TABLE 3. DETECTOR STATUS INDICATION
DETECTOR SENSOR LED
STATE
Power Up Red Blink every 5
seconds
Standby Green Blink every 5
seconds
Maintenance Red Blink every 5
seconds
Speed-Up Alternating Red/
Green Blink every
0.5 seconds
Trouble Red Blink every 5
seconds
Cover Tamper Red Blink every 5
Violation seconds
Communication Off
Error
Alarm Red Solid
Unit Loses Off
Power
NOTE: Power Board LED is not visible unless the power board cover is removed. If any other visual indication is noted contact System Sensor technical support
at 1-800-SENSOR2.
POWER BOARD LED COMMENTS
Alternating Green/ Initialization completes in
Amber Blink every 1
approximately 30 sec
second
Green Blink every 5
seconds
Amber Blink every 5 The 2D51 sensor is outside it's
seconds UL approved sensitvity limits and
needs to be cleaned or replaced.
Green Blink every Alternating red /green blink
0.5 seconds pattern exists until unit either
enters Alarm or reverts to
Standby (within approximately
60 seconds).
Amber Solid
Amber Solid When in "Standby" mode,
the product goes into "Cover
Tamper Violation" if the cover
has been removed or improperly
replaced and remains so for at
least 7 minutes. As soon as the
cover is properly reseated, the
product reverts to "Standby"
automatically.
Amber Solid Sensor LED state cannot be
guaranteed since there is a
communication error.
Red Solid
Off
RELAY STATES
Supervisory relay: Terminals 3 and 14 are closed.
Alarm Relay: Terminals 4 and 5 are open
Aux Relay does not switch states: Terminals 6 and 16
are closed; Terminals 8 and 18 are closed
Supervisory relay: Terminals 3 and 14 are closed.
Alarm Relay: Terminals 4 and 5 are open
Aux Relay does not switch states: Terminals 6 and 16
are closed; Terminals 8 and 18 are closed
Supervisory relay: Terminals 3 and 14 are closed.
Alarm Relay: Terminals 4 and 5 are open
Aux Relay does not switch states: Terminals 6 and 16
are closed; Terminals 8 and 18 are closed
Supervisory relay: Terminals 3 and 14 are closed.
Alarm Relay: Terminals 4 and 5 are open
Aux Relay does not switch states: Terminals 6 and 16
are closed; Terminals 8 and 18 are closed
Supervisory relay: Terminals 3 and 14 are open.
Alarm Relay: Terminals 4 and 5 are open
Aux Relay does not switch states
Supervisory relay: Terminals 3 and 14 are open.
Alarm Relay: Terminals 4 and 5 are open.
Aux Relay does not switch states
Supervisory relay: Terminals 3 and 14 are open.
Alarm Relay: Terminals 4 and 5 are open
Aux Relay does not switch states
Supervisory relay: Terminals 3 and 14 are closed
Alarm Relay: Terminals 4 and 5 are closed
Aux Relay switches states: Terminals 6 and 16 are
open; Terminals 8 and 18 are open
Supervisory relay: Terminals 3 and 14 are open.
Alarm Relay: Terminals 4 and 5 are open
Aux Relay does not switch states
7 I56-4260-002R
06-10
