Component
1
2
3
4

CS500 Scale-up components for 128GB to 1.5TB models

The following is a list of software, Server Block, and Internal Storage Block components for 128GB,
256GB, 384GB, 512GB, 768GB, 1TB, and 1.5TB models. Each configuration occupies 4U of rack space.
Software
• SLES 12 SP1 for SAP HANA/RHEL 7.2
• SAP HANA Enterprise SPS12
• HPE Insight and Systems Insight Management Agents
Server Block
• One HPE ProLiant DL580 Gen9 E7-8880 v4 (2.1GHz)/E7-8890 v4 (2.2 GHz) with two or four
processors
• 128GB, 256GB, 384GB, 512GB, 768GB, 1TB, and 1.5TB of RAM
• 1x SmartArray P431/4G FBWC 12GB 2Port Ext SAS Controller (optional)
• 1x 4-Port 1GbE LAN (ALOM)
• 1x 4-Port 1GbE LAN PCI-e
• 2x Dual port 10/40 GbE LAN (HPE Infiniband FDR/Ethernet 10 Gb/40Gb 2-port 544-QSFP Adapter)
• HP Ethernet 10GbE 2P 561T Adptr/ copper
• HP Ethernet 10GbE 2P 560SFP+ Adptr / fiber
Description
D3700 - 12 x 1.8TB 12G HDD (HANA DATA)
D3700 - 3 x 1.8TB 12G HDD – (HANA LOG)
D3700 - 5 x 400GB 12G SSD (SmartCache)
2 x 1.8TB 12G HDD – OS (Internal Storage)
Introduction 7
