Item Bond
1 bond2
2 bond2
3 bond8
4 bond4
5 bond7
6 bond3
7 bond6
8 bond6
9 bond8
10 bond4
11 bond7
12 bond3
Figure 5 - HPE ConvergedSystem (4 Socket) - 128GB/256GB/384GB/512GB/768GB/1TB/
1.5TB/2TB/3TB/4TB appliance network sample network layout
Card Slot Type
PCI#8 Port1 10/40GigE
PCI#7 Port1 10/40GigE
PCI#6 Port 1 1GigE
PCI#6 Port2 1GigE
PCI#6 Port3 1GigE
PCI#6 Port1 1GigE
PCI#6 Port1 10GigE
ALOM Port1 10GigE
ALOM Port1 1GigE
ALOM Port2 1GigE
ALOM Port3 1GigE
ALOM Port4 1GigE
Devices Network
Traffic
p8p1 data10
p8p1 data10
p6p1 data1
p6p4 Management
p6p3 Backup
p6p4 user/BI
p7p2 Replication
p8p2 Replication
em49 data1
em50 Management
em51 Backup
p6p1 data1
Introduction 11
