HP vc4815 - Thin Client Reference Manual

Service reference guide:hp compaq vc4815 thin client
Hide thumbs Also See for vc4815 - Thin Client:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Manual
Enlarged version
Service Reference Guide
HP Compaq vc4815 Thin Client
D o c u m e n t P a r t N u m b e r :
4 8 0 4 2 1 - 0 0 1
J a n u a r y 2 0 0 8

Advertisement

Table of Contents
loading

Related Manuals for HP vc4815 - Thin Client

Summary of Contents for HP vc4815 - Thin Client

  • Page 1 Service Reference Guide HP Compaq vc4815 Thin Client D o c u m e n t P a r t N u m b e r : 4 8 0 4 2 1 - 0 0 1 J a n u a r y 2 0 0 8...
  • Page 2 © 2008 Hewlett-Packard Development Company, L.P. HP, Hewlett Packard, and the Hewlett-Packard logo are trademarks of Hewlett-Packard Company in the U.S. and other countries. Compaq, and the Compaq logo are trademarks of Hewlett-Packard Development Company, L.P. in the U.S. and other countries.

  • Page 3: Table Of Contents

    Contents Product Description Network Firmware ......................1–1 HP Compaq Thin Client vc4815 Series ................1–2 Serial Number Location ....................1–6 Connecting USB Equipment ...................1–6 Locating Additional Information ..................1–7 Spare Parts Lists vc4815 Series Spare Parts List ..................2–1 HP vc4815 Series Setup (F10) Utility Using HP vc4815 Series Setup (F10) Utility ..............3–1 Diagnostics and Troubleshooting Diagnostic Front Panel LEDs and Audible Codes ............4–1...
  • Page 4 Contents Upload the Flash Image and system BIOS Upload the Flash image and BIOS ..................5–1 Thin Client vc4815 Specifications www.hp.com Service Reference Guide...

  • Page 5: Product Description

    Product Description The HP Compaq Thin Client vc4815 Series are Redflag Linux-based terminals that connect over a network to a server where all processing and storage occurs. Because of the nature of the products, troubleshooting is significantly simpler than on a standard PC and previous thin clients.

  • Page 6: Hp Compaq Thin Client Vc4815 Series

    Product Description H P C omp aq T h in C lien t v c 4 8 1 5 S eries Front view - vc4815 Power button Flash activity LED Power LED USB ports (2) Service Reference Guide www.hp.com...
  • Page 7 Product Description Product Description H P C omp aq T h in C lien t v c 4 8 1 5 S eries Rear View of the vc4815 PS/2 connectors (2) Power connector Serial connectors (4) Lock Slot Monitor connector Ethernet RJ-45 connector Universal Serial Bus (USB) Parallel connector...

  • Page 8: Serial Number Location

    Product Description Serial Number Location The serial number is displayed on the side of the unit. Connecting USB Equipment USB mouse devices and keyboards do not require special drivers and are considered to be plug and play peripherals. Certain USB devices such as printers and modems, however, may require special drivers.

  • Page 9: Locating Additional Information

    Product Description L o c a t i n g A d d i t i o n a l I n f o r m a t i o n The following documentation is available to support these products: Quick Setup Hardware Reference Guide Redflag Linux User manual...

  • Page 10: Spare Parts Lists

    SPS-Base, vc4815 512F/512R Linux 458813-001 SPS-Base, vc4815 1GBF/512R Linux 458814-001 SPS-Base, vc4815 2GBF/512R Linux 458815-001 SPS-KYBD USB, Basic, Vista-PRC 435382-AA1 SPS-MOUSE,OPTICAL CARBONITE 390938-001 For a full list of supported and leveraged Hewlett-Packard and third party options, go to: http://h18004.www1.hp.com/products/thinclients/software.html Service Reference Guide www.hp.com...

  • Page 11: Hp Vc4815 Series Setup (F10) Utility

    HP vc4815 Series Setup (F10) Utility U s i n g H P v c 4 8 1 5 S e r i e s S e t u p ( F 1 0 ) U t i l i t y The Setup utility can be accessed only by turning the computer on or restarting the system.
  • Page 12 HP vc4815 Series Setup (F10) Utility 4. Use the arrow (up and down, or left and right) keys to select the appropriate heading, then press the key. To return to the Enter Setup Utility menu, press the key. 5. To apply and save changes, select Save Setting and Exit Setup. ✎...
  • Page 13 HP vc4815 Series Setup (F10) Utility v c 4 8 1 5 S e r i e s S e t u p U t i l i t y (Continued) H e a d i n g O p t i o n D e s c r i p t i o n Standard System Date...
  • Page 14 HP vc4815 Series Setup (F10) Utility v c 4 8 1 5 S e r i e s S e t u p U t i l i t y (Continued) H e a d i n g O p t i o n D e s c r i p t i o n Integrated USB Controller...
  • Page 15 HP vc4815 Series Setup (F10) Utility HP vc4815 Series Setup (F10) Utility Heading Option Description v c 4 8 1 5 S e r i e s S e t u p U t i l i t y (Continued) H e a d i n g O p t i o n D e s c r i p t i o n...

  • Page 16: Diagnostics And Troubleshooting

    Diagnostics and Troubleshooting POST Diagnostic Front Panel LEDs and Audible Codes This section covers the front panel LED codes as well as the audible codes that may occur before or during POST that do not necessarily have an error code or text message associated with them.
  • Page 17 D i a g n o s t i c F r o n t P a n e l L E D s a n d A u d i b l e C o d e s Possibl Beeps Activity Recommended Action...

  • Page 18: System Requirements

    Reload Flash Image and BIOS System Requirements To create a recovery device for the purpose of reflashing or restoring the software image on the ROM, you will need the following: One or more HP Compaq vc4815 Series Thin Clients USB flash device 512MB Compatible USB flash devices (drive keys) are available from www.diskonkey.com.
  • Page 19 Reload image and system BIOS Hainan Image Reloading 1, Download the Image file *.gho from web. 2, Make a DOS Bootable USB flash drive(>=512M). Copy the image file and ghost.exe (ver11.0.1) to the USB flash drive. 3, Boot from the USB device. Run ghost.exe. System BIOS Update 1.
  • Page 20 Thin Client vc4815 Specifications S p e c i f i c a t i o n s - v c 4 8 1 5 S e r i e s I t e m D e s c r i p t i o n GV665PA#AB2 vc4815 Processor VIA C7 1GHz...
  • Page 21 Thin Client vc4815 Specifications S p e c i f i c a t i o n s - v c 4 8 1 5 S e r i e s I t e m D e s c r i p t i o n Memory Flash Memory 512 MB , 1GB, 2GB, Apacer ADMII series 44PIN 180 degree DOM...
  • Page 22 I/O ports and Four USB ports (two in front, two in rear), 4 serial, one parallel, one RJ-45, two PS/2 connectors Resident Operating Redflag Linux System Session Allocation HP PC Session Allocation Manager Software for the Consolidated Client Infrastructure, Managers/Session Citrix Desktop Broker for Virtual Desktop Infrastructure Brokers Server OS...
  • Page 23 Dimensions H x W x D Without stand 235 x 60 x 195 mm (approximate) Weight (approximate) Without stand 1.9 kg Environmental Temperature range on 50° to 104° F (10° to 40° C) Temperature range off -22° to 140° F (-30° to 60° C) Humidity 20% to 80% condensing 10% to 95% non-condensing...
  • Page 24 Appendix A HP Compaq vc4815 系列串口定义用户指南 HP Compaq vc4815终端默认具有4个串口，分别为串口一、串口二，串口三、 串口四。 定 辅口2 主口 辅口1 辅口3 义 （串口3） （串口1） （串口2） （串口4） （TTL） 引脚 DCD/ +5V +5V / DCD +5V / DCD +5V / DCD 1脚 RXD/TXD 2脚 TXD/RXD 3脚 DTR/ +12V DTR/+5V /+12V NC/DTR DTR/+5V /+12V...
  • Page 25 HP Compaq vc4815终端默认出厂设置 定 辅口2 主口 辅口1 辅口3 义 （串口3） （串口1） （串口2） （串口4） （TTL） 引脚 1脚 2脚 3脚 4脚 5脚 6脚 7脚 8脚 9脚 注：辅口2的 2、3脚为RS232，8、9脚为TTL 主串一的1脚可以提供+5V供电，8，9脚可跳选为RXD/TXD的TTL模式...
  • Page 26 主口（串口1）定义： 定 主口 义 （串口1） 引脚 DCD/ +5V 1脚 2脚 3脚 DTR/ +12V 4脚 5脚 6脚 RTS/+12V 7脚 CTS/RXD 8脚 （TTL） RI/TXD 9脚 （TTL）...
  • Page 27 跳线器默认如上图所示 COMA_JP1：更改跳线器将其置左(2连接3)，可为主口（串口1）的1脚取＋5V COMA_JP2：更改跳线器将其置左(2连接3)，可为主口（串口1）的4脚取＋12V COMA_JP3：更改跳线器将其置左(2连接3)，可为主口（串口1）的7脚取＋12V COMA_JP4：更改跳线器将其置左(2连接3)，可为主口（串口1）的8脚取RXD （TTL电平） COMA_JP5：更改跳线器将其置左(2连接3)，可为主口（串口1）的8脚取TXD （TTL电平）...
  • Page 28 辅口2（串口3）（TTL）定义： 定 辅口2 义 （串口3） （TTL） 引脚 +5V / DCD 1脚 RXD/TXD 2脚 TXD/RXD 3脚 NC/DTR 4脚 5脚 NC/DSR 6脚 NC/RTS 7脚 RXD/TXD(TTL) 8脚 TXD/RXD(TTL) 9脚...
  • Page 29 跳线器默认如上图所示 COMB_JP1：更改跳线器将其置右(2连接3)，可为辅口2(串口3)(TTL)的1脚取 COMB_JP2：更改跳线器将其置左(2连接3)，可为辅口2(串口3)(TTL)的2脚取 TXD(RS232)信号 COMB_JP3：更改跳线器将其置左(2连接3)，可为辅口2(串口3)(TTL)的3脚取 RXD(RS232)信号 COMB_JP4： 更改跳线器将其置左(2连接3)， 可为辅口2(串口3)(TTL)的8脚取TXD （TTL电平）信号 COMB_JP5： 更改跳线器将其置左(2连接3)， 可为辅口2(串口3)(TTL)的9脚取RXD （TTL电平）信号 COMB_JP6： 插上跳线器 (1连接2)， 可为辅口2(串口3)(TTL)的4脚取DTR (RS232) 信号 COMB_JP7： 插上跳线器 (1连接2)， 可为辅口2(串口3)(TTL)的6脚取RTS (RS232) 信号 COMB_JP8： 插上跳线器 (1连接2)， 可为辅口2(串口3)(TTL)的7脚取DSR (RS232) 信号...
  • Page 30 辅口1（串口2）与 辅口3（串口4）定义： 定 辅口1 辅口3 义 （串口2） （串口4） 引脚 +5V / DCD +5V / DCD 1脚 2脚 3脚 DTR/+5V /+12V DTR/+5V /+12V 4脚 5脚 6脚 RTS/+12V RTS/+12V 7脚 8脚 9脚...
  • Page 31 跳线器默认如上图所示 COMC_JP1：更改跳线器将其置下(2连接3)，可为辅口1（串口2）的1脚取+5V COMC_JP2：更改跳线器将其置下(2连接3)，可为辅口1（串口2）的7脚取＋12V COMCD_JP1： COMCD_JP1 +12V 辅口1第 4脚 7连接9 5连接7 3连接5 1连接3 辅口4 第4脚 8连接10 6连接8 4连接6 2连接4 COMD_JP1：更改跳线器将其置下(2连接3)，可为辅口3（串口4）的1脚取+5V COMD_JP2：更改跳线器将其置下(2连接3)，可为辅口3（串口4）的7脚取＋12V...
