4.- DATA VISUALIZATION ON DISPLAY
4.1.- Base screen
The disturbance analyzer has an only visualization screen. Main measurement
or set-up parameters can be read at this screen.
DISTURB
L1
V
220V
Hz
50.0
Dist.
10
04/06/04
File:STD-PROG.A5D
Trigger:
200V/ 50.0 Hz
Level:1.2/ 75%
Com: 9600/ NO /8/1
Single-phase analyzer
The 160 x 160 pixels, liquid crystal display can be divided into two parts:
instantaneous parameters measured from the power line (V = Voltage, Hz =
Frequency & Dist. = No. of detected disturbances) are shown on the upper part; while
Set-up values (file name, trigger values & communication parameters) are shown on
the lower part.
4.2.- Warning messages
Some warning messages can appear at the visualization screens. These
messages inform about the device performance:
-
STOP: The analyzer is not recording data.
-
M. Full: Memory is full.
-
M.Error: There is an error in the memory. The memory must be formatted.
Analyzer battery charge status. When only the symbol 3is shown,
-
it means that the battery is very low and the analyzer might turn off at any
moment.
-
battery charge level.
-
Full battery charge.
-
WARNING MAX 500 V: The maximum allowable phase to neutral voltage
of 500 V has been exceeded during the measuring process. When
measuring phase-to-phase voltages the limit is set at 866 V.
16:06:35
The battery is charging. The user can also see the accumulated
Page
DISTURB
L1
L2
V
220V 219V
Hz
50.0
Dist.
41
04/06/04
16:06:35
File:STD-PROG.A5D
Trigger:
200V/ 50.0Hz
Level:1.2/ 75%
Com: 9600/ NO /8/1
Three-phase analyzer
nº
9
L3
220V
