ion 7.4 V / 2200 mAh Operating temperature when charging 0 °C to +40 °C 32 °F to 104 °F when discharging -20 °C to +40 °C -4 °F to 104 °F Storage temperature... -
Page 27: Product Marking
Mobile Computer MC 9090 Product Marking 3.6.1 Mobile Computer MC 9090 CAUTION - CLASS 3R LASER LIGHT WHEN OPEN. AVOID DIRECT EYE EXPOSURE. Warning Laser ATTENTION - LUMIÈRE LASER DE CLASSE 3R, EN CAS D’OUVERTURE. EXPOSITION DANGEREUSE AU FAISCEAU. VORSICHT - LASERLICHT KLASSE 3R, WENN ABDECKUNG GEÖFFNET. DIREKTE BESTRAHLUNG DER AUGEN VERMEIDEN. -
Page 28: Laser Labels
User Manual Mobile Computer MC 9090 Laser Labels In accordance with Clause 5, IEC 825 and EN60825, the following information is provided to the user: DEUTSCH KLASSE 1 KLASSE 1 LASER PRODUKT KLASSE 2 LASERLICHT NICHT IN DEN LASERSTRAHL SEHEN KLASSE 2 LASER PRODUKT ENGLISH DANISH / DANSK... -
Page 29: Wlan / Bluetooth
Mobile Computer MC 9090 WLAN / Bluetooth 3.8.1 Radio Modules The device contain approved radio module(s). These module(s) are identified below. ■ Symbol Modular RLAN radio card, Type(s): 21-21160 ■ Symbol Bluetooth Terminal, Model: MC9090 3.8.2 Products equipped with Bluetooth® Wireless Technology This device contains the following Bluetooth Complimentary subsystems: ■... - Page 30 Note 2: If using WLAN (5 GHz) in the European Economic Area (EAA), there are varying restrictions that must be observed: For details see the CE Declaration from BARTEC (Chapter 10 "Certificates") or view the Motorola (Symbol) web site http://www2.symbol.com/doc/ for the CE Declaration of Conformity for the standard version.
-
Page 31: Commissioning
Mobile Computer MC 9090 Commissioning Mobile Computer To ensure that the devices function perfectly and have a long service life, they must be handled carefully. Chapter 5 "Handling" explains how to avoid inappropriate handling (e.g. by letting fall, damaging with objects). Use the devices only if they are in a perfect technical condition. -
Page 32: Battery
Note that battery type 17-A1Z0-0002 with 7.4 V/2200 mAh may only be charged outside the hazardous zone. Use only accessories approved by BARTEC. Do not attempt to charge damp/wet Mobile Computers or batteries. All components must be dry before they are connected to an external power supply point. -
Page 33: Power Supply
4.3.3 Power supply Use only the power packs approved by BARTEC/Motorola (50-14000-148, 12 Vdc and at least 3,33 A). The power pack is certified in accordance with EN60950-1 and has SELV outputs. The use of other power packs invalidates the permits granted for these devices and can be dangerous. -
Page 34: Installing Battery
User Manual Mobile Computer MC 9090 Installing Battery Do not remove the battery during the first 15 hours of operation. There is a risk of losing data if the battery is removed. Sliding the battery into the mobile computer as shown in Figure Ensure the battery is fully inserted. -
Page 35: Handling
Mobile Computer MC 9090 Handling Make sure that the Mobile Computer is set down on a stable supporting surface. Avoid putting it down on places such as e.g. tables, trolleys, stands or holders if they are not stable. Mobile Computer MC 9090 In this position the device cannot be protected against damage. -
Page 36: Ex -G
User Manual Mobile Computer MC 9090 Mobile Computer MC 9090 In this position the device cannot be protected against damage. The scanner window can be damaged by objects lying on the supporting surface. In this this position the device cannot be protected against damage. -
Page 37: Battery
Replace the battery when a significant loss of run time is detected. Batteries must be charged within the 0° to +40 °C (32° to 104° F) temperature range. Standard warranty period for all BARTEC batteries is 1 year, regardless of whether the battery was purchased separately or included as part of the mobile computer. - Page 38 User Manual Mobile Computer MC 9090 Charging the Battery in the Mobile Computer Care must be taken that the devices to be charged are inserted into the charging station in the direction of the arrow. The Mobile Computer starts the charging process automatically. The yellow charging LED in the LED display bar lights up to indicate the charging status.
-
Page 39: Tips On Optimising The Operating Time
Mobile Computer MC 9090 5.3.3 Tips on Optimising the Operating Time ■ Leave the mobile computer connected to AC power at all times when not in use. ■ Set the mobile computer to turn off after a short period of non-use. ■... -
Page 40: Changing The Display Backlight Settings
User Manual Mobile Computer MC 9090 5.4.2 Changing the Display Backlight Settings To change the display backlight settings in order to conserve more battery power: Tap Start > Settings > System tab > Backlight icon > Battery Power tab Select the On battery power: Disable backlight if not used for: check box and select a value from the drop-down list box. -
Page 41: Waking The Mobile Computer
Mobile Computer MC 9090 Waking the Mobile Computer 5.4.5 The wakeup conditions define what actions wakeup the mobile computer. These settings are configurable and the factory default settings shown in the following Table are subject to change/update. Table Wakeup Conditions (Default Settings) Status Description Conditions for Wakeup... -
Page 42: Mobile Computer Booten
User Manual Mobile Computer MC 9090 Mobile Computer booten 5.5.1 Windows Mobile 5.0 Devices If the functions stop working when you are using the Mobile Computer, it is recommendable to REBOOT the device. There are two reset functions, warm boot and cold boot. A warm boot restarts the mobile computer and closes all running programs. - Page 43 Mobile Computer MC 9090 To perform a cold boot on a MC9090-G: Press the primary battery release on the mobile computer to partially eject the battery from the mobile computer. On an MC9090-G, while the battery is partially released, simultaneously press and release the trigger and the Power button.
-
Page 44: Additional Components
User Manual Mobile Computer MC 9090 Additional components Keypad and CD Card 6.1.1 Keypad with blue overlay Options Order number 28 keys 05-0080-0388 43 keys 05-0080-0389 53 keys 05-0080-0390 53 keys keypad coding for VT Emulation 05-0080-0391 53 keys keypad coding for 3270 Emulation 05-0080-0392 53 keys keypad coding for... -
Page 45: Removing/Changing The Keypad
Mobile Computer MC 9090 6.1.3 Removing/Changing the Keypad The keypad and SD card may only be replaced outside the hazardous area! Turn off the MC 9090 Remove the battery (see Chapter 5.3.2 "Charging Processes"). Take out the screws at the top edge of the keypad. Fig. - Page 46 User Manual Mobile Computer MC 9090 Snap on the keypad in the direction of the arrow (see fig. 4) and push it upwards until the boreholes for the screws are over the threaded sleeves. Fig. 4: Changing the keypad Check that the keypad is mounted correctly. Figure 5: Keypad mounted incorrectly Figure 6: Keypad mounted correctly Push the keypad in the direction of the arrow (see fig.
-
Page 47: Inserting/Replacing The Sd Card
Mobile Computer MC 9090 6.1.4 Inserting/replacing the SD card The hardware status of the SD cards is specified in the test certificate. Accordingly only the SD cards with the order number 17-28BE-F006/000x are to be used. Take off the keypad as instructed in Chapter 6.1.3; Repeat Steps 1 - 4. SD card slot Figure 7: MC 9090 without keypad... -
Page 48: Stylus
User Manual Mobile Computer MC 9090 Stylus 6.2.1 Stylus for MC 9090 Order number for stylus ( yellow): 3-pack 3-pack 10-pack 10-pack Stylus with holder 3-pack 3-pack 50-pack 50-pack 6.2.2 Stylus for MC 9090 Order number for stylus (grey): 10-pack 10-pack 50-pack 50-pack... -
Page 49: Maintenance
If you wish to send in a defective device for repairs please first read the RMA procedure guide. Then fill in and sign the RMA (Return Merchandise Authorisation) form and send it to our Service Centre. Email: services@bartec.de Fax: +49 7931 597-119 We cannot guarantee any contractually agreed processing times for devices that are sent in without an RMA number. -
Page 50: Additional Information
User Manual Mobile Computer MC 9090 Additional information Links http://www.bartec-group.com BARTEC Homepage http://www.symbol.com Motorola Homepage http://www.symbol.com/ The Motorola site for the MC 9000 Support and Resources Product Manuals Mobile Computers MC 9090 WM http://www.symbol.com/ The Motorola site for the MC 9000... -
Page 51: Accessories
Mobile Computer MC 9090 Accessories Order number Order number Designation Motorola BARTEC Accessories for the hazardous zone Ex Accessory: Battery Spare battery for devices with UL approval 17-A1Z0-0002 Ex Accessory: SD Card for ATEX and UL version ATP Industrial Grade SD Card with 512 MB... - Page 52 User Manual Mobile Computer MC 9090 Order number Order number Designation Motorola BARTEC non-hazardous area Accessories for the Single Slot Cradle Set: 05-0079-0018 Consists of: Single Slot Cradle CRD9000-1001SR 03-9915-0003 Power pack 50-14000-148R 03-9911-0015 RS232 cable (Cradle <-> PC) 25-63852-01R 03-9919-0004 USB cable (Cradle <->...
-
Page 53: Order Numbers
Mobile Computer MC 9090 Order numbers 17-A129-0G 0/HJ FA6 0 Lorax 1D Long Range Scan Engine (SE 1524) 28 Key Tastatur (mobile phone keypad) 43 Key Tastatur (with function keys F1 – F12 in direct access) 53 Key Tastatur (alphanumeric keypad) 53 Key Tastatur with printing for VT Emulation (the software is not installed on the device) 53 Key Tastatur with printing for 3270 Emulation... - Page 54 User Manual Mobile Computer MC 9090 17-A129-0K 0/HJ FA6 0 1D Standard Range Scan Engine (SE950) 2D Imager (SE1440) 28 Key Tastatur (mobile phone keypad) 43 Key Tastatur keypad (with function keys F1 – F12 in direct access) 53 Key Tastatur (alphanumeric keypad) 53 Key Tastatur with printing for ür VT Emulation (the software is not installed on the device) 53 Key Tastatur with printing for 3270 Emulation...
-
Page 55: Transport And Shipment
Mobile Computer MC 9090 Transport and shipment Important note concerning transport and shipping ! Sensitive Devices ! It is absolutely necessary to deliver the equipment in the original packaging in order to avoid damage to the equipment. Page 57... -
