Bertazzoni C36500X (Z36500X), C36600X (Z36600X) User Instructions
Bertazzoni C36500X (Z36500X), C36600X (Z36600X) User Instructions

Bertazzoni C36500X (Z36500X), C36600X (Z36600X) User Instructions

Built-in gas cooktops
Hide thumbs Also See for C36500X (Z36500X), C36600X (Z36600X):

Advertisement

Models C36500X (Z36500X)
Models C36600X (Z36600X)
IMPORTANT - PLEASE READ AND FOLLOW
-Before beginning installation, please read these instructions completely and carefully.
-Do not remove permanently affixed labels, warnings, or plates from the product. This may void the warranty. -Please observe all local
and national codes and ordinances.
-Please ensure that this product is properly grounded.
-The installer should leave these instructions with the consumer who should retain for local inspector's use and for
future reference.
-The electrical plug should always be accessible.
Installation must conform with local codes or in the absence of codes, the National Fuel Gas Code ANSIZ223.1-latest edition. Electrical
installation must be in accordance with the National Electrical Code, ANIS/NFPA70
Installation must be in accordance with the current CAN/CGA-B149.1 National Gas Installation Code or CAN/CGA-B
Installation Code and/or local codes. Electrical installation must be in accordance with the current CSA C22.1 Canadian Electrical
Codes Part 1 and/or local codes.
Installation of any gas-fired equipment should be made by a licensed plumber. A manual gas shut-off valve must be installed in the gas
supply line ahead of the oven in the gas flow for safety and ease of service.
In Massachusetts:
All gas products must be installed by a "Massachusetts" licensed plumber or gasfitter. A "T" handle type manual
gas valve must be installed in the gas supply line to this appliance.
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
OBSERVE ALL GOVERNING CODES AND ORDINANCES.
WARNING: If the information in this manual is not followed exactly, a
fire or explosion may result causing property damage, personal injury
or death.
Do not store or use gasoline or other flammable vapors and liquids in
the vicinity of this or any other appliance.

WHAT TO DO IF YOU SMELL GAS

- Do not light any appliance.
- Do not touch any electrical switch.
- Do not use any phone in your building.
- Immediately call your gas supplier from a neighbor's phone. Follow
the gas supplier's instructions.
- If you cannot reach your gas suppliers, call the fire department.
Installation and service must be performed by a qualified installer,
service agency or the gas supplier.
310200
User Instructions
Built-in gas cooktops
BERTAZZONI
DIMENSIONS: 36'' (915 mm)(W) x 253/16'' (640 mm)(D)
[C3W0..U4X(2 or 5)A]
[C3Y0..U4X(2 or 5)A]
-
latest edition and/or local codes. IN CANADA:
149.2,
Propane

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C36500X (Z36500X), C36600X (Z36600X) and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bertazzoni C36500X (Z36500X), C36600X (Z36600X)

  • Page 1: What To Do If You Smell Gas

    - If you cannot reach your gas suppliers, call the fire department. Installation and service must be performed by a qualified installer, service agency or the gas supplier. 310200 User Instructions Built-in gas cooktops BERTAZZONI [C3W0..U4X(2 or 5)A] [C3Y0..U4X(2 or 5)A] latest edition and/or local codes. IN CANADA: 149.2, Propane...
  • Page 2: User Manual

    SERVICE & MAINTENANCE INSTRUCTIONS Service and maintenance only to be carried out by an authorised person To replace parts such as burners, valves and electric components, the appliance must be open removing the worktop. Note: if the valves must be replaced, first disassemble the ignitions switches wires. It is recommended to replace the valve gaskets each time the valve is replaced, thus ensuring a perfect seal between the body and the gas train.
  • Page 3: Using Burners

    USING BURNERS A diagram is etched on the control panel above each knob which indicates which burner corresponds to that knob. Manual ignition: Manual ignition is always possible even when the power is cut off or in the event of prolonged power failure. Turn the knob that corresponds to the burner selected counterclockwise to the MAXIMUM position at the etched star (large flame) and place a lit match up to the burner.
  • Page 4: Cleaning The Appliance

    Please note here below details for after save service. Refer to warranty certificate for warranty condiftions Dealer /Importer: Name, address, phone SERVICE CENTERS Name Phone MANUFACTURER: BERTAZZONI SPA VIA PALAZZINA, 8 – 42016 – GUASTALLA (REGGIO E.) ITALY Tel. 0522/226411 – telefax 0522/226440 – http://www.bertazzoni-italia.com...

This manual is also suitable for:

C36500x, c36600xZ36500xZ36600x
