R82 Multi Frame:x Pre-Sales Information page 2

Pre-sales information
Multi Frame:x
Disinfection description
Dimensions
Mass
Maximum slope
Type(s) of tyres
Used in combination with other
products
Conformity
Resistance to ignition
Warning about dangerous
combinations
List of accessories, detachable
parts and materials
Programmable controller
information
Operator control adjustments
Folding and dismantling
Used in motor vehicles
2017-03 rev. 03
detergent or disinfection without chlorine, in a machine designed for
medical devices. Equipment shall be disassembled as necessary to
allow access of the detergent solution to all parts. Equipment
components and utensils shall be scrapped or rough cleaned to remove
food particle accumulation. Please allow the product to dry before reuse.
The product can be disinfected with a 70% disinfectant solution. It is
recommended to wipe off any residue and dirt from the upholstery, using
a cloth with warm water and a mild detergent/soap without chlorine and
let it dry before disinfection.
http://www.R82.org - Select product or click
http://www.R82.org - Select product or click
Mass of test dummy is 100 kg (EN12183).
http://www.R82.org - Select product or click
12½", 20", 22" or 24" rear wheels.
6" or 7" front wheels.
Either as solid or pneumatic tyres
Can be used in combination with
•
Panda Futura 5 seat
•
x:panda seat 4S, 4M, 4L
General combination scheme available at
Select Chart transport overview or click
The product conforms to standard EN12183 including requirements and
test methods for static, impact and fatigue strengths (ISO 7176-8)
N/A
The CE mark must be removed when rebuilding the product, when used
in combination with a product from another manufacturer or when using
other than original R82 spare parts and fittings.
http://www.R82.org - Select product or click
N/A
Manual
The push brace on Multi Frame:x can be folded down and make the
frame smaller.
1) If mounted, dismount the seat
2) Pull the red knob on the back of the frame to disconnect the gas strut.
The push brace will loosen and can be folded forward over the frame.
When folding, please be careful not to squeeze fingers
The Multi Frame:x complies with ISO 7176-19, for safe transportation in
motor vehicles. Detailed information about configurations for frames and
seat, max. load/user weight and transportation can be found
The user should transfer to the vehicle seat and use the vehicle-installed
R82 A/S Parallelvej 3 DK - 8571 Gedved
here
here
here
http://www.r82.org/support
here
here
here
-
support.R82.org
Page 2 of 3
