Bartec MC 9060ex-K Quick Start Manual

ex
MC 9060 -K
Quick Start Guide
See Product Reference Guide for more information

Battery Removal

It is allowed to replace the battery
in hazardous areas.
To charge the battery in hazardous
areas is strictly prohibited.

Accessories for safe area

Charging Instructions

Slow Flash = Normal Charge Solid Amber = Full Charge
Four Slot Spare Battery Charger
All manuals and user guides at all-guides.com
2
1
3
Fast Flash = Charging Error
safe area
Single Slot Serial/USB Cradle
CLASS

Battery Insertion

Microphone optional
Touch Screen
Indicator LED Bar
Power
Scan Button
Keypad
Back View
Color Camera optional
Stylus
Stored in strap
Strap
1
= LED Indicator Location
safe area
Four Slot Cradles
I
DIV 1 - UL version
Scan Button
safe area
Charge-Only Cradle and Ethernet Cradle
