4½ Digit loop-powereD meters
model pD675 NemA 4X
pD677
•
4½ Digit 0.7" (17.8 mm) LCD, 19999
•
PD677-N-EX is FM Approved & CSA Certified
•
Ex-proof, cast aluminum with glass window
•
Operates from -20 to 65°C
•
Easy to Calibrate
Precision Digital corPoration
model pD677 explosion-proof
®
pD675
•
4½ Digit 0.7" (17.8 mm) LCD, 19999
•
FM Approved & CSA Certified
•
Impact-resistant polycarbonate body
•
Operates from -20 to 65°C
•
Easy to Calibrate
®
www.predig.com
Advertisement
Related Manuals for PRECISION DIGITAL PD677
Summary of Contents for PRECISION DIGITAL PD677
- Page 1 Easy to Calibrate ® model pD677 explosion-proof pD677 • 4½ Digit 0.7" (17.8 mm) LCD, 19999 • PD677-N-EX is FM Approved & CSA Certified • Ex-proof, cast aluminum with glass window • Operates from -20 to 65°C • Easy to Calibrate ®...
- Page 2 Unscrew the two fasteners that hold the faceplate, then remove. for the desired reading. Complete the calibration by making any minor PD677: Turn the enclosure cover counterclockwise to remove. Unscrew adjustments to the LO and HI displays. the two fasteners that hold the faceplate, then remove.
- Page 3 MOUNTING PLATE METER A: 3.15 (80) E: 2.56 (65) PDA6844 Panel Mounting Kit B: 5.51 (140) F: 0.79 (20) C: 2.36 (60) pD675 & pD677 pipe mount D: 4.72 (120) pD677 0.31 (7.9) Dia. PDA6845 Pipe Mounting Kit A: 5.44 (138) C: 5.63 (143)
- Page 4 PDN-ONEDAYRTN One-Day Turnaround Service pD677 Display: 0.7" (17.8 mm) LCD, 4½ digits; 19999 Certificate of Conformance Approvals: The PD677-N-EX is FM Approved & CSA Certified PDN-CERTCON Certificate of Conformance as explosion-proof for Class I, Division 1, Groups B, C, & D; dust- ignition proof for Class II, Division 1, Groups E, F, &...
