NOTE: Instead of using HPE Infiniband FDR/Ethernet 10Gb/40Gb cards, the customer can choose to
replace the cards with 10GigE fiber cards, or 10GigE copper cards.
Internal Storage Block
• 3 x 1.8TB 12G SAS 10K HDD (OS and LOG)
• 4 x 1.8TB 12G SAS 10K HDD (Hana data)
• 3 x 400GB 12G SSD (SmartCache)
External Storage Block (Optional)
• For 128GB or 256GB or 384GB configurations
32GB DIMM: 4x or 8x or 12x 4R x 4 PC4 DDR4
• For 512 GB or 768GB, 1TB, or 1.5TB configurations
32GB DIMM: 16x or 24x or 32x or 48x 4R x 4 PC4 DDR4
64GB DIMM: 16x or 24x 4R x 4 PC4 DDR4 (only 1TB and 1.5TB supported)

CS500 Scale-up components for 2TB to 4TB models

The following is a list of software, Server Block, and Internal Storage Block components for 2TB, 3TB and
4TB models. Each configuration occupies 6U of rack space.
Software
• SLES 12 SP1 for SAP HANA/RHEL 7.2 with SAP HANA
• SAP HANA Enterprise SPS12
• HPE Insight and Systems Insight Management Agents
Server Block
• One HPE ProLiant DL580 Gen9 E7-8880 v4 (2.1GHz)/E7-8890 v4 (2.2GHz) with four processors
• 2TB, 3TB and 4TB of RAM
• 1x SmartArray P830i/4G FBWC 12G 2Port SAS/SATA RAID Controller
• 1x SmartArray P431/4G FBWC 12G 2P Ext SAS Controller
• 1x 4-Port 1GbE LAN PCI-e
• 1x 4-Port 1GbE LAN (ALOM)
• 4x Dual Port 10/40 GbE LAN (HPE InfiniBand FDR/Ethernet 10GB/40GB 2-port 544-QSFP Adapter)
• HP Ethernet 10Gb 2P 561T Adptr/ copper
• HP Ethernet 10Gb 2P 560SFP+ Adptr / fiber
NOTE: Instead of using HPE Infiniband FDR/Ethernet 10Gb/40Gb cards, the customer can choose to
replace the cards with 10GigE fiber cards, or 10GigE copper cards.
