  • Page 1 *Assembly Guide & Warranty Card Included LAT/ROW OWNER’S MANUAL Model # SD1002 Revision 033117...
  • Page 2 FORCE STRENGTH OWNERS MANUAL IMPORTANT: All Products shown are prototype. Actual product delivered may vary. Product specifications, features & software are subject to change without notice. For the most up to date owner’s manual please visit www.truefitness.com. For documents in additional languages please visit www.truefitness.com/resources/document-library/ IMPORTANTE: Todos los productos mostrados son prototipos.
  • Page 3 FORCE STRENGTH OWNERS MANUAL Frank Trulaske began TRUE Fitness® over thirty-five year ago with the simple philosophy of delivering superior fitness products, service, and support. Today, TRUE is the global leader in premium fitness equipment for the commercial and residential markets. Our goal is to be the leader in technology, innovation, performance, safety and style. TRUE has received many awards for its product over the years and remains the benchmark for the industry.

  • Page 4: Table Of Contents

    FORCE STRENGTH OWNERS MANUAL TABLE OF CONTENTS: Chapter 1: Safety Instructions Chapter 5: Customer Service Safety Instructions Contacting Service Space Requirements Contacting Sales Working Dimensions Reporting Freight Claims or Parts Damage Warning Decals Chapter 6: Additional Information Proper Training Position Specification Sheet Chapter 2: Assembly Instructions Warranty Registration...

  • Page 5: Chapter 1: Safety Instructions

    *for additional information visit http://oehha.ca.gov/prop65 WARNING: Keep equipment stable on flat ground. True Fitness recommends for all strength equipment to be bolted down to the floor to avoid toppling during improper use. WARNING: Replace warning labels that may be worn, damaged or missing.
  • Page 6 CHAPTER 1: SAFETY INSTRUCTIONS CAUTION: • Health related injuries may result from incorrect or excessive use of exercise equipment. • Take care when getting on or off strength equipment. • If you do not understand how to use/operate a piece of equipment seek assistance from facility staff or trainer to demonstrate safe and proper use.

  • Page 7: Space Requirements

    CHAPTER 1: SAFETY INSTRUCTIONS SPACE REQUIREMENTS: TRUE’s recommendation is to leave a 40” (1.0m) safety zone on all sides of the unit. Additionally for Functional Trainers there should be enough room left for full extension of all cable in all directions. (See Fig 1) WORKING DIMENSIONS: Height 87”...

  • Page 8: Warning Decals

    WARNING DECALS: WARNING: Replace warning labels that may be worn, damaged or missing. *To replace any worn or missing warning decals contact TRUE FITNESS by one of the following: www.truefitness.com or contact customer service at 800-883-8783. Truefitness.com / 800.426.6570 / 636.272.7100...

  • Page 9: Proper Training Position

    CHAPTER 1: SAFETY INSTRUCTIONS PROPER TRAINING POSITION: Target Muscles: Upper Back: A. Select appropriate weight B. Adjust leg pads to rest on thighs. C. Grasp lat bar and place feet on floor. D. Lean back slightly and pull bar to upper chest. E.
  • Page 10 Please use the various lists in this manual to make sure that all parts have been included in your shipment. • When ordering, use part number and description from the lists. Use only True Fitness replacement part when servicing. Failure to do so will void your warranty and could result in personal injury or damage your machine.

  • Page 11: Pre-Assembly Checklist

    CHAPTER 2: ASSEMBLY GUIDE PRE-ASSEMBLY CHECKLIST: Box One Contents: Item No. Description QTY. Upright Assembly Shield Support Frame Lower Support Plate Seat Pad Leg Pads Front Shroud Retainer Plates Right Shroud Retainer Plate Left Shroud Retainer Plate Stability Foot Guide rods Top Plate &...
  • Page 12 CHAPTER 2: ASSEMBLY GUIDE PRE-ASSEMBLY CHECKLIST: Box Two Contents: Item No. Description QTY. Front Frame Seat Frame Support Frame Top Frame Leg Pad Support Tube Foot Tube Floating Pulley Row Handle Cable 1 Cable 2 Adjustable Foot Plates Cover Plate Lat Bar *Hardware Pack (not pictured) is included in box two as well.
  • Page 13 CHAPTER 2: ASSEMBLY GUIDE PRE-ASSEMBLY CHECKLIST: Box Three Contents: Item No. Description QTY. Accessory Tray Placard Frame Rear Shroud Cap Rear Shroud Front Shroud Weight Plate Cartons: Weight Plates are packaged (4) per box. The shipment should contain (4) Boxes of weight plates for a total of 16 weight plates.

  • Page 14: Assembly Steps

    CHAPTER 2: ASSEMBLY GUIDE UNIT ASSEMBLY STEPS: STEP 1 Frame Assembly: ITEM Description 1. Attach two Adjustable Foot Plates to the Socket head Cap Screw M10x100 bottom of the Upright Assembly. Flat Washer 11x20x2 Nylon Lock Nut M10 2. Attach two Adjustable Foot Plates to the bottom of the Upright Assembly.
  • Page 15 CHAPTER 2: ASSEMBLY GUIDE UNIT ASSEMBLY STEPS (continued): STEP 2 Foot Tube: ITEM Description 1. Install the Foot Tube as shown below. Socket Head Cap Screw M10x75 Flat Washer 11x20x2 Nylon Lock Nut M10 Cover Plate Foot Tube Seat Frame Truefitness.com / 800.426.6570 / 636.272.7100...
  • Page 16 CHAPTER 2: ASSEMBLY GUIDE UNIT ASSEMBLY STEPS (continued): STEP 3 Front Frame & Support Frame: ITEM Description 1. Attach the Support Frame to the Front Frame Socket Head Cap Screw M10x20 Socket Head Cap Screw M10x70 2. Install the Support Frame & Front Frame as Socket Head Cap Screw M10x75 shown below.
  • Page 17 CHAPTER 2: ASSEMBLY GUIDE UNIT ASSEMBLY STEPS (continued): STEP 4 Top Frame: ITEM Description 1. Install the Top Frame as shown. Socket Head Cap Screw M10x35 Socket Head Cap Screw M10x75 Flat Washer Nylon Lock Nut M10 Top Frame Truefitness.com / 800.426.6570 / 636.272.7100...
  • Page 18 CHAPTER 2: ASSEMBLY GUIDE UNIT ASSEMBLY STEPS (continued): STEP 5 Lower Support Plates: ITEM Description 1. Install the Lower Support Plates as shown. Flat Washer 6.6x12x1.6 Hexagon Socket Button Head Screw M6x20 Lock Washer #6 Upright Assembly Lower Support Plates Truefitness.com / 800.426.6570 / 636.272.7100...
  • Page 19 CHAPTER 2: ASSEMBLY GUIDE UNIT ASSEMBLY STEPS (continued): STEP 6 Front Shroud Retainer Plates: ITEM Description 1. Secure the Front Shroud Retainer Plates to the Countersunk Pan Head Screw M5x16 Upright Assembly as shown below. Upright Assembly Front Shroud Retainer Plates Truefitness.com / 800.426.6570 / 636.272.7100...
  • Page 20 CHAPTER 2: ASSEMBLY GUIDE UNIT ASSEMBLY STEPS (continued): STEP 7 Weight Stack: ITEM Description 1. Assemble and install the guide rods and Rubber Weight Bumper weight stack to the upright assembly as Rubber Plug shown below. Flat Washer 9x16x1.6 Lock Washer #8 Socket Head Cap Screw M8x30 Guide Rods Top Plate...
  • Page 21 CHAPTER 2: ASSEMBLY GUIDE UNIT ASSEMBLY STEPS (continued): STEP 8 Shield Support Plate: ITEM Description 1. Install the Shield Support Plate as shown below. Flat Washer 6.6x12x1.6 Button Head Cap Screw M6x20 Lock Washer #6 Shield Support Plate Truefitness.com / 800.426.6570 / 636.272.7100...
  • Page 22 CHAPTER 2: ASSEMBLY GUIDE UNIT ASSEMBLY STEPS (continued): STEP 9 Rear Shroud Retainer Plates: ITEM Description 1. Attach both Rear Shroud Retainer Plates to Countersunk Pan Head Screw M5x16 the upright assembly as shown below. Rear Shroud Retainer Plates Truefitness.com / 800.426.6570 / 636.272.7100...
  • Page 23 CHAPTER 2: ASSEMBLY GUIDE UNIT ASSEMBLY STEPS (continued): STEP 10 Route Cables 1. Route the Cables as shown. CAUTION A minimum of 1/2 inch (12.7mm) of the threaded 2. Verify that the no more than one inch (25mm) portion of the cable bolt must be threaded into the top of the cable bolt thread is left exposed.
  • Page 24 CHAPTER 2: ASSEMBLY GUIDE UNIT ASSEMBLY STEPS (continued): STEP 11 Leg Pads: ITEM Description 1. Install the Leg Pads and Leg Pad Support Tube Aluminum Ring 90x26.2x8.5 as shown below. Large Washer 60x10.5x10.9 Flat head Cap Screw M10x40 Socket Set Screw M8x8 Leg Pad Leg Pad Support Tube Truefitness.com / 800.426.6570 / 636.272.7100...
  • Page 25 CHAPTER 2: ASSEMBLY GUIDE UNIT ASSEMBLY STEPS (continued): STEP 12 Seat Pad: ITEM Description 1. Install the Seat Pad as shown below. Socket head Cap Screw M10x40 Flat Washer 11x20x2 Seat Pad Truefitness.com / 800.426.6570 / 636.272.7100...
  • Page 26 CHAPTER 2: ASSEMBLY GUIDE UNIT ASSEMBLY STEPS (continued): STEP 13 Placard Frame: ITEM Description 1. Attach the Placard Frame to the Upright Button Fastener Assembly as shown below. Countersunk Pan Head Screw M5x16 Placard Frame Upright Assembly Truefitness.com / 800.426.6570 / 636.272.7100...
  • Page 27 CHAPTER 2: ASSEMBLY GUIDE UNIT ASSEMBLY STEPS (continued): STEP 14 Front Shroud: ITEM Description 1. Slide the Front Shroud into the Shroud Flat Washer 6.6x12x1.6 Retainer Plates. Hexagon Socket Button Head Screw M5x16 2. Secure the Shroud with six screws and six washers.
  • Page 28 CHAPTER 2: ASSEMBLY GUIDE UNIT ASSEMBLY STEPS (continued): STEP 15 Accessory Tray: 1. Secure the Accessory Tray to the Placard Frame by pushing it down and snapping it into place. Accessory Tray Truefitness.com / 800.426.6570 / 636.272.7100...
  • Page 29 CHAPTER 2: ASSEMBLY GUIDE UNIT ASSEMBLY STEPS (continued): STEP 16 Rear Shroud: ITEM Description 1. Slide the Rear Shroud down into the Retainer Flat Washer 6.6x12x1.6 Plates. Hexagon Socket Button Head Screw M6x20 2. Secure the shroud with four screws and four washers as shown.
  • Page 30 CHAPTER 2: ASSEMBLY GUIDE UNIT ASSEMBLY STEPS (continued): STEP 17 Rear Shroud Cap: ITEM Description 1. Install the Rear Shroud Cap as shown below. Flat Washer 6.5x12x1.6 Button Head Cap Screw M6x20 Truefitness.com / 800.426.6570 / 636.272.7100...
  • Page 31 CHAPTER 2: ASSEMBLY GUIDE UNIT ASSEMBLY STEPS (continued): STEP 18 Lat Bar, Row Handle & Selector Pin: ITEM Description 1. Install the Lat Bar and Row Handle using the Snap Link provided snap links. 2. Install the Weight Selector Pin and attach to the Weight Stack Cable.

  • Page 32: Chapter 3: Product Overview

    CHAPTER 3: PRODUCT OVERVIEW PRODUCT OVERVIEW: Lat Bar Weight Stack Adjustment Pin Leg Pads Row Handle Leg Pad Adjustment Pin Truefitness.com / 800.426.6570 / 636.272.7100...

  • Page 33: Chapter 4: Care & Maintenance

    The following items are critical to the safety of users and maintenance staff as well as to ensure the optimum performance of the machines. These inspections should be performed each day before the equipment is subject to use. TRUE Fitness is not responsible for performing or scheduling regular maintenance or inspections.

  • Page 34: Other Scheduled Preventive Maintenance

    CAUTION Do not use any acidic cleaners. Doing so will weaken the paint or powder coatings and may void the TRUE Fitness Warranty. Never pour or spray liquids on any part of the equipment. Allow the equipment to dry completely before using.

  • Page 35: Cable Inspection & Maintenance

    If any of these conditions are apparent, the machine should immediately be taken out of service and repaired. Be sure to use only cables supplied by TRUE Fitness. DO NOT use cables that have fittings attached with hand- crimp tools.
  • Page 36 CHAPTER 4: CARE & MAINTENANCE CABLE INSPECTION & MAINTENANCE (continued): Cable Tension: Ensure that the cables are adjusted to remove any slack using the threaded end fittings. These are normally located at the weight stack connection. Depending upon the machine, there may be multiple threaded fittings on multiple cables. You can determine if there is too much slack by performing the exercise.

  • Page 37: Chapter 5: Customer Service

    CONTACTING SERVICE: TRUE Fitness recommends that you gather the serial number, model number, and a brief description of the reason for the request. After information has been gathered you may choose to contact your selling dealer or local service company to set an appointment.

  • Page 38: Reporting Freight Claims Or Parts Damage

    Obvious damage to external packaging / internal product. Please refuse the shipment and it will be returned to TRUE Fitness by the carrier. Contact the TRUE Fitness customer support team by calling 800.883.8783 or sales support team by calling 800.426.6570 Monday-Friday during normal business hours to notify us that the shipment has been refused. Once we have received the damaged shipment, a replacement shipment will be sent to you.
  • Page 39 LA T /ROW LAT/ROW The TRUE FORCE Lat/Row is another eye-catching piece of equipment that is a must-have for any facility. Combining both lat pulldown and seated row exercises allows users to further their workout without changing machines, and efficiently utilizes your valuable real estate space by allowing more equipment to be placed in an area.
  • Page 40 TRUE is Impacting Fitness. TRUE has a thirty-four year history making the world’s most premium cardio equipment. Now, we are taking that same manufacturing and design quality and bringing it to you in the new FORCE strength line. All of the features you have come to associate with TRUE are found in the FORCE line…quality, durability, craftsmanship and superior aesthetics.

  • Page 41: Chapter 6: Additional Information

    NOTE: Buying after-market products from a 3rd party will by contacting TRUE directly at: result in voided warranty. TRUE Fitness, Service Department 865 Hoff Road, St. Louis, MO 63366 Frame: The frame is warranted for defects in material and 1.800.883.8783...
  • Page 42 CHAPTER 6: ADDITIONAL INFORMATION Commercial Limited Warranty Force Strength Line Save Time and Register Online! Activate Multiple Warranties at truefitness.com The above Limited Warranty is subject to and will be in accordance with the conditions set forth below: NOTE TO AUTHORIZED WARRANTY LABOR PROVIDERS: Warranty labor reimbursement or warranty parts rights may 1.

  • Page 43: Warranty Registration

    If you prefer to mail your warranty card, have the owner of the product complete the information below and return it to TRUE Fitness within 30 days from the date of equipment installation.
