  • Page 1 Atlas 200/201 Group Training System OWNER’S MANUAL Model # XFT-200 or XFT-201 Revision 040519...
  • Page 2 Технические характеристики, особенности и программного обеспечения могут быть изменены без предварительного уведомления. Для получения самой последней на сегодняшний день руководство по эксплуатации пожалуйста, посетите www.truefitness.com .Для документов на другие языки, пожалуйста, посетите www.truefitness.com/resources/document-library/ Page # 2 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 3 Atlas 200/201 A MESSAGE TO OUR CUSTOMERS Frank Trulaske began TRUE Fitness® over thirty-five year ago with the simple philosophy of delivering superior fitness products, service, and support. Today, TRUE is the global leader in premium fitness equipment for the commercial and residential markets.

  • Page 4: Table Of Contents

    CHAPTER 4: CUSTOMER SERVICE ..........................49 • CONTACTING SERVICE: ......................49 • CONTACTING SALES: .......................49 • REPORTING FREIGHT OR PARTS DAMAGE: ..............50 CHAPTER 5: WARRANTY INFORMATION: ......................51 Page # 4 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...

  • Page 5: Chapter 1: Safety Instructions

    Be certain members are instructed on how to operate and adjust all safety mechanisms. Page # 5 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 6 7. Some assembly materials may come preassembled in the carton. Refer to Chapter 2: Assembly Guide for instructions on disassembling assembly materials where appropriate before beginning assembly. Page # 6 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 7 4. Replace any warning label at the first sign of wear. Labels and the facility safety sign may be obtained from TRUE. ENGTH EASURING UIDE FLAT HEAD SCREW BUTTON HEAD SCREW HEX HEAD SCREW SOCKET HEAD SCREW Page # 7 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 8 Be sure all hardware is tight before using the machine. Retain these instructions for future reference. If you have any questions, do not hesitate to contact your TRUE dealer or TRUE Fitness Technology at (800)883-8783 or service@truefitness.com. Page # 8 of 53...

  • Page 9: Anchoring

    7. DO NOT allow the machine to be used if it is not sitting solidly on the floor at all leveling feet locations. Page # 9 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...

  • Page 10: Commerical Maintenance Schedule

    CLEAN: Guide rods and lubricate with a teflon lubricant if equipped. CLEAN: Upholstery LUBRICATE: Pivot bearings and linear bearings. REPLACE: Cables if equipped. Page # 10 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...

  • Page 11: Chapter 2: Assembly Guide

    900, or Half Rack) attached to the center column assembly or optional attachments listed in this manual. 63“ 95“ 108“ COMPLIANCES: This equipment complies with all fitness product standards. For a complete list of compliances, please visit www. TrueFitness.com. Page # 11 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...

  • Page 12: Required Tools

    5/16” • 1/4” 9/16” wrench and 1/2 wrench” OR Open Ended wrench Allen wrench (supplied): • 5/16” • 1/4” Rubber Mallet Step Ladder LABELS: Page # 12 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...

  • Page 13: Pre-Assembly Checklist

    XFT000-ATT900X XFT-900/FT-900 Brackets will be used based on Attachment Bracket whether you order the XFT-100, FS- XFT-MDR Medicine Ball Ring 100, XFT-900, or FT-900. Page # 13 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 14 XFT000-CBR000X Strap Rack may not match the hardware XFT000-KBR010X XFT-200/201 Tray item numbers shown in the owner’s manual. XFT000-CLM130X Tall End Column Page # 14 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 15 XFT000-KBR010X XFT-200/201 Tray may not match the hardware XFT000-CLM120X Short End Column item numbers shown in the owner’s manual. Page # 15 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 16 XFT-DIP Dip Station may not match the hardware XFT-RRC Battle Rope Hanger item numbers shown in the Assembly owner’s manual. XFT-SPL Step Platform Page # 16 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...

  • Page 17: Xft-200/201 Assembly Overview

    Olympic Bar Storage and Core Rope Flex, Heavy Bag, and Instruction Battle Rope Hanger Trainer Suspension Bracket Page # 32, 35 33-34 36-38 (Only select 1 of 3) Page # 17 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...

  • Page 18: Assembly Steps

    XFT000-CBR120 Lower XFT-100/FS-100 securing the FS-100 to the XFT-200/201. Cross Brace XFT000-CBR115 Upper XFT-100/FS-100 Cross Brace XFT000-CBR125 Right, Lower XFT-100/FS- 100 Attachment Bracket Page # 18 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 19 C-754C Washer, Flat, 3/8” identified hardware. XFT000-ATT100X Lower XFT-100/FS-100 Attachment Bracket Note: Do not remove the XFT-100/FS-100 Upper Cross Brace Assembly until Step 2B. Page # 19 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 20 Attachment Bracket to the XFT-100/FS-100 C-749 Washer, Lock, 3/8” Assembly in the same location using the C-754C Washer, Flat, 3/8” identified hardware. XFT000-ATT100X Upper XFT-100/FS-100 Attachment Bracket Page # 20 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 21 Center Column Assembly Secure all hardware from Steps 1-2C. XFT-100A XFT-100 Assembly Confirm the XFT-100/FS-100 Assembly is level using the leveling feet located throughout the machine. Page # 21 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 22 XFT-200/201. Note: Refer to the XFT-900 owner’s manual for assembly of the XFT-900 and FT-900 owner’s manual for assembly of the FT-900. Page # 22 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 23 Attachment Bracket XFT900 XFT-900 Assembly Secure all hardware from Steps 1-2. Confirm the XFT-900/FT-900 Assembly is level using the leveling feet located throughout the machine. Page # 23 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 24 HRK sub-assembly using the identified hardware. C1136 SHCS Screw, 3/8”-16, 3-3/4” C-754C Washer, Flat, 3/8” XFT200- Center Column Assembly CLM110X C-766A Lock Nut, 3/8”-16 C-634 SHCS Screw, 3/8”-16, 4” Page # 24 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 25 C-749 Washer, Lock, 3/8” C-754C Washer, Flat, 3/8” C766A Lock Nut, 3/8”-16 XFT-HRK- Right XFT-HRK CTN2B0600 Connecting Brace XFT-HRK- Left XFT-HRK CTN1B0600 Connecting Brace Page # 25 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 26 Assemble the chin-up bar to the XFT-HRK using Item Part Number Description Quantity the identified hardware. C-634 SHCS, 3/8”-16, 4” C-754C Washer, Flat, 3/8” C-766A Lock Nut, 3/8”-16 Page # 26 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 27 Description Quantity the identified hardware. C1023 SHCS, 3/8”-16, 1” C-754C Washer, Flat, 3/8” C-766A Lock Nut, 3/8”-16 Fully tighten all hardware from Steps 1A-1D. Page # 27 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 28 SHCS, 5/8”-18, 1-1/4” hardware. PSXFW83-BPG Band Peg Kit Note: The band peg kit option is used only when the Half Rack option is used. Page # 28 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 29 Note: For XFT-200 configurations, proceed to Step 4 (XFT-200 Tall Column Configuration). For XFT-201 configurations, proceed to Step 6 (XFT- 201 Short Column Configuration). Page # 29 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 30 Confirm the Tall End Column configuration is XFT000-CLM130X Tall End Column level using the leveling feet. XFT000-KBR010X XFT-200/201 Tray Note: XFT-100/FS-100/XFT-900/FT-900/Half Rack removed for clarity in Steps 4 and 5. Page # 30 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 31 (maximum of five allowed) to the C1023 SHCS, 3/8”-16, 1” tall end column using the identified C-754C Washer, Flat, 3/8” C-766A Lock Nut, 3/8”-16 hardware. XFT-MDR Medicine Ball Ring Page # 31 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 32 XFT000-KBR010X XFT-200/201 Tray Confirm the Short End Column configuration is level using the leveling feet. Note: XFT-100/FS-100/XFT-900/FT-900/Half Rack removed for clarity in Steps 6 and 7. Page # 32 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 33 (maximum of five allowed) to the C1023 SHCS, 3/8”-16, 1” short end column using the identified C-754C Washer, Flat, 3/8” C-766A Lock Nut, 3/8”-16 hardware. XFT-MDR Medicine Ball Ring Page # 33 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 34 C-754C Washer, Flat, 3/8” C-766A Lock Nut, 3/8”-16 bosu ball and roller rack assembly using XFT000-RLR500X Bosu Ball/Roller Rack the identified hardware. Page # 34 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 35 Quantity the end column using the identified C-623 SHCS, 5/8”-18, 1-1/4” hardware. C-754C Washer, Flat, 3/8” C-766A Lock Nut, 3/8”-16 XFT-OBS Olympic Bar Storage Page # 35 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 36 Secure the core trainer to the end Item Part Number Description Quantity column using the identified hardware. C1012 SHCS, 3/8”-16, 2-1/4” C-754C Washer, Flat, 3/8” XFT-CRTA Core Trainer Assembly Page # 36 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 37 Note: The Battle Rope Hanger can be XFT000-RCK040X Battle Rope Hanger secured in other column mounting Assembly locations dependent on your overall XFT- 200/201 configuration. Page # 37 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 38 SHCS, 5/8”-16, 1-1/4” hardware. C-754C Washer, Flat, 3/8” C-766A Lock Nut, 3/8”-16 XFT-WPS Weight Plate Storage Note: The short end column can also be used. Page # 38 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 39 C1068 SHCS, 1/2”-13, 1-1/4” C1066 Washer, Flat, 1/2” XFT000-RPL520X Rope Flex XFT200-RPL501X Rope Flex Bracket W0220 Lock Nut, 1/2”-13 Page # 39 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 40 Note: Disregard Step 13 (Heavy Bag) C1136 SHCS, 3/8”-16, 3-3/4” and Step 14 (Suspension Bracket) due to sharing the same mounting location as the Rope Flex. Page # 40 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 41 Heavy Bag. Note: If a TRUE Fitness-branded heavy bag is not used, refer to that manufacturer’s owner’s manual for specific heavy bag assembly instructions. Page # 41 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 42 Suspension Bracket Note: Disregard Step 12 (Rope Flex) and Step 13 (Heavy Bag) due to sharing the same mounting location as the Suspension Bracket. Page # 42 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 43 CHAPTER 2: ASSEMBLY GUIDE OPTIONAL ASSEMBLY STEPS: Step 16 (Dip Station): Assemble the dip station to the Item Part Number Description Quantity rack station. XFT-DIP Dip Station Page # 43 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 44 CHAPTER 2: ASSEMBLY GUIDE OPTIONAL ASSEMBLY STEPS: Step 17 (Step Platform): Assemble the step platform to the rack Item Part Number Description Quantity station. XFT-SPL Step Platform Page # 44 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...

  • Page 45: Chapter 3: Care & Maintenance

    The following items are critical to the safety of users and maintenance staff as well as ensuring the optimum performance of the machines. These inspections should be performed each day before the equipment is subject to use. TRUE Fitness is not responsible for performing or scheduling regular maintenance or inspections.

  • Page 46: Other Scheduled Preventive Maintenance

    CAUTION: Do not use any acidic cleaners. Doing so will weaken the paint or powder coatings and may void the TRUE Fitness Warranty. Never pour or spray liquids on any part of the equipment. Allow the equipment to dry completely before using.

  • Page 47: Cable Inspection & Maintenance

    If any of these conditions are apparent, the machine should immediately be taken out of service and repaired. Be sure to use only cables supplied by TRUE Fitness. DO NOT use cables that have fittings attached with hand- crimp tools.
  • Page 48 Ensure that the snap-link opens and closes easily and is fully engaged when closed. Replace the snap-link as needed. Page # 48 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com Truefitness.com / 800.426.6570 / 636.272.7100...

  • Page 49: Chapter 4: Customer Service

    CHAPTER 4: CUSTOMER SERVICE CONTACTING SERVICE: TRUE Fitness recommends that you gather the serial number, model number, and a brief description of the reason for the request. After information has been gathered you may choose to contact your selling dealer or local service company to set an appointment.

  • Page 50: Reporting Freight Or Parts Damage

    Obvious damage to external packaging / internal product. Please refuse the shipment and it will be returned to TRUE Fitness by the carrier. Contact the TRUE Fitness customer support team by calling 800.883.8783 or sales support team by calling 800.426.6570 Monday-Friday during normal hours of operation to notify us that the shipment has been refused.

  • Page 51: Chapter 5: Warranty Information

    Page # 51 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 52 LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. 10. THE REMEDIES DESCRIBED ABOVE ARE YOUR SOLE Keep this page for your records AND EXCLUSIVE REMEDIES AND TRUE’S ENTIRE LIABILITY Page # 52 of 53 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 53 If you prefer to mail your warranty card, have the owner of the product complete the information below and return it to TRUE Fitness within 30 days from the date of equipment installation.
