USER MANUAL
Locking nut
Load the rotor to the shaft
● Load the rotor to the shaft to ensure rotor is in position until it connected well with the shaft.
● Rotate the rotor slightly with your fingers to check. if the rotor vibrates, if so attach the rotor again.
● Hold on the rotor with one hand, tighten clockwise the nut with the other hand and make sure tighten firmly.
● Put the rotor lid to the rotor, press the fastener down and make the fastener attach the locking nut tightly.
● Close the door and start running.
● To release the rotor, firstly pull the fastener up to remove the lid, and then turn the locking nut anti-clockwise.
CAUTION
● Check the rotor is firmly tightened before running.
8.1.2 Set the operation programs
Press the button to select required program. The value can be modified when the program is flashing. Rotate the
Select
program button clockwise
Program button rotate faster, and the value increase faster. The minimum speed increment is 100 rpm, the
minimum time increment is 1 second.
(1) Set the speed
● Press the select button
● When the speed button is selected, the speed symbol will flash the speed value.
● The minimum speed value you can set 500 rpm, the minimum increment is 100 rpm.
● Rotate program button clockwise
decrease speed value.
● You can speed-up set the speed value by rotating program button
● There is a circulating function to increase/decrease the speed values. Rotate the program button clockwise
change settings from small → large → maximum → minimum. Rotate the program button anti-clockwise
change settings from large → small → minimum → maximum.
Page 12
Symmetrically load centrifuge tubes to rotor
Figure 8-2 The rotor installation
to increase value; anti-clockwise rotate the program button
until the speed rpm is displayed.
Select
to increase speed value; rotate the program button anti-clockwise
Rotor lid
Load the rotor lid
to decrease value.
quickly.
www.scilogex.com
Fastener
to
to
to
