Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
The minimum requirements are for iLO and Data management networks to be configured. All hostnames
must follow SAP requirements as specified in SAP note 611361.

CS500 Scale-up storage

The file system layout for the HPE ConvergedSystem 500 for SAP HANA Single System Scale-up is
shown in Figure 6. The operating system is on a mirrored pair of local disks; the data, log, and shared
directories are separate file system mount points and are dependent on the model size for the various
types of storage and location.
Figure 6 - SAP recommended file system layout with edits for deployment overlay
12 Introduction
Bond Card Slot
bond4 ALOM Port2
bond4 PCI#6 Port2
bond7 PCI#4 Port1
bond2 PCI#7 Port2
bond6 PCI#5 Port2
bond6 PCI#4 Port2
bond3 PCI#7 Port1
bond3 PCI#8 Port1
bond9 ALOM Port3
bond8 PCI#6 Port1
bond8 ALOM Port1
bond7 PCI#5 Port1
bond2 PCI#8 Port2
bond9 PCI#6 Port3
Type Devices
1GigE em50
1GigE p6p2
10/40GigE p4p1
10/40GigE p7p2
10/40GigE p5p2
10/40GigE p4p2
10/40GigE p7p1
10/40GigE p8p1
1GigE em51
1GigE p6p1
1GigE em49
10/40GigE p5p1
10/40GigE p8p2
1GigE p6p3
Network
Traffic
management
management
backup
data10
replication
replication
user/BI
user/BI
quorum
data1
data1
backup
data10
quorum
