Focus Spot 4Z Operating Instructions
PANEL CONTROL
- With this function you can make fine adjustments.
1. Press the MODE button to access the main menu. Press the UP or DOWN buttons so that "Test" is high-
lighted, then press ENTER.
2. Press the UP or DOWN buttons until "Panel. Ctrl" is displayed, press ENTER.
3. Use the UP or DOWN buttons to scroll through the various functions.
4. Press ENTER when you find the function you would like to adjust or press MODE to exit.
CALIBRATE
- With this function you can calibrate and adjust the effect wheels to their correct positions. The
Calibration password 050. NOTE: ONLY QUALIFIED TECHNICIANS SHOULD PERFORM THIS FUNCTION.
1. Press the MODE button to access the main menu. Press the UP or DOWN buttons so that "Test" is highlighted,
then press ENTER.
2. Press the UP or DOWN buttons until "Calibrate" is displayed, press ENTER.
3. "XXXX" will be displayed. The password is 050.
4. Press ENTER to confirm or press MODE to exit.
PROGRAM
EDIT PROGRAM: - The fixture comes equipped with a built-in DMX recorder that allows custom programs to
be installed and recalled directly from the fixture's control board. Programs can be created and stored using
the fixture's control board or by using an external DMX controller.
Select.Prog – This function allows the user to select one of nine of the user defined built-in programs. This
program is then accessed in "Function Mode" under "Program Run."
Edit.Prog – This function allows the user to edit the built-in programs.
Edit.Scene – This function allows the user to edit or define the actual scenes that are stored in the user
defined built-in programs that are accessed in the previous step.
